- Page 1 NEMA 12 Conversion Kit for 9000X Adjustable Frequency Drive Installation Manual New Information January 2004 MN04003011E For more information visit: www.eatonelectrical.com...
- Page 3 January 2004 Important Notice – Please Read The product discussed in this literature is subject to terms and conditions outlined in Eaton Electrical Inc. selling policies. The sole source governing the rights and remedies of any purchaser of this equipment is the relevant Eaton Electrical Inc. selling policy.
-
Page 4: Table Of Contents
NEMA 12 Conversion Kit — Installation Manual January 2004 Table of Contents SAFETY Definitions and Symbols .......... -
Page 5: Definitions And Symbols
NEMA 12 Conversion Kit — Installation Manual January 2004 Safety Definitions and Symbols WARNING This symbol indicates high voltage. It calls your attention to items or operations that could be dangerous to you and other persons operating this equipment. Read the message and follow the instructions carefully. - Page 6 NEMA 12 Conversion Kit — Installation Manual January 2004 For more information visit: www.eatonelectrical.com MN04003011E...
-
Page 7: Chapter 1 - General
NEMA 12 Conversion Kit — Installation Manual January 2004 Chapter 1 — General ® ® The NEMA Type 12 Kit is used to convert a Cutler-Hammer 9000X drive by Eaton Electrical from a NEMA Type 1 to a NEMA Type 12 enclosure. A NEMA Type 12 enclosure may be necessary when the adjustable frequency drive is used in ambient conditions that may contain moisture or dust. - Page 8 NEMA 12 Conversion Kit — Installation Manual January 2004 For more information visit: www.eatonelectrical.com MN04003011E...
-
Page 9: Chapter 2 - Contents Of Kits
NEMA 12 Conversion Kit — Installation Manual January 2004 Chapter 2 — Contents of Kits OPTN12FR4 (Frame 4) and OPTN12FR5 (Frame 5) The contents of the NEMA Type 12 Kits for Frames 4 and 5 are shown in Figure 2-1 . -
Page 10: Optn12Fr6 (Frame 6)
NEMA 12 Conversion Kit — Installation Manual January 2004 OPTN12FR6 (Frame 6) The contents of the NEMA Type 12 Kit for Frame 6 is shown in Figure 2-2 . Components 1. Grounding Terminals 2. Screws, M4x10 3. Grounding Cable Clamps 4. -
Page 11: Chapter 3 - Installation
NEMA 12 Conversion Kit — Installation Manual January 2004 Chapter 3 — Installation Installation Instructions for Frame 4 WARNING After disconnecting the utility, wait until the unit cooling fan stops and the indicators on the control panel are extinguished (if no keypad is present, check the indicators in the cover). -
Page 12: Table 3-1: Instructions For Nema Type 12 Kit Installation - Frame 4
NEMA 12 Conversion Kit — Installation Manual January 2004 Table 3-1: Instructions for NEMA Type 12 Kit Installation — Frame 4, continued Step Procedure Remove the cover of the control. Open the control cable cover and remove the cable cover and detach the grounding rack. - Page 13 7. Re-install the grounding rack with cable clamps mounted using (M4x16) screws next to fan (#2). Install the NEMA 12 conduit plate on the base of the drive. Tightly screw in the enclosure using the attached screws.
-
Page 14: Installation Instructions For Frame 5
NEMA 12 Conversion Kit — Installation Manual January 2004 Installation Instructions for Frame 5 WARNING After disconnecting the utility, wait until the unit cooling fan stops and the indicators on the control panel are extinguished (if no keypad is present, check the indicators in the cover). Wait five more minutes before doing any work on the connections. -
Page 15: Table 3-2: Instructions For Nema Type 12 Kit Installation - Frame 5
NEMA 12 Conversion Kit — Installation Manual January 2004 Table 3-2: Instructions for NEMA Type 12 Kit Installation — Frame 5, continued Step Procedure Insert the rubber sealing as shown for FR5. Re-install the fan ensuring that the connector clip fits accurately. Do not force. - Page 16 Connect the red wire into terminal 6 and the black into terminal 7. Re-install the grounding rack with cable clamps mounted using (M4x16) screws next to fan (#2). Install the NEMA 12 cable entry flange on the base of the drive. For more information visit: www.eatonelectrical.com MN04003011E...
-
Page 17: Installation Instructions For Frame 6
NEMA 12 Conversion Kit — Installation Manual January 2004 Installation Instructions for Frame 6 Table 3-3: Instructions for NEMA Type 12 Kit Installation — Frame 6 Step Procedure Remove the cover of the AF Drive. Remove the cable cover and screw the grounding cable clamps into place. -
Page 18: Table 3-3: Instructions For Nema Type 12 Kit Installation - Frame 6
NEMA 12 Conversion Kit — Installation Manual January 2004 Table 3-3: Instructions for NEMA Type 12 Kit Installation — Frame 6, continued Step Procedure Open the small lid on the power unit cover, and set the screw aside for later use. - Page 19 NEMA 12 Conversion Kit — Installation Manual January 2004 Table 3-3: Instructions for NEMA Type 12 Kit Installation — Frame 6, continued Step Procedure Route wiring as shown in the picture at right. Install the NEMA Type 12 cable entry flange on the base of the drive.
- Page 20 NEMA 12 Conversion Kit — Installation Manual January 2004 3-10 For more information visit: www.eatonelectrical.com MN04003011E...
-
Page 21: Chapter 4 - Specifications
NEMA 12 Conversion Kit — Installation Manual January 2004 Chapter 4 — Specifications Table 4-1: NEMA Type 12 Kit — Dimensions and Weight Catalog Frame Approximate Dimensions in Inches (mm) Approximate Number Size Weight in Lb. (kg) Length Width Height... - Page 22 NEMA 12 Conversion Kit — Installation Manual January 2004 For more information visit: www.eatonelectrical.com MN04003011E...
