Summary of Contents for Procentec ProfiHub F1
- Page 1 ProfiHub F1 User Manual...
-
Page 2: Important Information
This user manual provides information how to work with ProfiHub F1. Recycling and Disposal The parts of the ProfiHub F1 can be recycled. For further information about environment-friendly recycling and the procedure for disposing of your old equipment, please contact:... - Page 3 This product can only function correctly and safely if it is transported, stored, set up, installed, operated and maintained as recommended. ProfiHub F1 is a CE class A product. In a domestic environment it may cause radio interference in which case the user may be required to take adequate measures.
-
Page 4: Table Of Contents
Mounting ..................... 12 Type selection and technical data ............... 13 Other PROCENTEC products ................ 15 10. Sales offices and distributors ............... 17 11. About PROCENTEC ..................22 12. Notes ......................23 ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 4/26... -
Page 5: System Description
System description The interface modules ProfiHub F1 couple PROFIBUS-DP or PROFIBUS-FMS two-wire-segments (RS-485) via op- tical fibres. The module can work as a ring module or work in a Line- or Point-to-point-structure. This can be set by a DIP-switch. They are equipped with two supply voltage inputs to provide redundant power supply. The integrated error relay can be used to indicate malfunctions. -
Page 6: Hardware Installation
Rx : Data being received. A received frame is only shown at the Rx-led of the channel where it arrives first. Thus it can happen that although working in a ring, only one of the Rx-leds lights or both Rx-leds of the ProfiHub F1 are blinking. - Page 7 POF in place. Pay attention on the bending radius of the optical cables while installing them and check the temperature range of the used plugs. ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 7/26...
-
Page 8: Project: Planning A Ring Structure
Constant considering the bit times per km fibre optical cable (see table) Number of ProfiHub F1 in the ring. Constant considering the delay time (in bit times) of one ProfiHub F1 (see table below). Data rate [KBit/s] [Bit times/km] [Bit times] 12.000... -
Page 9: Dimensions
Dimensions ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 9/26... -
Page 10: Connectors And Operation Modes
Connectors and operation modes 6: Channel 1 ON: Fiber port CH1 disabled 5: Channel 2 ON: Fiber port CH2 disabled 4: Mode ON: Ring OFF: Line 1-3: termination ON or OFF ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 10/26... -
Page 11: System Description
A ring topology must be connected from CH1 to CH1 and CH2 to CH2. Only with an uneven number of FO modules, the cables may be connected from CH1 to CH2 and CH2 to CH1 (only once per ring). ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 11/26... -
Page 12: Mounting
As an option, a wall mount kit is also available. If the system should be fixed onto the wall, the clip for DIN rail mount has to be unscrewed first. ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 12/26... -
Page 13: Type Selection And Technical Data
Power supply (green) / Failure (red) / Data receive (green) / Status (red) / Fiber view (red, yellow, green) Operating voltage 12-30 VDC, other voltages on request Current consumption 200 mA Potential separation 500 VDC (24 VDC → RS-485) ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 13/26... - Page 14 EN61000-6-2 (2001) / EN55022 Kl. B (1998) +A1 + A2 Weight 500 g Dimensions H: 115mm W: 61mm D: 113mm H x D x W Case Stainless steel, powder-coated ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 14/26...
-
Page 15: Other Procentec Products
• Bus redundancy option • Star, tree and bus structured networks • Alarm contact • Monitoring port per channel • IP20 • Certifications: UL Listed, DNV, FCC, CE www.procentec.com/profihub ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 15/26... - Page 16 Redundant power supply • Digital glitch filtering • No limit in cascading • Integrated switchable termination • Diagnostic LEDs • DB9 connector for measurements • IP 20 with DIN-rail mounting www.procentec.com/profihub ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 16/26...
-
Page 17: Sales Offices And Distributors
W: www.procentec.net China CZECH REPUBLIC FOXON s.r.o. T: +420 484 845 555 Polní 367 F: +420 484 845 556 460 01 Liberec 12 E: foxon@foxon.cz Czech Republic W: www.foxon.cz ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 17/26... - Page 18 Netanya, 42170 W: www.inst-ic.co.il Israel ITALY PROCENTEC Italy T: +39 030 200 8610 Via Branze n. 43/45 F: +39 030 238 0059 25123 Brescia E: www.procentec.it Italy W: www.procentec.it ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 18/26...
- Page 19 T: +966 2 691 27 41 Al-Zahra Dist. – Attas st. F: +966 2 682 89 43 cross section with helmy Kutby St. E: info@asmestablishment.com Villa no.25 W: www.asmestablishment.com Jeddah-21553 Saudi Arabia ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 19/26...
- Page 20 United Kingdom Hi-Port Controls T: +44 (0)8452 902 030 The Hub 2 Martin Close F: +44 (0)2392 552 880 Lee-on-Solent E: sales@hiport.co.uk Hampshire PO13 8LG W: www.hiport.co.uk United Kingdom ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 20/26...
- Page 21 For the complete list of our Sales Offices and Distributors see www.procentec.com/company/distributors. If your country or region is not listed, please contact us. We are still searching for distributors who can cover complete areas or countries. ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 21/26...
-
Page 22: About Procentec
11. About PROCENTEC PROCENTEC is a specialist in PROFIBUS and PROFINET technology and develops products to optimize the production processes of end users. Our innovative solutions ensure that our customers successfully operate in the world of industrial automation and enjoy maximum results from their process. -
Page 23: Notes
12. Notes ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 23/26... - Page 24 ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 24/26...
- Page 25 ProfiHub F1 User Manual v1.0.1 | September 2018 | ©PROCENTEC 25/26...
- Page 26 PROCENTEC BV Klopperman 16 2292 JD Wateringen The Netherlands T: +31 (0)174 671 800 F: +31 (0)174 671 801 E: support@procentec.com W: www.procentec.com...
