Thank you for choosing our product.
For proper operation, please read and keep this manual carefully.
If you have lost the User's Manual, please contact the local agent or visit www.skyworth-ac.com or sent
email to swac@skyworth.com for electronic version.
USER'S MANUAL
Split Air Conditioner
MODEL
FSS101EI/JDF-N3
FSS121EI/JDF-N3
FSS181EI/JDF-N3
FSS 241 EI/JDF-N3
Advertisement
Table of Contents
Related Manuals for Fluo FSS101EI/JDF-N3
Summary of Contents for Fluo FSS101EI/JDF-N3
- Page 1 USER'S MANUAL Split Air Conditioner MODEL FSS101EI/JDF-N3 FSS121EI/JDF-N3 FSS181EI/JDF-N3 FSS 241 EI/JDF-N3 Thank you for choosing our product. For proper operation, please read and keep this manual carefully. If you have lost the User's Manual, please contact the local agent or visit www.skyworth-ac.com or sent...
-
Page 2: Table Of Contents
Content Operation Notices Precautions ......................1 Parts name ......................6 Operation Guide Operation guide....................7 Remote controller ....................8 Buttons on remote controller................9 Indoor unit address inquiry................13 Maintenance Clean and maintenance ................... 13 Malfunction Malfunction analysis ..................15 Safety operation of flammable refrigerant ............. -
Page 3: Precautions
Precautions Please read this operating manual carefully before operating the unit. Appliance filled with flammable gas R32. Before use the appliance, read the owner's manual first. Befoer install the appliance, read the installation manual first. Befoer repair the appliance, read the service manual first. The figures in this manual may be different with the material objects, please refer to the material objects for reference. - Page 4 Precautions WARNING Operation and Maintenance This appliance can be used by children aged of 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 5 Precautions WARNING Do not block air outlet or air inlet. It may cause malfunction. Do not spill water on the remote controller, otherwise the remote controller may be broken. When below phenomenon occurs, please turn off air conditioner and disconnect power immediately, and then contact the dealer or qualified professionals for service.
- Page 6 Precautions WARNING Including an circuit break with suitable capacity, please note the following table.Air switch should be included magnet buckle and heating buckle function, it can protect the circuit-short and overload. Don't use unqualified power cord. Make sure the power supply matches with the requirement of air conditioner.Unstable power supply or incorrect wiring or malfunction.
- Page 7 Precautions WARNING The appliance must be positioned so that the plug is accessible. All wires of indoor unit and outdoor unit should be connected by a professional. If the length of power connection wire is insufficient, please contact the supplier for a new one. Avoid extending the wire by yourself.
-
Page 8: Parts Name
Parts name Indoor unit Panel Air inlet Horizontal louver Filter Air outlet Aux.button Display Remote controller For some model: Temp.indicator Wi-Fi indicator For some model: Temp.indicator Wi-Fi indicator NOTE: Actual product may be different from above graphics,please refer to actual products. -
Page 9: Operation Guide
Operation guide Installation batteries 1. Press the back side of remote controller marked with " ", as shown in the fig, and then push out the cover of battery box along the arrow direction. 2. Installation two 7# (AAA 1.5V) dry batteries, and make sure the position of "+"... -
Page 10: Remote Controller
Remote controller Smart function There is no this function for the unit. Set fan speed Battery Quiet function Auto mode Turbo function Cooling mode Dual-8 nixietube Dry mode Fan mode Clock display Heating mode Child lock Health function ECO function Sleep function Light I feel function... -
Page 11: Buttons On Remote Controller
Buttons on remote controller After connecting the power, the air conditioner will make a sound. Power indicator is ON. After that, you can operate the air conditioner by using remote controller. In state of turning on, pressing the button on the remote controller, the air conditioner will make a "beep"... - Page 12 Buttons on remote controller button Press " " or " " button once to increase or decrease 1℃ of temperature. Holding " " or " " button, temperature on remote controller will change quickly. On releasing button after setting is finished, temperature indicator on indoor unit will change accordingly. (Temperature can’t be adjusted under auto mode) When setting TIMER ON, TIMER OFF, press "...
- Page 13 Buttons on remote controller ECO button In cool mode, press this button can turn on or turn off the ECO function. When ECO function is on, " ECO " icon is displayed on remote controller. Note: ● Air conditioner will operate at auto speed. Set temperature can’t be adjusted. ●...
- Page 14 Buttons on remote controller Function introduction for combination buttons Child lock function Press " " and " " simultaneously to turn on or turn off child lock function. When child lock function is on, " " icon is displayed on remote controller. If you operate the remote "...
-
Page 15: Indoor Unit Address Inquiry
Indoor unit address inquiry ● If match with MULTI-S outdoor unit, when units has malfunction and need to inquire the address to maintainance, the step is as below: Remote controller aims to the indoor display, press "Light" and "-" buttons at the same time for 3s , then will display the indoor unit address(1~5) for 3s. - Page 16 Clean and maintenance Clean filter Installation filter Use dust catcher or water to clean the Installtion the filter and then close the filter. when the filter is very dirty, use panel cover tightly. the water (below 45°C) to clean it, and then put it in a shady and cool place to dry.
-
Page 17: Malfunction Analysis
Malfunction analysis General phenomenon analysis Please check below items before asking for maintenance. If the malfunction still can't be eliminated,please contact local dealer or qualified professionals. Phenomenon Check items Solution Whether it's interfered severely Pull out the plug. Reinsert the plug (such as static electricity, stable after about 3min, and then turn on voltage)? - Page 18 Malfunction analysis Phenomenon Check items Solution Because indoor air is cooled rapidly. Mist is emitted Indoor temperature and humidity After a while, indoor temperature and from indoor unit’s is high? humidity will be decrease and mist air outlet. will disappear. Temperature can’t be adjusted under Unit is operating under auto auto mode.
- Page 19 Malfunction analysis Error Code When air conditioner status is abnormal, temperature indicator on indoor unit will blink to dispiay corresponding error code. Please refer to below list for identification of error code. Below listed error codes are only part error codes. Please refero to error code list in serive manual for more information.
-
Page 20: Safety Operation Of Flammable Refrigerant
Safety operation of flammable refrigerant Qualification requirement for installation and maintenance man All the work men who are engaging in the refrigeration system should bear the valid certification awarded by the authoritative organization and the qualificationfor dealing with the refrigeration system recognized by this industry. - Page 21 Safety operation of flammable refrigerant Welding If you should cut or weld the refrigerant system pipes in the process of maintaining, please follow the steps as below: 1. Shut down the unit and cut power supply. 2. Eliminate the refrigerant. 3.
-
Page 22: Installation Drawing
Installation drawing Space to the wall At least 15cm At least 15cm Space to the wall Selection of location Basic requirement Installing the unit in the following places maycause malfunction. If it is unavoidable, please consult the local dealer: 1. The place with strong heat sources,vapors,flammable or explosive gas,or volatile objects spread in the air. -
Page 23: Installation Prepare
Installation prepare Tools 1 Level meter 2 Screw driver 3 Impact drill 4 Drill head 5 Pipe expander 6 Torque wrench 7 Open-end wrench 8 Pipe cutter 9 Leakage detector 10 Vacuum pump 11 Pressure meter 12 Universal meter 13 Inner hexagon spanner 14 Measuring tape Safety precaution 1. - Page 24 Installation prepare Grounding requirement 1. The air conditioner is the first class electric appliance. It must be properly grounding with specialized grounding device by a professional. Please make sure it is always grounded effectively, otherwise it may cause electric shock. 2.
- Page 25 Installation prepare 5. When installing the unit, make sure that connection pipe is securely connected before the compressor starts running. — If compressor starts running when stop valve is open and connection pipe is not yet connected, air will be sucked in and cause pressure rise or compressor rupture, resulting in injury.
-
Page 26: Installation Of Indoor Unit
Installation of indoor unit Step 1: Choosing installation location Recommend the installation location to the client and then confirm it with the client. Step 2: Install wall-mounting frame 1. Hang the wall-mounting frame on the wall; adjust it in horizontal position with the level meter and then point out the screw fixing holes on the wall . - Page 27 Installation of indoor unit 2. Open a piping hole with the diameter of Φ55/Φ70 on the selected outlet pipe position. In order to drain smoothly, slant the piping hole on the wall slightly downward to the outdoor side with the gradient of 5-10°. Note: Indoor Outdoor...
- Page 28 Installation of indoor unit Step 6: Install drain hose 1. Connect the drain hose to the outlet pipe of indoor unit. 2. Bind the joint with tape. drain hose drain hose outlet pipe drain hose outlet pipe tape insulating pipe ●...
- Page 29 Installation of indoor unit Step 8: Bind up pipe 1. Bind up the connection pipe, power cord and drain hose with the band. 2. Reserve a certain length of drain hose and power cord for installation when binding them. When binding to a certain degree, separate the indoor power and then separate the drain hose.
- Page 30 Installation of indoor unit Note: ● The through-wall height of drain hose shouldn't be higher than the outlet pipe hole of indoor unit. ● The water outlet can't be placed in water in order to drain smoothly. The drain hose can't The water outlet can't raise upwards.
-
Page 31: Check After Installation
Check after installation Check according to the following requirement after finishing installation. Items to be checked Possible malfunction Has the unit been installed firmly? The unit may drop, shake or emit noise. Have you done the refrigerant leakage It may cause in sufficient cooling (heating) test? capacity. -
Page 32: Test Operation
Test operation 1. Preparation of test operation ● The client approves the air conditioner. ● Specify the important notes for air conditioner to the client. 2. Method of test operation ● Connect the power, press "ON/OFF" button on the remote controller to start operation. ●...
