Veris HD series Installation Manual

HD SerieS

Product IdentIfIcatIon

NIST US or EU
Accuracy Output
HD
1 = 1% N = NIST S = Standard
M = 4-20mA
2 = 2% X = None C = CE
V = 0-5V/0-
3 = 3%
10VDC
5 = 5%

dImensIons

0.7"
(18 mm)
2.9"
(74 mm)
4.6"
(117 mm)
2.0"
(51 mm)
Z203896-0F PAGE 1
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Veris, and the Veris 'V' logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
environmental SenSorS
OPTION
Temp.
Sensor Type
Temp Cert
Q
T = Temp
= 1uA/˚C,
Blank = None
X = No Temp
Linitemp 1 =1pt Cal
(Stop here)
2 = 2pt Cal
Foam Gasket
2.5" x 2.5"
(62 mm x 62 mm)
0.5" Dia.
(13 mm.)
8.5"
(216 mm)
©2009 Veris Industries USA 800.354.8556 or 503.598.4564 / support@veris.com
HD SerieS
Duct Mount Linitemp Sensors
Installer's Specifications
HS Element
Accuracy @ 25ºC*
Reset Rate**
Stability
Hysteresis
Linearity
Operating Humidity Range
Operating Temperature Range
Available
Temperature Coefficient
Analog Output
Scaling
Input Power***
Optional Temperature Transmitter Output
Conformance
* Specified accuracy with 24VDC supplied power with rising humidity.
** Reset Rate is the time required to recover to 50% RH after exposure to 90% RH for 24
hours.
*** One side of transformer secondary is connected to signal common. Isolation trans-
former or dedicated power supply may be required.
RTD Thermistors are not compenstated for internal heating of product
To conform to EMC standards, shielded cabling and technical information is available
from factory upon request or is available on our website: www.veris.com

quIck Install

Observe handling precautions for static sensitive
devices to avoid damage to the circuitry which
would not be covered under the factory warranty.
1. Choose a location on the return air duct.
2. Drill a 7/8" diameter hole for the sensor probe.
3. Mount junction box housing to duct using self-tapping screws (included).
4. Insert probe through black swage fitting into duct. Tighten swage fitting.
5. Wire probe (see Wiring section). Leave wires at factory length to allow for a service
loop (to removed sensor from junction box for service without disturbing the
conduit).
inStallation GUiDe
Digitally profiled thin-film capacitive (32-bit mathematics)
U.S. Patent No. 5,844,138
±1%, ±2%, ±3%, or ±5% respectively@10 to 80% RH%;
Multi-point calibration, NIST traceable
±1% @ 20°C (68°F) annually, for two years
Included in Accuracy spec.
-40° to 50°C (-40° to 122°F)
+0.1% RH/°C above or below 25°C (typical)
4-20mA version: 2-wire, polarity insensitive;
0-5V/0-10V versions: 3-wire, observe polarity
4-20mA version: loop powered 12-30VDC only, 30mA max.;
0-5V/0-10V versions: 12-30VDC/24VDC, 15mA max.
Digital, 4-20mA or 0-5V/0-10V output;
resolution/accuracy ±0.5°C (±1°F) typical
EMC EN 50081-1, EN 50082-1, EN 61000-4-4, EN 61000-4-5,
EN 61000-4-3, ENV 50204, EN 61000-4-6
24 hours
1.5% typical
0 to 100% RH
0–100% RH
02092
