Flow Safe F7000 SERIES Installation, Operation & Maintenance Manual page 43

INSTALLATION, OPERATION, &
MAINTENANCE MANUAL
TITLE: F7000 / 8000 Series
Pilot-Operated Safety Relief Valve
8.2 PILOT VALVE SOFTGOODS (cont'd)
F500 Softgoods Kits:
P/N F500-LPS-DXYZ
F500-LPT-DXYZ
Contents (See drawing on Page 25):
Seat *
Diaphragm
Small face seal
Large face seal
Bushing seal
Feedback piston seal
Spindle seal
Diaphragm fastener seal
BFP O-ring
Diaphragm support ring seal
BFP seal (Teflon)
SPI seal
SPI bushing seal
SPI pin seal
SPI seat
P/N F500-MPS-7XY
F500-MPT-7XY
F500-HPS-9XY
F500-HPT-9XY
F500IM-HPS-9XY
F500IM-HPT-9XY
Contents:
(See drawings on Pages 26-27)
Seat *
Piston seal
Small face seal
Large face seal
Bushing seal
Feedback piston seal
Spindle seal
Diaphragm fastener seal
BFP O-ring
Piston ring seal
BFP seal (Teflon)
Inlet port face seal
Lower bushing seal
Lower bushing seal backup ring (Teflon)
SPI seal
SPI bushing seal
SPI pin seal
SPI seat
* Hardness per Code"D" (P. 41)
See Page 41 for terminal digits "D", "X", "Y", & "Z".
LP (to 285 psig)
LP (to 285 psig), with set point indicator
F500-LPS- F500-LPT-
2
1
2
1
1
1
1
1
1
1
1
--
--
--
--
IP (286 - 999 psig), Conventional body
IP (286 - 999 psig), Conventional body, with set point indictor
HP (1000 - 6000 psig), Conventional body
HP (1000 - 6000 psig), Conventional body, with set point indicator
HP (1000 - 6000 psig), 'IM'-style body
HP (1000 - 6000 psig), 'IM'-style body, with set point indicator
F500-MPS-
F500-HPS-
2
1
2
1
1
1
1
1
1
1
1
--
--
--
--
--
--
--
Rev. T
Page 43 of 43
2
1
2
1
1
1
1
1
1
1
1
2
1
1
1
Qty.
F500-MPT-
F500-HPT- F500IM-HPS-
2 2
1 1
2 2
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
-- 1
-- 1
-- 1
2 --
1 --
1 --
1 --
F500IM-HPT-
2
1
2
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
