VP Keypad Access Device
Keypad Adapter Plate
• A keypad adapter plate is an aluminum plate used to mount
keypads to stands, bollards, and goosenecks manufactured by
other companies.
• The installer measures, marks, and drills holes in the adapter
plate to match the stand configuration. To prevent tampering,
ensure the holes are countersunk on the same side as the
installed screws so that the keypad covers the mounting screws.
• The screws and screwholes provided on the aluminum plate
match up with the VP keyhole mounting pattern.
Single Bollard
A bollard is an attractive and functional stand for
keypads. It helps protect the keypad from vehicle
damage. It can be used in driveways for vehicle
access or near doors as a keypad stand. Height is
determined by the length of the pipe on which it
is mounted.
Bollards can be filled with concrete and used as
barriers to protect keypads, walls, or gates.
Both single and double bollards are mounted on
a Schedule 40 10 3/4" diameter pipe with a .365"
wall. This pipe is footed in concrete and filled 3/4
of the way with concrete to create a solid barrier.
The entire pipe and bollard are then painted to
match the facility. Contact PTI Security Systems for
full measured installation plans and instructions.
6
Drawing 4: single
bollard
