Safety Regulations The printers PP 407 (High Speed Fanfold Printer) and the PP 408 (High Speed Fanfold Printer with Cutter) fulfils the safety regulations according to EN 60950- 1, UL 60950-1 and CAN/CSA 22.2/No. 60950-1 for Information Technology Equipment. The mains cable must be connected to a ground protected wall-socket. The indicated voltage of the printer needs to agree with the local voltage.
We certify that the equipment at issue, • Printer PP 407 (High Speed Fanfold Printer) and • Printer PP 408 (High Speed Fanfold Printer with Cutter) corresponds to the law regulations ruling electromagnetic compatibility of appliances (2004/108/EC) and, therefore, fulfils the requirements for conformity marking with the CE-sign.
Operating Environment Avoid installing the printer where it is exposed to moisture or heat (eg. direct sun light). • Temperature: + 10°C to + 35°C (+50°F to +95°F) • Humidity: 20% to 80% Slots and openings in the printer‘s housing are provided for ventilation. Always ensure that these openings are not obstructed.
Page 6
1. Preface About this Manual This manual is covering the two printers • High Speed Fanfold Printer • High Speed Fanfold Printer with Cutter The operation and functionality are nearly the same. In most illustrations, the High Speed Fanfold Printer with Cutter is used.
Page 7
Appendix Interface Description This chapter gives hints about possibilities to connect the printer to the various computer systems and explains particularities depending on the version of the operating system. Additionally, cable connection is illustrated Print examples of the standard fonts Character Set Tables All printer supported character sets are listed in this chapter D / E Control Codes...
Serial, USB and Parallel etter uality etter uality raft uality The operation of both printers is almost identical. Most of the illustrations show the PP 408 printer. Differences in handling have special references to the printer PP 407 or PP 408. Chapter 1-3...
2. Getting Started Unpacking High Speed Fanfold Printer (Content PP407) Check each item against the check list detailed below. Contact your reseller immediately if any item is missing or damaged. The printer package should contain the following parts: • 24-Needle Printer (1) •...
Page 10
2.1.1 A First Look at the High Speed Fanfold Printer Before installing the printer, spend some time familiarizing yourself with the printer. Top cover (1) Power cord socket (6) Ribbon cassette (2) Control panel (7) Printer base (3) Interface serial, parallel, USB (8) Tractor cassettes (4) Tear off edge (9) Power switch(5)
Page 11
Unpacking High Speed Fanfold Printer with cutter (Content PP408) Check each item against the check list detailed below. Contact your reseller immediately if any item is missing or damaged. The printer package should contain the following parts: • 24-Needle Printer (1) •...
Page 12
2.2.1 A First Look at the High Speed Fanfold Printer with cutter (PP 408) Before installing the printer, spend some time familiarizing yourself with the printer.. Top cover(1) Operator panel (7) Cutting device (2) Interface serial, parallel, USB (8) Printer base (3)
2.3 Site Considerations Environment Conditions • Install the printer in an area away from any heat source, air conditieiner or streing draught. • Avoid installing the printer in a dusty or humid environment. Work Location • Place the printer on the stand or a flat, solid level area such as a desk. •...
Page 14
2.4 Mounting the Cutting Device (only for High Speed Fanfold Printer with Cutter) • Insert the pins (3) of the Cutting Device (2) into the mounting plate (4). • Swivel the Cutting Device (2) to the Printer (1) and push the support plates (5) onto the pins (6). •...
2.5 Transport Lock In delivery condition a red shipping tab is visible under the top cover (1), which is attached with the transport locking clip (2). Lift up the top cover (1) and remove the transport locking clip (2) from the print head drive belt. •...
Page 16
2.6 Installation of the interface (PM) The printer functions only in combination with an installed interface module, called a Personality Module (PM). The illustration below shows the standard PM with a serial, parallel, and USB interface. Note: To avoid damage due to electrostatic discharge, do not touch the pins or compeinents of the PM.
Page 17
2.7 Power supply and power on printer Mains Voltage In general, the main‘s voltage selection is determined at factory sites.Make sure that the specified voltage on the label (1) corresponds to your main‘s voltage: The 230 V setting applies to the range of 180 to 264 V alternating current. Note: Since an incorrect voltage selection can seriously damage the printer, please pay special attention to the following.
Power ON/OFF The power ON/OFF switch (1) turns the printer‘s power supply ON or OFF. After switched ON the printer an internal self-test which checks the electronics, the print head carriage movement and the interface will be performed. At first the yellow LED on the Operator Panel is lighting up and the display shows TEST..0.1 (bootstrap).
2.8 Installing ribbon cassette Hinweis It is recommended to use only original ribbon puts out by our company. Using other ribbons will void your warranty. Caution: Never manually move the print head fully to the right-hand stop (you could change the way of the paper output).
Page 20
8. Then move the cassette towards you until it clicks into place on both sides. Now swivel the ribbon under the print head until the lower retaining pins click (click!) . Note: At each end of the ribbon cassette there are two pins (9) and (10) which keep the cassette in position when mounted.
Page 21
2.9 Replacing the Ribbon Cassette Caution: The print head may be very hot immediately after printing! 1. Close the top cover and power on the Printer. After the display shows READY 1 ELQ, open the top cover. The print head (4) will move to the correct position, aligned with the cut-out in the paper guide plate (5) to facilitate the installation of the ribbon cassette.
2.10 Insert paper The printer has two tractor cassettes (1) for fanfold paper. They are named TRACTOR LOWER and TRACTOR UPPER. The standard setting of the paper source is the TRACTOR LOWER cassette. Ensure that the printer is placed in the depression on the top of the stand (option). If the printer is used without a stand, align the printer with the front edge of the table.
Page 23
or both printers: Insert the paper as shown in the illustration; the top edge of the paper must be equal with the top of the tractors or maximum up to two transport holes above the tractors. The left perforation should be aligned with the centre mark (1) on the plastic plate (6). Paper without vertical perforation should be aligned in such a way that the left holes are positieined to the left of the centre mark (1) on the plastic plate (6).
Page 24
Attention: Only move on tractor base (2) not on flaps (4) iehen (danger of breakage) The paper should be inserted taut, but not overstretched and the transport pins Note: must be in the middle of the transport holes! Chapter 2-16...
2.11 Selection of Operator Panel Language The printer control panel and LCD display menu is used for the next steps. It is possible to change the language in the printer menu from English to French or German. The following example shows how to change from English to German: Attention: The Menu is than displayed in german language.
Page 26
2.12 Print Menu The current status of the printer configuration can be printed out via the menu item „PRINT MENU“ by following steps: Power on printer LOCAL 1ELQ MACRO SELECT ] -- [ PRINT MENU PRINT MENU ...
EXAMPLE OF PRINT MENU MENU PRINTOUT PM 00-013665-0 VERSION 8017556 INTERFACE Adjustment BUFFER 8 KBYTE AGC POSITION WORD LENGHT 8 BIT PLATEN GAP I/F TYPE SHARED PAPER-IN JUST. BAUD RATE 9600 BIT/S TEAROFF ADJ.LO 0 1/60 PARITY EVEN TEAROFF ADJ.LO 0 1/60 PROTOCOL UNI-DIRECT.CMD...
2.13 Test-Printout There are three test prints in the printer. PRINT TEST 1 Shows a pattern of all printable characters. Use this to check if the printer operates correctly. PRINT TEST 12 Sroduces a standard letter (ECMA-132) which can be used for measuring the printer‘s throughput. PRINT TEST 3 Lists all available fonts, contains the page count to identify the actual number of printed pages, and gives information on technical releases which are intended for service purposes.
Page 30
Example Print Test 2 Eilzustellung Norddeutsche Farbwerke KG Herrn Dr. Grauert Große Elbstraße 64 2000 Hamburg 4 Org. III 5/37 4 34 22.04.75 17.04.75 Volkmann Vordruckgestaltung für den allgemEinen Schrift- verkehr, für das Bestell- und Rechnungswesen E i l t Sehr geehrter Herr Dr.
Page 31
Example Print Test 3 CONFIGURATION 20815776 00-013665-0 1500 NLSF TNA1 TNA2 TNA3 2.60 NDLC PGCNT 143299 C031 ISO 8859/1 CO32 ISO 8859/15 CO34 ISO 8859/5 CO32 ISO 8859/9 C061 IBM SET 1 C062 IBM SET 2 C063 IBM CODE PAGE C071 EPSON EXT.
2.14 Connection to a Computer Parallel, Serial, or USB Interface. Switch the printer and computer OFF. Connect the interface cable coming from the computer to the printer‘s parallel (1), serial (2), or USB port (3). The printer is set by default to SHARED (PARALLEL/RS232) interface with the following parameters for serial port: 8 Kbyte buffer 8 bit...
This part of the documentation describes the features of the printer driver for the models PP803, but it is likely the same for PP 407 and PP 408. The printer driver is available for Microsoft Windows NT2000,WIN XP Vista WIN7, WIN8, WIN10,SERVER 2003 and 2008.
Page 34
• choose a printer port -> next • create a new port (example: Standard TCP/IP Port) • put in Data for the port • -> next the system try to detect the TCP/IP port (printer must switched on) • choose Generic Network Card -> next Chapter 2-26...
Page 35
• choose the folder where the driver is placed by „Have a disk“ • Select the * .INF of the unpacked printer driver and open. • open -> OK -> • select the signed printer modell Chapter 2-27...
Page 36
If PSi printer drivers are not yet installed on the PC or server, you will receive a request that you want to trust in the compilation of PSi. Put a tick on “Always trust PSi software” and install it. • Specify whether the printer should be used as the default printer. and finish. You can also print a test page.
Page 37
• Next -> • The printer is now installed Chapter 2-29...
2.17 Change Macro The following emulations are pre defined in the Macros • EPSON LQ / ESC/P2 in Macro 1 • IBM Proprinter XL 24 in Macro 2 • IBM Proprinter XL 24 AGM in Macro 3 • EPSON LQ / ESC/P2 in Macro 4 The factory setting is the EPSON LQ/ESC/P2 emulation in Macro 1.
3. Operation Most of the printer‘s settings can be changed from the control panel or software commands from the host computer. Some functions can only be set via the control panel, eg. B. the locking of the menu access. 3.1 Control Panel The control panel •...
Page 40
3.2 Paper Source Selection The TRACTOR LOWER is the default paper source. Using the control panel to change to the TRACTOR UPPER is explained below: The printer should be in the „Stop“ Mode (LOCAL) = Paper Source Example: Change from „TRACTOR LOWER“ to „TRACTOR UPPER“. Power on printer READY 1ELQ...
3.3 Function Keys The function keys of the operator panel are grouped into two rows. The function of a key depends on the printer operation state. Following operation states are possible: • READY or BUSY • LOCAL 3.3.1 Function Keys in the printer operation state READY or BUSY TASTEN SYMBOL FUNCTION VERT.POS.JUST.
Page 42
3.3.2 Function Keys in the printer operation state OFFLINE TASTEN SYMBOL FUNCTION [FORM FEED] Insert or edject paper, Form Feed [MICRO STEPS] Paper feed, paper return by micro steps START/STOP Key [START/STOP] Switches between Ready and Offline mode MENU Key [MENU] to enter the first level of the menu mode.
Page 43
3.3.3 Detailed description Function keys in ready mode • Quick Setup (Only active if the MENU ACCESS function has not been locked by QUICK OFF - see Appendix A Configuring the Printer). READY 1ELQ MACRO 1 SELECT MACRO 2 SELECT MACRO 3 SELECT MACRO 4...
Page 44
Meaning of Lower Keys on ONLINE (READY or BUSY) state If an application with continuous forms requires special vertical positioning, there are two options for setting in the menu: • Setting vertical positioning with the VERT.POS.JUST. Key • Endless displacement with the Continuous JUST This function allows you to jump directly to the menu mode to adjust the vertical positioning.
Page 45
If pressed key the message Continuous JUST. with condition 0 is displayed, if a printjob is running it will stopped a went into the OFFLINE Mode. By using key the vertical position can be shifted. Taste Anzeige READY 4 ELQ FANFOLD DIS U.
Page 46
page, but no more than 999 steps (42 cm) in total. A pushback is only possible up to the upper edge of the current page. If the required value is found, press key to change in READY or BUSY state. There are the following possibilities: •...
Page 47
3.4 MENU-Mode All operator‘s selectable features are access able via the control panel and combined in the printer MENU This feature provides: • easy handling of configuration (interface, etc.) • quick parameter changes during an application • a SAVE function to make changes permanent (until purposely reset), facilitating changes in default settings.
Page 48
MENU TEXT Changing the values is possible by pressing the key orgo back by keys The following display appears: Now we are in a subfunction. Movement in both directions is possible using the or keys. MENU TEXT In the last step, to select and activate values, you can select with After the selection, an ...
3.4.2 MENU-SAVE If the selection is to be permanent, i. after switching the printer off and on again, this is achieved with the SAVE function. The following steps are necessary for this: Taste Anzeige LOCAL 4 ELQ MACRO SELECT [] -- [] SAVE ...
4. Printer Configuration 4.1 How to Configurate“ This chapter describes how to use the control panel and the menu settings to set or configure the printer so that the printer and the computer can communicate with each other easily. For the printer to communicate with the system, the computer‘s operating system and printer must have the same communication settings or features.
Page 51
4.2 Explanation of the „PRINT OUT“ MENU PRINT OUT PM 00-013665-0 VERSION 8017556 INTERFACE Adjustment BUFFER 8 KBYTE AGC POSITION WORD LENGHT 8 BIT PLATEN GAP I/F TYPE SHARED PAPER-IN JUST. BAUD RATE 9600 BIT/S TEAROFF ADJ.LO 0 1/60 PARITY EVEN TEAROFF ADJ.LO 0 1/60...
Adjustment- Here are the following default settings • AGC POSITION 24 -> indicates the position on which the paper thickness is measured in the line. • PLATEN GAP 0 -> Correction value for the head gap • PAPER-IN ADJ. 0 -> Correction value for Paper-In-Sensor •...
4.4.3 FONT Selectable via MENU / SELECT MACRO CHANGE MACRO FONT SELECTION PARAMETER / VALUE DEFAULT DATA Draft ROMAN LQ / NLQ SANS SERIF LQ / NLQ COURIER LQ / NLQ FONT PRESTIGE LQ / NLQ SCRIPT LQ / NLQ OCR B OCR A...
Page 54
4.4.6 LINE Selectable via MENU/ SELECT MACRO CHANGE MACRO FONT PITCH SELECTION PARAMETER / VALUE DEFAULT 10 CPI 12 CPI 15 CPI PITCH 17 CPI 18 CPI 20 CPI 4.4.7 PITCH Selectable via MENU/ SELECT MACRO CHANGE MACRO FONT LINE SELECTION PARAMETER / VALUE DEFAULT...
Page 55
4.4.10 Adjusting the first print position in the line (left margin) Selectable via MENU/ SELECT MACRO CHANGE MACRO FONT LEFT MARGIN SELECTION PARAMETER / VALUE DEFAULT 1. POSITION LEFT MARGIN (Range 1 to 15; Steps Inch) 4.4.11 Adjust the last print position in the line (right margin) Selectable via MENU/ SELECT MACRO ...
Page 56
PAPER SOURCE • TRACTOR UPPER • TRACTOR L/U 1) werden nur angezeigt, wenn die entsprechenden ASF Kassetten installiert sind 4.4.16 Paper Exit (PP 408 only) Selectable via MENU/ SELECT MACRO CHANGE MACRO FONT PAPER EXIT SELECTION FUNCTION...
4.4.18 CHARACTER SET Selectable via MENU/ SELECT MACRO CHANGE MACRO FONTCHARACTER SET SELECTION CODEPAGES DEFAULT ISO 8859/1 Western European / American ISO 8859/5 Latin / Cyrillic ISO 8859/9 Turkish ISO 8859/15 Western European / American(€) 1: U.S.A. 2: FRANCE 3: GERMANY 4: U.K.
Page 58
1: CP 437 GK 2: CP 851 GK 3: CP 928 GK 4: CP 855 CYRI 5: CP 866 6: CP 869 7: CP 852 CODE PAGE EE 8: KAMENICKY 9: ISO LATIN 2 10: MAZOVIA 11: CP 437 HUN 12: CP 852 SEE 13: CP 866 LAT 14: CP WIN LAT2...
Page 59
• TEAR OFF 10 S. • TEAR OFF 1 S. FF TEAR OFF • TEAR OFF 1 S. • CUT 10 S. • CUT 1 S. • CUT 1S WITHOUT. FF 1) • CUT ON 1 ) Only displayed on PP 408 Chapter 4-10...
4.5 Quick description of the menu items Installation The following tables show the menu and submenus as well as the associated parameters with the possible ON positions. ON star (*) indicates the default setting (factory setting). 4.5.1 Iterface Type (I/F) Selectable via MENU/ SELECT MACRO ...
Page 61
4.5.3 PLATEN GAP Selectable via MENU/ SELECT MACRO INSTALLATION Adjustment PLATEN GAP SELECTION PARAMETER / VALUE DEFAULT PLATEN GAP 0 PLATEN GAP (Bereich. -3 to +4) 4.5.4 AGC adjust Selectable via MENU/ SELECT MACRO INSTALLATION AdjustmentAGC ADJUST SELECTION PARAMETER / VALUE DEFAULT...
Page 62
4.5.7 Undirektional Kommando Selectable via MENU/ SELECT MACRO INSTALLATION Adjustment UNI.DIREKT.BEF SELECTION PARAMETER / VALUE DEFAULT UNI.DIREKT.BEF 4.5.8 TRACTOR Form Feed Mode Selectable via MENU/ SELECT MACRO INSTALLATION Adjustment TRACT. FF-MOD SELECTION PARAMETER / VALUE DEFAULT IGNORE...
Page 64
4.5.14 SELF TEST Selectable via MENU/ SELECT MACRO INSTALLATION INTERFACE SELF TEST SELECTION FUNCTION TEST 1 Printout of all available fonts, current status of the page counter TEST 2 Printout of the standardized letter according to ECMA-132 TEST 3 Print all printable characters (endless must be canceled) 4.5.15 HEX DUMP...
4.5.18 Save Menu Selectable via MENU/ SELECT MACRO INSTALLATION SAVE SELECTION PARAMETER / VALUE EXECUTE SAVE SAVE execute / 4.6 Description of the individual menu items Main function The following main functions are available: • SELF TEST Four test printouts and the HEX-DUMP are available. •...
Each paper source can be assigned a correction factor for the vertical or horizontal paper position. Note: The exact paper specifications can be found in chapter Technical data. PAPER EXIT Tthe following settings are possible (only for PP 408): • PATH and STACK CAPACITY Parameter für PATH: BATCH Standard for continuous paper STACKER for cutted single papers Parameters for STACK CAPACITY.
VERT. POS.ADJ. (vertical offset ) • This function sets the vertical positioning in the current macro for the available paper paths Tractor [LOWER / UPPER]. Tthe following settings are possible • Tract L V O: - 24,0 to 99,9 in steps of 1/6 Inch, •...
LETTER FONT QUAL. Different print quality levels can be selected: • NLQ (Letter Quality). • LQ (Letter Quality). GRAFIK QUAL. Four different levels of graphics quality are selectable: • Standard 180 dots per inch (360 pts horizontal possible) * Mögliche Grafikbeschleunigungen bei Ausgangsauflösung 180 x 180 dpi (Treiber) •...
Page 69
PITCH Denotes the number of printed characters per inch. For all existing fonts, all types of fonts can be set. In some cases, this may conflict with the style of the font The following pitches are available per FONT: • 10 CPI •...
LEFT MARGIN The left edge is set in steps of 1/10 inch. The position of the first left margin is 1/10 inch from the left edge of the paper and shows the left margin of the letter H. The left margin can be set to a maximum of 16/10 inches.
LINE MODE • If LF = LF + CR is set, a carriage return (CR) is also performed for every line feed (LF) received by the interface. • If CR = LF + CR is set, a line feed (LF) is also performed for each carriage return (CR) received from the interface.
• CUT 1S WITHOUT. FF 1) • CUT ON 1 ) Only displayed on PP 408 • If the TEAR OFF 1S or 10S setting is selected, the printer waits for eine second or ten seconds, and if no more data is received, the paper is transported to the first perforation after the text.
4.6.3 INSTALLATION INTERFACE INTERFACE TYP (I/F TYP) The following interfaces are available: • Parallel / RS232 • Parallel / RS422 • Parallel • USB • Shared (all interfaces are activ) • Ethernet (Only in corresponding interface modules / option) With the setting PARALL./RS2 and PARALL./RS422, the respective interfaces are active after switching on the printer.
ADJUSTMENT AGC POSITION � � � AGC ( utomatic ontrol, automatic distance control) is an important function of the printer in terms of paper processing, which allows the use of different paper thicknesses while maintaining the same print quality. The printing gap is set automatically when feeding paper as follows: •...
Cutting edges Setting CUT V-POS CUT V-POS (only displayed in PP 408) (vertical adjustment for the cutting position) A vertical FON adjustment of the cutting position form is possible via the control panel. The parameters for the lower and upper tractor can be changed in the range of - 8/60 „to + 8/60“.
5. Maintenance Preferred Materials The following materials and cleaning lubricants are recommended for use in the maintenance procedure: • Lint-free cloth • Vacuum cleaner. 5.1 Preventive measures The user should clean the printer every six months or after 50,000 prints, whichever occurs first. If you experience paper feed problems, or if the print head carriage movement becomes affected, cleaning should be carried out more often.
Page 78
5.2 Cleaning • Power off prints, • Remove the top cover • Remove ribbon • Thoroughly clean and vacuum all accessible areas to remove scraps of paper and dust • Clean the platen surface, paper pressure rollers, and transport rollers with the platen roller cleaner •...
Remove print head Hinweis: Immediately after printing, the print head can become very hot. • Turn on the printer, open the top cover, and lift it up. • The print head moves to the position opposite the green insertion aid (4) over the oval sheet metal cutout.
Install print head The new print head (DK) is pushed into the holder. Make sure that the printer is switched off. When installing the print head, the carriage should be aligned with the cutout in the paper guide plate (same position as when removing). Hold the print head (1) in its installed position and press it against its stop in the direction of the platen.
Page 81
5.3.2 Change platen A change of the platen roller may become necessary after about 800,000 pages (compare page counter „PGCNT“ in the printer test HW-AUSBAU). Remove platen • Open the top cover and remove it upwards. • Remove the ribbon cassette. •...
Install platen Make sure that the printer is switched off. • Position the platen (1) in its original position. • Pull the printhead (3) from the right to the center. • Insert the geared end of the platen into the right bracket. •...
6. Troubleshooting and diagnostics How to work with this Chapter First, find the category that fits the problem with your printer. The categories are: 1. Problems related to the power supply 2. Error messages 3. No print out 4. Problems with the operation 5.
Page 84
6.2 Error messages 6.2.1 Self-test error After turning on the printer, a self-test will automatically run. In case of an error, one of the following messages appears on the display: SELECTION MEANING CAUSE • Power cord connected? No information • Control unit (CUDEV) POWER ON LED is No Power ..
Page 85
6.2.2 Faults during printing During normal operation, the following error messages may occur: DISPLAY MEANING CAUSE STOP The printer is in STOP mode Press to continue COVER OPEN Top cover is open and the printer is in READY Close the cover and or BUSY mode press to continue Displayed when the host computer issues a...
6.2.3 Technical Error SELECTION MEANING CAUSE • Distance print head to platen faulty • Print head loose AGC ERROR The AGC ADJUST Procedure is faulty • The paten is not installed correctly • No ribbon installed by AGC adjust • Horizontal drive is blocked •...
6.2.4 No Print out Test print out does not start. • Check, that all covers has been closed. • Check, that paper is loaded in the printer. 6.2.5 Printing does not start • Make sure that the READY or BUSY message is displayed. If there is a different message displayed please refer to the above error message table.
Parking paper and resetting top of form Tear off paper on perforation (fold) Press Press until the paper is in the park position. Press Printing will resume at the top of the next form. Print head carriage does not move smoothly/does not move at all •...
Page 89
If the printout or the character set is not ok, the following procedure can help to clear the situation. SELECTION RESULT CHECK • PAPER SOURCE • selection incorrect Select and start Print not OK or partly missing? Ribbon worn or not PRINT TEST 1 installed •...
Page 90
6.3 Process diagrams for troubleshooting 6.3.1 Paper jam TRF Note: Do not turn off the printer in case of a paper jam to avoid data loss. • Lift and remove the top cover. • Grasp the cutter housing (1) (only for High Speed Fanfold Printer with Cutter) on both sides. •...
Page 91
On the Paper Guide (above the platen) is the so-called „D wave“ (1) (the shaft is flattened at the top and has the appearance of a large „D“ in cross section). At the right end of the D-shaft is a green lever (2).
Page 92
6.3.2 Paper jam in TRF Note: Do not turn off the printer in case of a paper jam to avoid data loss. Chapter 6 -10...
7. Technical Data CONTINUOUS PRINTER CONTINUOUS PRINTER w. CUTTER Printing technology SIDM SERIAL Impact Dot Matrix Technologie Paper path Flatbed technology 24 needles, needle diameter 0.25 mm, life time Over 400 million Print head characters, equivalent to about 350,000 pages (DIN standard letter). Data, Roman, San Serif, Courier, Prestige, Script, OCR B, OCR A, Orator-C, Orator, DATA LARGE;...
Page 96
CONTINUOUS PRINTER CONTINUOUS PRINTER w. CUTTER Code 39, 2 aus 5 industrial, 2 of 5 interleaved, Codabar (Monarch), EAN 8, EAN 13, Code 39, Code 93, MSI Mod 10/10, Barcode UPC-E, UPC-A, Code 128 (inkl.EAN 128), Postnet and and KIX code all in horizontal and vertical position (see Appendix F Barcode Quick Reference) Uni-/bi-directional (selectable) Graphic...
Page 97
CONTINUOUS PRINTER CONTINUOUS PRINTER w. CUTTER Ambient temperature • operating +10°C to +35°C • storage - 40°C to +70°C Relative humidity 20% to 80% • operating 5% to 85% • storage # 55 dB (A) according to ISO 7779 Noice level (Sound pressure level 1 meter away from the housing) Mean failure distance 10,000 hours at 25% duty cycle...
Page 98
Appendix A System Interface Description • Serial interface with RS-232C or RS-422 support • Parallel Centronics interface. • USB The interfaces can be operated in different modes: parallel interface active parallel interface active in shared mode with serial RS-232C / USB /ETH parallel interface active in shared mode with serial RS-422 The following chapter gives an overview about interface characteristics, control signals, protocols, and cabling.
Page 99
A 1 Serial Interface RS-232C / RS-422 A 1.1 Interface Characteristics Signal Description RS-232C Pin No. Direction Protective Ground Transmit Data (from printer to host) OUTPUT RXD Receive Data (from host to printer) INPUT Request to Send (printer is requesting data transfer from OUTPUT host) INPUT...
A1.2 Serial Interface with RS-232C Transmission Protocols: • DTR - Ready/Busy (only RS-232C) • XON/XOFF • XON/XOFF + DTR (only RS-232C) Transmission Protocols and Connection Diagrams DTR - Ready/Busy (Supported RS-232C Protocols) - Full Duplex Local Connection This protocol uses the following signal lines: Protective Ground (PG) Transmit Data (TXD) Receive Data (RXD)
Page 101
Additional Information After Power-ON DTR is activated and the printer is ready to receive data. DTR is deactivated when the interface buffer has only space left for 256 more characters. Fürther incoming data will be stored until the interface buffer is full. All data sent in addition will get lost. DTR is activated again if there is a free interface buffer space of 512 characters.
Page 102
Additional Information After Power-ON DTR and RTS are activated and the printer is ready to receive data. XOFF is sent, when the interface buffer has only space left for 256 more characters. XOFF is sent again, at a level of 128 characters buffer space. Fürther incoming data will be stored until the interface buffer is full.
Page 103
A 2 Parallel Centronics® Interface A 2.1 Interface Characteristics - Connector Pin Assignment / Signal Definition Return line Signal Description Pin No. Direction Pin No. Control Signal from the Host. Printer reads data Input STROBE **) line (Data 1 to Data 8) when going low. Data lines transfer the characters from the host to Data 1 - 8 2 - 9...
Page 104
IEEE Std 1284 Nibble mode including Device ID are supported. The maximum throughput for data transfer is 42,000 characters per second. Transmission Protocol After Power-ON the PE (Paper Empty) signal is set to low level and the SELECT and the FAULT are set to high level.
USB INTERFACE • Reference standard: Universal Serial Bus • Transmissions speed: 12 Mbps • USB-Connector: Type B • USB 2.0 compatible Shared Mode In shared operation the interface buffer capacity is reduced by 256 bytes. • After Power-ON both the serial and the parallel interfaces are available for data transfer. •...
ETHERNET INTERFACES There are 2 Ethernet Interface available: • 8707-241-90102 PM SER/USB/ETH PP40x Ethernet Interface MultiPROTOCOL with USB and Serial Connection • 8707-241-90119 PM SER/PAR/USB/ETH PP40x (PNS) Ethernet Interface TCP/LPR only with USB, Parallel and Serial Connection 8707-241-90102 PM SER/USB/ETH PP40x •...
Appendix B Resident Fonts (nur in englischer Sprache) The Printer with the Personality Module (PM SER/PAR) provides the following resident fonts: Appendix B-1...
Page 116
Code Table ISO 8859-9 ° À Ǧ à ğ ¡ ± Á Ñ á ñ ¢ ² Â Ò â ò £ ³ Ã Ó ã ó ¤ Ä Ô ä ô ¥ µ Å Õ å õ & ¦ ¶...
Page 117
C 2. IBM Code Pages Code Table IBM All Character Set ° À Ǧ à ğ ¡ ± Á Ñ á ñ ¢ ² Â Ò â ò £ ³ Ã Ó ã ó ¤ Ä Ô ä ô ¥ µ...
Page 118
Code Table IBM SET 1 National Version = USA 0 NUL ░ ╨ p NUL á └ α ≡ ▒ ┴ ╤ í β ± ▓ ┬ ╥ ʺ DC2 ó Γ ≥ ├ ╙ DC3 ú │ π ≤ ┤...
Page 119
Code Table IBM SET 1 National Versions Character Code (Hex) 1: USA 2: FRANCE à ̊ ç § é ù è ¨ 3: GERMANY § Ä Ö Ü ä ö ü ß 4: U.K. £ 5: DENMARK Æ Ø Å æ...
Page 120
Code Table IBM SET 2 National Version = USA 0 NUL ░ ╨ Ç É á └ α ≡ ▒ ┴ ╤ ü æ í β ± ▓ ┬ ╥ ʺ é Æ ó Γ ≥ ♥ DC3 ├ ╙ â...
Page 121
Code Table IBM SET 2 National Versions Character Code (Hex) 5C 5D 7C 7D 9B 9D 1: USA ¢ ¥ 2: FRANCE à ̊ ç § é ù è ¨ ¢ ¥ 3: GERMANY § Ä Ö Ü ä ö ü...
Appendix D IBM ProPrinter Quick Reference (TM) his appendix contains basic information on the IBM ProPrinter XL 24 Emulation commands supported in the Printer: IBM and Proprinter is a registered trademark of International Business Machines Corporation. Characters used in control functions appear in monospaced type. Table 1 explains some of the conventions used.
Page 160
Table 2: Control Codes Column/Row Mnemonic Function Null Backspace Horizontal Tab Line Feed Vertical Tab Form Feed Carriage Return Double Width Printing By Line Condensed Printing (17.1 cpi) Select Printer Select Pica (10 cpi) Buffer Data Flow Control Cancel Double Width Printing By Line Cancel Buffer Initiate Escape Sequence Space...
Page 161
Table 3: Vertical Form Handling Vertical Form Handling The printer is always equipped with two continuous form tractors. The last sheet of a continuous form stack can be printed on up to the end of the form. The capabillity of the printer to feed paper from different sources is optimally supplemented by the option that automatically adjust the distance between the print head and the print ba Escape Sequence Mnemonic Function...
Page 162
ESC [ > ;;;P4 s P4 = 1 : Cut Mode On (Native Command) P4 = 2 : Cut on actual position (cutting edge is approximate 4 mm above PP 408 only the base of the actual line Appendix D-4...
Page 165
Escape Sequence Mnemonic Function Select Print Quality LQ / NLQ P1 = 0 : LQ P1 = 1 : NLQ; this is only valid if the NLQ type style is available. ESC [ P1 SP r P1 = 2 : Draft P1 = 3 : HSD (High Speed Draft) (Native Command) Note: The LQ / NLQ selection becomes...
Page 166
Table 5: Character Set Selection Escape Sequence Mnemonic Function ESC 6 Select Character Set 2 ESC 7 Select Character Set 1 Print from All Character Set ESC \ P1 P2 Number of codes = (P1 + P2 * 256) (Pn = 0/0...F/F) Print Single Character from All Character ESC ^ P1 P1 = Number of Char.
Page 167
Escape Sequence Mnemonic Function Double Density Graphics Mode *) ESC L P1 P2 v1 . . . vn (P1 + P2 * 256) = number of data (Pn = 0/0...F/F) Double Speed & Density Graphics Mode *) ESC Y P1 P2 v1 . . . vn (P1 + P2 * 256) = number of data (Pn = 0/0...F/F) Quadruple Density Graphics Mode *)
Page 168
Table 7: Further Control Sequences, supported by IBM Emulation Mode (Native Commands) Escape Sequence Alternative Function Control String Introducer (CSI) for” ESC [ ESC [ HEX 1B 5B Control String Introducer (ESC) for “ESC“ HEX 1B Select Various Graphics Modes P2 + P3 * 256 = number of columns ESC * P1 P2 P3 v1 .
Page 169
Escape Sequence Alternative Function Set National Version and Code Table P1 = 1 - 15 national version depending on selected character set (see Appendix C Char. Set Tables) P2 = 3 digit code of the code table (see command SCT) P1 for national version IBM SET 2: P1 = 1 : U.S.A...
Page 170
Escape Sequence Alternative Function P1 for CODE PAGE EE: (continou) P1 = 8 : KAMENICKY P1 = 9 : ISO LATIN 2 P1 = 1 0 : MAZOVIA P1 = 1 1 : CP 437 HUN P1 = 1 2 : CP 852 SEE P1 = 1 3 : CP 866 LAT ESC [ESC [ P1 ;...
Page 172
Escape Sequence Alternative Function Set Graphic Rendition P1 = 0 : default - no rendition or rendition reset P1 = 1 : bold P1 = 3 : italics P1 = 4 : underline P1 = 9 : crossed out or strike through printing ESC [ P1 m P1 = 20 : enlarged double width printing...
Page 173
Hex Code Format Page Null Backspace Horizontal Tab Line Feed Vertical Tab Form Feed Carriage Return Select Double Width (one line) Select Condensed Mode (17,1 cpi) Select Printer Select Pica (10 cpi) Buffer Data Flow Control Cancel Double Width Cancel Buffer Escape Space Delete...
Page 174
Hex Code Format Page 1B 33 P1 Set Line Space to P1/216" (P1/180") 1B 35 01 / 1B 35 00 Carriage Return Function 1B 41 P1 Set Line Space to P1/72" (P1/60") 1B 43 P1 Set Form Length in Lines 1B 49 P1 Select Character Mode 1B 4A P1...
Page 175
Hex Code Format Page 1B 5B P1 3B P2 77 Set National Version and Code Table D-12 1B 5B P1 3B P2 78 Select Font and Character Pitch 1B 5B P1 60 Set Horizontal Position Absolute D-13 1B 5B P1 61 Set Horizontal Position Relative D-13 1B 5B P1 62...
Page 177
Appendix E EPSON LQ ® Quick Reference EPSON LQ 2550 and ESC/P Emulation EPSON® is a registered trademark and EPSON Perfection ™ and Exceed Your Vision are trademarks of Seiko Epson Corporation This appendix contains basic information on the EPSON LQ 2550, ESC/P2, and EPSON Barcodes Printer Emulation: Characters used in control functions appear in monospaced type.
Page 178
Table 2: Control Codes Column/Row Mnemonic Function Null Backspace Horizontal Tab Line Feed Vertical Tab Form Feed Carriage Return Double Width Printing By Line Condensed Printing (17.1 cpi) Select Printer Select Pica (10 cpi) Deselct Printer Cancel Double Width Printing By Line Cancel Buffer Initiate Escape Sequence Space...
Page 179
Vertical Form Handling The printer is always equipped with two continuous form tractors. The last sheet of a continuous form stack can be printed on up to the end of the form. The capabillity of the printer to feed paper from different sources is optimally supplemented by the option that automatically adjust the distance between the print head and the print bar.
Page 180
ESC [ > ;;;P4 s P4 = 1 : Cut Mode On (Native Command) P4 = 2 : Cut on actual position (cutting edge is approximate 4 mm above PP 408 only the base of the actual line Appendix E-4...
Page 181
Table 5: Horizontal Form Handling and Printing Modes Escape Sequenz Mnemonic Function ESC SO Select Double Width for One Line Select Condensed 10 cpi -> 17 cpi ESC SI 12 cpi -> 20 cpi 15 cpi -> 15 cpi (unchanged) proportional ->...
Page 185
Escape Sequenz Mnemonic Function Select Font and Character Pitch ESC [ P1 ; P2 x (parameter P1 or P2 may be skipped, see (Native Command) following alternative command sequences) P1 Selects Font P1 = 0 or missing : Font is unchanged P1 = 1 : Data P1 = 2...
Page 186
Escape Sequenz Mnemonic Function ESC K P2 P3 v1 . . . vn Standard Density Graphics Mode ESC L P2 P3 v1 . . . vn Double Density Graphics Mode Double Density / Double Speed Graphics ESC Y P2 P3 v1 . . . vn Mode ESC Z P2 P3 v1 .
Page 187
Table 7: Character Set Selection Escape Sequenz Mnemonic Function ESC 6 Enlarge Print Code Area (128-159 dec.) ESC 7 Enable Upper Control Code (128-159 dec.) Select National Version P1 = 0/0 : U.S.A. P1 = 0/1 : FRANCE P1 = 0/2 : GERMANY P1 = 0/3 : U.K.
Page 188
Escape Sequenz Function Set relative vertical print position Define relative vertical print position in units ESC ( v P1 P2 P3 P1 = 02 00 rvpp = P2 + P3 x 256 rvpp: moves the print position in defined units. Select font by pitch and point P1 = 0 : No change in pitch P1 = 1 : Selects proportional spacing...
Page 189
Escape Sequenz Function Select character table Selects the character table to be used for printing from among the four character tables which are assigned by ESC ( t command. Pn = 0/0 or 3/0 : Character Table 0 Pn = 0/1 or 3/1 : Character Table 1 Pn = 0/2 or 3/2 : Character Table 2 ESC t P1 Re-maps downloaded Characters from the positions...
Page 190
Table 9: EPSON Barcodes Commands Escape Sequenz Function Specify and Print barcode P1 P2 number of data bytes to follow: 6 bytes + number of BarCodeData = P1 + P2 x 256 k specifies the barcode type: k = 0/2 Interleaved 2 of 5 k = 0/5 Code 39 k = 06 Code 128 m specifies the module width (unit 1/180 inch)
Page 191
Table 10: Further Control Sequences, supported by EPSON LQ Emulation Mode (Native Commands) Escape Sequence Alternative Function Set National Version and Code Table P1 = 1 - 15 national version depending on selected character set (see Appendix C Char. Set Tables) P2 = 3 digit code of the code table (see command SCT) P1 for national version IBM SET 2:...
Page 192
Escape Sequence Alternative Function P1 for CODE PAGE EE: (continou) P1 = 8 : KAMENICKY P1 = 9 : ISO LATIN 2 P1 = 1 0 : MAZOVIA P1 = 1 1 : CP 437 HUN P1 = 1 2 : CP 852 SEE P1 = 1 3 : CP 866 LAT ESC [ESC [ P1 ;...
Page 197
Hex Code Format Page 1B 61 P Select Justification 1B 6A P Perform Reverse Line Feed 1B 6B P Select Font 1B 6C P Set Left Margin 1B 70 00 1B 70 01 Cancel / Select Proportional 1B 71 P Select Character Style 1B 74 P Select Character Table...
Page 198
Hex Code Format Page 1B 44 P ...P Set Horizontal Tabs 1B 4B P data Standard Density Graphics Mode E-13 1B 4C P data Double Density Graphics Mode E-13 1B 58 P Select Font by Pitch and Point E-13 Double Speed & Double Density Graph. 1B 59 P data E-13...
Appendix F Barcode Quick Reference Introduction The barcode print facility is available in all three emulations. Programming There are three escape sequences to print barcodes The first sequence is to define the Barcode Header. The type of barcode as well as all parameters are selected by a header.
Barcode Header Format Function/Parameter Hex Code Barcode Header P 2 = Barcode type; P 3 = Height of barcode; 1B 5B 3B P 2 3B P 3 3B P 4 3B P 5 3B P 6 3B P 7 20 7A P 4 = Width of thin bars;...
horizontal + vertical + human Type horizontal human readable vertical readable text text MSI Mod 10/10 UPC-E not applicable not applicable UPC-A not applicable not applicable Code 128 (EAN 128) Postnet not applicable not applicable not applicable KIX RM4SCC, U.K. not applicable not applicable not applicable...
Barcode Width (Thin bars) Parameter Description Function • default: = 0.35 mm Width of the thin bars Note: The width of bars and gaps should be equal. For this, the parameters P4 and P5 should not deviate more than one step for horizontal Barcode inch 2/144...
Page 204
Barcode Width (Thin gaps) Parameter Description Function • default: = 0.35 mm Width of the thin gaps Note: The width of bars and gaps should be equal. For this, the parameters P4 and P5 should not deviate more than one step for horizontal Barcode inch 2/144...
Barcode Ratio Width to Thin Parameter Description Function • default: 0 (2 to 1)) Ratio Width to Thin Code 39 2 of 5 industrial EAN 8 2 of 5 interleaved EAN 13 Codabar UPC-A Code 93 UPC-E MSI mod 10/10 Code 128 2.0 to 1 2.5 to 1...
Barcode Programming Examples Note: All examples are coded in standard uni-directional printing - that means the parameter “P7” is not used. In the following examples, stands for “Space”. print position. The red square before and after the printed barcode indicates the actual print position. Between Start Barcode and Stop Barcode are only printable characters tolerated (no CR or LF).
Page 207
Barcode Example for 2 of 5 industriel (with redable Text) Barcode Header: ESC[ ; P2 ; P3 ; P4 ;P5 ; P6 ;P7 ˽ z ASCII ESC[ ; 202 ;8 ;1 ; 1; 1 ; ˽ z 1B 5B 3B 32 30 32 3B 38 3B 31 3B 31 3B 31 3B 20 7A Start Barcode: ASCII ESC [ ? 0 h 1B 5B 3E 30 68...
