User Manual
Transceiver U922

Clip Replacement

For System Administrators

2000 01 25 /Rev.A
U922 has a belt clip on the back.
The clip can be easily replaced
by lifting the top of the clip out
from the unit and then pushing
the clip upwards.
The system administrator uses the software application Pocket Unit Programmer,
included in the software package Win900 Base Kit, to facilitate programming and
for administration of pocket units. See section Pocket Unit Programmer below. For
example, some functions can be open to the user and others locked.
Programming the 922
The parameter memory consists of an EEPROM (SIM-card). The transceiver can be
programmed in the storage/charging rack via the system bus or via radio with a so-
called programming paging. See also the document Win900 User Guide, document
number TD90838 in Volume 7 "Software". To program a transceiver in a charging
rack, the transceiver must be switched on. The transceiver is programmed from
Pocket Unit Programmer via the system bus.
The transceiver system identity and the call number can also be programmed via
radio. When the transceiver is set to the "PROGRAM" operation mode it can
receive a programming paging that is generated from a control keyboard or a
telephone (via a PBX interface).
OPEN>
<LOCK
TD 91836GB
The transceiver memory consists
of a SIM card located behind the
battery pack.
The SIM card can easily be
removed for replacement or to
be put in another unit.
Slide the locking plate to the
right and lift the card holder to
remove the SIM card
18
