CMT2300AW RF-EB User Guideline

Summary

The CMT2300AW evaluation platform is designed to help users evaluate the performance of
CMOSTEK's wireless transceiver chip CMT2300AW. The evaluation platform consists of a pair of universal
wireless evaluation boards (RF-EB) and a pair of wireless modules（CMT2300AW-EM）. Users can evaluate
the main characteristics of the CMT2300AW chip through the platform, such as the actual environment
communication distance, signal strength and packet loss rate.
The part numbers covered in this document are shown below.
Part No.
Frequency
CMT2300AW
127 - 1020MHz
Copyright © By CMOSTEK
Table1. The part numbers covered in this document
Modem
(G)FSK/OOK
Rev 0.8 | Page 1/13
Function
Configuration
Transceiver
Register
AN148
AN148
Package
QFN16
www.cmostek.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMT2300AW and is the answer not in the manual?

Questions and answers

Related Manuals for CMOSTEK CMT2300AW

Summary of Contents for CMOSTEK CMT2300AW

  • Page 1: Summary

    CMOSTEK's wireless transceiver chip CMT2300AW. The evaluation platform consists of a pair of universal wireless evaluation boards (RF-EB) and a pair of wireless modules（CMT2300AW-EM）. Users can evaluate the main characteristics of the CMT2300AW chip through the platform, such as the actual environment communication distance, signal strength and packet loss rate.

  • Page 2: Table Of Contents

    Summary ................................1 Hardware Platform ........................... 3 1.1 Evaluation Motherboard (RF-EB) ....................... 3 1.2 Wireless Module (CMT2300AW-EM) ....................4 User Operation Guideline for Evaluation Platform ................6 2.1 LCD Function Icon ..........................6 2.2 Evaluation Platform Operation Process ..................... 6 2.3 Configure Interface Parameter ......................

  • Page 3: Hardware Platform

    Power Switch - The power switch (S3) determines the power supply of the RF-EB. When the power switch is switched to 'USB', the RF-EB voltage is supplied by the USB socket. When the power switch is switched to 'Battery', the RF-EB voltage is supplied by the battery. www.cmostek.com Rev 0.8 | Page 3/13...

  • Page 4: Wireless Module (Cmt2300Aw-Em)

    CMT2300AW-EM is the evaluation module of the wireless transceiver chip CMT2300AW provided by CMOSTEK. It consists of the simple peripheral circuit, the matching network and the CMT2300AW chip. The top and bottom view of CMT2300AW-EM are shown below. The pins are defined as shown in the following table.
  • Page 5 AN148 Table2. CMT2300AW-EM Pin Definition Definition FCSB SCLK GPO1 SDIO GPO2 GPO3 Evaluate Module Type (EM Type)–Currently only support the 13dBm and 20dBm module. Evaluate Module Frequency (EM Frequency)– Currently support 315MHz, 433MHz, 868MHz and 915MHz frequency. www.cmostek.com Rev 0.8 | Page 5/13...

  • Page 6: User Operation Guideline For Evaluation Platform

    CMT2300AW evaluation platform user operation processes are as follows: Turn off the RF-EB power, see section 2.1. Insert the wireless module (CMT2300AW-EM) into the slot of the connector on the RF-EB and make sure that CMT2300AW-EM and RF-EB are properly connected.

  • Page 7: Chip Function Configuration Interface (Chip Setting)

    Chip Part No. –The chip model is automatically identified through the RF-EB boot phase. Chip Function –The CMT2300AW evaluation platform provides options for TX, RX, and TRX functions. The specific description is as the follow table. Table4. CMT2300AW RF-EB Function Description...

  • Page 8: Wireless Parameter Configuration Interface1 (Rf Parameters)

    工作频偏 Figure5. Wireless Parameter Configuration Interface1 Modulation –MT2300A RF-EB has three modulation modes, OOK, FSK and GFSK. Symbol rate–CMT2300AW RF-EB provides users with a wide variety of configurable symbol rates, as shown in the following table. Table5. Symbol rate Modem...

  • Page 9: Wireless Parameter Configuration Interface2 (Rf Parameters)

    Data Mode–The CMT2300AW RF-EB data mode supports Direct mode and Packet mode. When the symbol rate is greater than 100 kbps, the CMT2300AW RF-EB only supports Packet mode. TX Power–The transmitting power of the CMT2300AW RF-EB is subject to the module type (EM Type). www.cmostek.com...

  • Page 10: Data Frame Configuration Interface

    Preamble–The preamble can be configured with a range of 1-8 bytes. ID–The ID on the CMT2300AW RF-EB interface can only select numbers between 0 and 9, but in fact the ID configured to CMT2300AW is 4 bytes, with the contents of 0x (0x55+ID) (0x55+Length) 5678.
  • Page 11 信号强度指示 数据帧 Figure9. Configuration Information Display Interface Signal strength indicator (RSSI) –The signal strength when it receives the data frame. Data Frame–It is the number of data frames that have been received or transmitted. www.cmostek.com Rev 0.8 | Page 11/13...

  • Page 12: Document Modification Record

    AN148 3. Document Modification Record Table8. Document Modification Record Sheet Version Chapter Modification descriptions Date Initial release 2017-10-08 www.cmostek.com Rev 0.8 | Page 12/13...

  • Page 13: Contact Information

    The material contained herein is the exclusive property of CMOSTEK and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of CMOSTEK. CMOSTEK products are not authorized for use as critical components in life support devices or systems without express written approval of CMOSTEK.
