HD WinCNC Manual
This document will provide a quick guide to the set up and operating
procedure of the Techno HD Mini CNC Router and the Techno HD Series CNC
Router with a WinCNC Controller.
The Techno HD Mini CNC Router and the HD CNC Routers are powered by
high precision stepper motors and controlled by a PC with a WinCNC Control
System. Files are transferred from a Cam system via a USB memory stick.
Call: 1-631-648-7481 or Visit: support.technocnc.com
1
