INSTALLATION &
OPERATING INSTRUCTIONS
REVISION:
Form No. 3310426.022 7/07
(Replaces 3310426.014)
(French 3310427.020)
©2007 Dometic Corporation
LaGrange, IN 46761 U.S.A.
This manual must be read and
understood before installation,
adjustment, service, or mainte-
nance is performed. This unit must
be installed by a qualified service
technician. Modification of this
product can be extremely hazard-
ous and could result in personal
injury or property damage.
Important:
These instructions must stay with
unit. Owner read carefully.
Lire et comprendre ce manuel avant
de procéder à l'installation, à des ré-
glages, de l'entretien ou des répara-
tions. L'installation de cet appareil doit
être effectuée par un réparateur quali-
fié. Toute modification de cet appareil
peut être extrêmement dangereuse et
entraîner des blessures ou dommages
matériels.
MODEL
920(XX)(XX).000(#)
920(XX)(XX).020(#)
