- Page 1 SELF-PRIMING ELECTRIC PUMP FOR TRANSFERRING VARIOUS LIQUIDS INSTRUCTIONS FOR USE 162 001 1B - UP1/AC 110 V © S.p.A.
-
Page 3: Product Description
TECHNICAL DETAILS CODE TYPE FLOW RATE PRESSURE VOLT FUSE WEIGHT P .CS x CART. 162 001 1B UP1/AC 9,5 gpm 15 psi 18,7 lb AMBIENT CONDITIONS TEMPERATURE: min.-10°C 14°F-max.60°C 140°F RELATIVE HUMIDITY: max. 90 % WARNING: the above indicated temperature ranges are applicable to all components of the pump and these limits must be respected in order to avoid any possible damage or malfunctioning. -
Page 4: Transportation And Handling
FLUIDS ALLOWED / NOT ALLOWED ALLOWED: FRESH WATER AND SEA WATER WATER CONTAINING GLYCOLS NOT ALLOWED: RELATED DANGERS PETROL (GASOLINE) FIRE EXPLOSION FIRE EXPLOSION FLAMMABLE LIQUIDS with PM < 55°C MOTOR OVERHEATING LIQUIDS WITH VISCOSITY > 20 cSt FOODSTUFF LIQUID CONTAMINATION FOODSTUFF LIQUIDS PUMP CORROSION - CORROSIVE CHEMICAL PRODUCTS... -
Page 5: Tubing Connections
WARNING: THE MOTOR IS NOT EXPLOSION PROOF. Do not install the pump where flammable vapours or gases may be present. Install it in an accessible place for inspection. The pump is IP55 protection rated. It is good practice to avoid any pump contact with water splashes possibly causing water seepage into the motor with high risk of internal oxidation and/or short circuit. -
Page 6: Troubleshooting
WARNING: it is the responsibility of the installation technician to ensure a a correctly designed circuit installation fitted according to regulations. Environmental risks must be taken into account with the installation. TROUBLESHOOTING CHECK POINTS IF THE PUMP HAS STOPPED OR WILL NOT START? - Check the effectiveness of the battery power supply (voltage activity) - Check if the fuse has blown - Check for any foreign matter present in the pump impeller. -
Page 7: Normal Maintenance
5) The Warranty does not cover any related installation costs involved. 6) Transport costs are refundable only in the case where warranty has been duly recognized and accepted by Marco Spa. These costs will be limited to the actual shipment costs between Marco Spa warehouse and the client's delivery address. -
Page 8: Exploded View
EXPLODED VIEW Art. Art. Description Q.ty Q.ty Description MOTOR SEEGER PUMP BODY JOINT HEADLESS SCREW RUBBER LIP SEAL FLANGE IMPELLER SCREW O-RING SCREW TOP PLATE BALL BEARING SCREW SHAFT © S.p.A. - Page 9 DIMENSIONS 27,5 © S.p.A.
-
Page 10: Declaration Of Conformity
E.C. DECLARATION OF CONFORMITY We confirm that the product: 162 001 1B - UP1/AC 110V Flexible impeller pump Is in conformity with 73/23/EC Directive relating to Low Voltage and with 2004/108/EC Directive relating to the Electromagnetic Compatibility This declaration is valid for all products which are produced in accordance with the technical documentation which is a part of this declaration. - Page 11 NOTES...
