- Page 1 SHIMANO ENGINE MANUAL INSTALLATION VERSION 4.01 E8000 STEP...
-
Page 2: Installation
INSTALLATION Module connection WARNING Unlocking the speed limiter in public places such as roads, squares, bike paths is prohibited by law. Therefore, you can activate unlocking only in private locations such as circuits, slopes, and private properties. Mounting the device may invalidate the bicycle factory warranty. - Page 3 Once removed the protective cap, locate the connector in the foreground among the connector assembly on the right side. Remove it gently, paying attention not to crush or spoil connectors or wires. 3. INSTALLATION...
- Page 4 With a cutter gently remove the pin on the connector just disconnected. Insert the supplied tube into the connector just disconnected. 4. INSTALLATION...
- Page 5 Put one of the two connectors of the eplus on the opposite side of the tube and connect the second connector of the eplus replacing the one that you previously plugged out of the engine. Locate the 2 screws to use the lights and proceed with step 8. 5.
- Page 6 Insert the black cable between the screw with the symbol - and the plate (left), AND the red cable between the screw with the + symbol and the plate (right). Tighten the two screws. If necessary, order the cables, making sure that there are no cables positioned in correspondan- ce of the holes where the screws of the protective cap of the motor pass and reposition it.
- Page 7 E-Tube app). Download the Etube application from Google Play or Play Store: http://e-tubeproject.shimano.com/ and turn on the “lights” function using the app. The activation can also be performed by the Dealer using the Shimano Diagnosis. • Access the menu by holding down the key on the dashboard •...
- Page 8 Choose Customize> transmission unit and switch to On. Press on OFF and save to the bottom right, then exit the application. From this point on, the ‘lights’ menu will be active on the display: it will then be possible to set the lights from the ‘lights’ menu by choosing ACC to activate the unlocker mode of the Eplus.
- Page 9 Use of the Eplus app Available for: Android goo.gl/DehnLE goo.gl/i3uwvL The Eplus app displays: • total km • partial km • maximum and average speed • odometer At the time of the first installation, the Eplus app will ask you to type the number of kilometers traveled in total by the bicycle.
- Page 10 Notes 12 months Warranty . We will respond for manufacturing faults but not for installation defects. Keep away from moisture and heat sources. 10. INSTALLATION...
- Page 11 11. INSTALLATION...
