Psion Teklogix 7535 Quick Start Manual

Hide thumbs Also See for 7535:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
7535
Hand-Held Computer
Quick Start Guide
January 12, 2006
PN 8000011.C
ISO 9001 Certified
Quality Management System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7535 and is the answer not in the manual?

Questions and answers

Related Manuals for Psion Teklogix 7535

Summary of Contents for Psion Teklogix 7535

  • Page 1 7535 Hand-Held Computer Quick Start Guide January 12, 2006 PN 8000011.C ISO 9001 Certified Quality Management System...
  • Page 2 Psion Teklogix manufactured goods and services. Furthermore, this docu- ment is not to be used as a basis for design, manufacture, or sub-contract, or in any manner detrimental to the interests of Psion Teklogix Inc. All trademarks are the property of their respective holders.
  • Page 3 Psion Teklogix products at no charge to you.) In some regions, this warranty may exceed this period. Please contact your local Psion Teklogix office for details. For a list of offices, refer to “Support Services & Worldwide Offices” on page 60. The warranty on...
  • Page 4 This Product, and its accessories, comply with the requirements of the Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC. If your end-of-life Psion Teklogix product or accessory was first placed on the Euro- pean Union market on or after August 13 , 2005, contact your local country representative for details on how to arrange recycling.

  • Page 5: Table Of Contents

    2. Getting To Know Your 7535 ......27 2.1 7535 Features ....... . 27 2.2 The Battery .
  • Page 6 2.4.3 Calibrating The Touchscreen ....37 2.5 7535 Indicators ....... 38 2.5.1 LEDs.

  • Page 7: Approvals

    Year of Manufacture: 2003 Standard(s) to which Conformity is Declared: The 7535 Hand Held Micro-computer with Portable Docking Module, supplied by Psion Teklogix, has been tested and found to comply with FCC PART 15, SUBPART B - UNINTENTIONAL RADIATORS, CLASS B COMPUTING DEVICES FOR HOME &...

  • Page 8: Safety Summary

    1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Psion Teklogix, the party responsible for compliance, may void the user’s authority to operate the equipment.
  • Page 9 Keep a minimum distance of 20 cm between the device and the product to reduce the risk of interference. If you have any reason to suspect that interference is taking place, turn off the 7535 and con- tact your cardiologist for assistance.
  • Page 10 EN 60825-1: 2001, and is classified as a Class 2 laser product. The SE1200 ALR has an maximum radiated power less than 1.4 mW; according to EN 60825-1: 2001 it is classified as a Class 3B laser product. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 11: Program License Agreements

    Do not operate the equipment without the covers and enclosures properly installed. Caution! Danger of explosion if a 7535 battery is incorrectly handled, charged, disposed of or replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the instructions described in “The...
  • Page 12 NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLERANT. PSION TEKLOGIX INC. HAS INDEPENDENTLY DETERMINED HOW TO USE THE SOFTWARE IN THE DEVICE, AND MS HAS RELIED UPON PSION TEKLOGIX INC. TO CONDUCT SUFFICIENT TESTING TO DETERMINE THAT THE SOFTWARE IS SUITABLE FOR SUCH USE.
  • Page 13 IMPORTANT – READ CAREFULLY: This License Agreement (“Agreement”) is a legal agreement between you and Psion Teklogix (“we”), the licensor of Psion Teklogix software (“Soft- ware”), for your use of the Software only as authorized in this Agreement. By clicking on the “Accept” or other appropriate assent button and/or install- ing the Software, you agree to be and are hereby bound by the terms and con- ditions of this Agreement.
  • Page 14 Software, and you may not install or use the Soft- ware or any accompanying documentation. The Software is the property of Psion Teklogix Inc. or its licensors and is pro- tected by copyright laws and international copyright treaties, as well as other intellectual property laws and treaties.
  • Page 15 We do not warrant uninterrupted or error free operation of the Software nor do we warrant that the Software will meet your requirements. THE SOFT- WARE IS PROVIDED “AS-IS” WITHOUT ANY WARRANTY WHAT- SOEVER AND WITHOUT ANY TECHNICAL SUPPORT OF ANY Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 16 6. COPYRIGHTS, OWNERSHIP AND PROPRIETARY RIGHTS All title and copyrights in and to the Software, and any copies thereof, are owned by Psion Teklogix Inc. or its suppliers. The Software also contains copyrighted material licensed from our suppliers and all rights to such copy- righted material rests with such suppliers.
  • Page 17 You acknowledge that you have read this Agreement, understand it, and that it is the complete agreement between you and Psion Teklogix with respect to the subject matter hereof and supersedes all prior agreements, oral or written.
  • Page 18 The shareware version of the Software may be distributed freely without any associated fees to other parties who wish to try the software as long as the Software is distributed within an exact copy of the original MDC Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 19 (“High Risk Activities”). Accordingly, MDC and its suppliers specifically disclaim any express or implied warranty of fitness for High Risk Activities. You agree that MDC and its suppliers will not be liable Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 20 You may not use or otherwise export or reexport the Software except as authorized by United States law and the laws of the jurisdiction in which the Software was obtained. In particular, but without limitation, the Software Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 21 The Software is provided “AS IS” and without warranty of any kind and MDC and MDC’s licensor(s) (for the purposes of warranty and liability, MDC and MDC's licensor(s) shall be collectively referred to as “MDC”) EXPRESSLY DISCLAIM ALL WARRANTIES AND/OR CONDITIONS, Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 22 UNDER NO CIRCUMSTANCES, EXCEPT TO THE EXTENT PROHIB- ITED BY LOCAL LAW, INCLUDING NEGLIGENCE, SHALL LICEN- SOR, ITS SUBSIDIARIES, AFFILIATES, OR SUPPLIERS BE LIABLE FOR ANY DIRECT, INCIDENTAL, SPECIAL, INDIRECT OR CONSE- Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 23 OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/). This product includes crypto- graphic software written by Eric Young (eay@cryptsoft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com). Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 24 IFY, AND ARE IN ADDITION TO, THE MANDATORY STATU- TORY RIGHTS APPLICABLE TO THE LICENSE OF THE SOFTWARE TO YOU. Meetinghouse Data Communications, Inc. 150 Greenleaf Avenue, Unit F Portsmouth, NH 03801 Revised 8/12/2002 Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 25: Basic Preparation

    Typically, 7535 hand-helds are configured at the factory and arrive ready for use. Although the 7535 is equipped with an internal Com- pact Flash and SD I/O slot, these slots are not intended for user mod- ification.
  • Page 26 • Use a Phillips screwdriver to attach the strap to the two threaded inserts at the back of the 7535 at the top of the unit. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 27: Attaching A Pistol Grip

    1.3 Attaching A Pistol Grip The pistol grip is attached to the back of the 7535 using the four threaded inserts in the upper part of the 7535 casing. Four black #4- 40 Phillips head screws are provided with this accessory.
  • Page 28 • Position the pistol grip so that it fits snugly over the back of the unit and the inserts on the back of the 7535 align with the holes in the pistol grip. • Use a Phillips screwdriver to securely fasten the pistol grip to the back of the 7535.

  • Page 29: Installing The Battery

    Microsoft® Windows® CE. net logo appears followed by the startup desktop. Note: If the 7535 is in suspend state, pressing <ENTER/ON> ‘wakes’ the unit from this state. The screen in which you were working before the computer entered suspend state is dis- played.

  • Page 30: Switching The 7535 Off

    <BLUE> key is locked on. 1.7 Connecting To An 802.11 Network In most cases, the 7535 must be configured before it can connect to an 802.11 wireless network. Chapter 2, Section 2.2.2, “Configuring An IEEE 802.11 Radio Installed In The 7535” in the “7535 Hand- Held Computer User Manual”...

  • Page 31: Getting To Know Your 7535

    2. Getting To Know Your 7535 2.1 7535 Features 7535 Screen Sound Port Ambient Light Sensor Tether Port Docking Port Scanner Window Stylus (Pointing Tool) Battery Pack Tether Port Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 32: The Battery

    2.2 The Battery The 7535 hand-held operates with a Lithium-Ion battery pack. Preparing the hand-held unit for operation requires that a battery pack be charged and installed in the unit. Important: Before charging or using the battery pack, it is criti- cal that the safety information in this section be reviewed and that all warnings are strictly followed.
  • Page 33 • Do not store the battery in extremely high temperatures (e.g., a vehicle, strong direct sunlight, etc.). This may cause the battery to overheat or ignite, and it may also reduce the performance and service life of the battery. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 34: Battery Swap And Runtime

    A full charge is completed in 4 hours with a typi- cal charge time of 1.5 hours. Always switch the unit off before changing the battery. While the battery is being replaced, the 7535 will save its current data for at least 10 minutes. 2.3 The Keyboard The 7535 offers two types of keyboard layouts –...

  • Page 35: The Keys

    When a modifier key is pressed once, it is displayed in lowercase let- ters in the taskbar at the bottom of the 7535 screen. For example, if the <CTRL> key is pressed, ctrl key is displayed at the bottom of the unit screen.

  • Page 36: The 58-Key Keyboard

    In addition to alphanumeric keys that are directly accessible on the keyboard (no key combination is required) and the keys described in this chapter, the 58-key keyboard also provides function keys and macro keys. They can be custom defined for each application. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 37: The 36-Key Keyboard

    • Press the <ORANGE> key again to unlock or turn it off. Creating Uppercase Letters To display a capital letter: • Press the <ORANGE> key and then the <SHIFT> key before typing the alpha character. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 38 • If you do not want to choose any additional alpha characters, press <ORANGE> again to unlock or turn ‘off’ the key and end alpha selection. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 39: Adjusting The Keypad Backlight

    To adjust the intensity of the keypad backlight and the conditions under which this backlight is activated • In the Windows CE Control Panel, choose the Keyboard icon Note: Access may be restricted to supervisory use. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 40: The Display

    The contrast can also be adjusted to further improve character visibility. 2.4.1 Adjusting The Display Backlight • In the Windows CE Control Panel, choose the Display icon and select the ‘Backlight’ tab. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 41: Adjusting The Contrast

    2.4.3 Calibrating The Touchscreen Note: This function may be restricted to supervisory use. If your 7535 touchscreen has never been calibrated or if you find that the stylus pointer is not accurate when you tap on an item: Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 42: 7535 Indicators

    7535s use LEDs (Light Emitting Diode), onscreen messages and audio tones as indicators. 2.5.1 LEDs The 7535 is equipped with four tri-coloured LEDs. This section out- lines what these LEDs indicate. Important: If an LED is illuminated in red, the operator should be cautious as this generally indicates an abnormal operating condition or active laser emission.
  • Page 43 User Application Scanner Charge Charge LED The lower-right LED is reserved for internal charger/power status. and is active even when the 7535 is inserted in a docking station (and in suspend mode). Function Charge LED Behaviour External power not available.

  • Page 44: Onscreen Indicators

    Radio Traffic LED The upper-left LED on your 7535 flashes either orange (transmit) or green (receive). Note: Keep in mind that while the standard 802.11b radio supports the transmit/receive LED, not all radios support this function. Scan LED Successful scans are indicated in two ways – with a scan LED and with an audio tone.
  • Page 45 The taskbar changes dynamically, and only those icons that are applicable are displayed. For example, if a radio is not installed in your 7535, the radio signal icon is not displayed in the taskbar. Windows® Start Button If you have a touchscreen, you can display the Start Menu by tapping on the Windows®...
  • Page 46 – a warning window pops up. When the battery power is completely depleted, a final warning window indicates that the 7535 will be powered down. If the 7535 is using external AC power, an AC icon is displayed. Full Empty AC Connection...
  • Page 47 Security levels can be set to limit access and prevent inadvertent changes to application settings. Bluetooth Radio If a Bluetooth radio is installed in your 7535, this icon is displayed in the taskbar. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 48: Audio Indicators

    2.5.3 Audio Indicators The 7535 beeper provides a variety of sounds and can be configured to emit a sound under a variety of conditions. Refer to ‘Volume Adjustment’ in Chapter 5 of the ‘7535 Hand-Held Computer User Manual’ for details about determining when your unit will beep.

  • Page 49: Checking The Scanner

    2.7 Checking The Scanner If your 7535 is equipped with an internal scanner, it will successfully decode most 1D bar codes as delivered. Press the SCAN button or the pistol trigger, and check for a valid decode on any UPC bar code.

  • Page 50: Scan Led Indicators

    • Hold the scanner closer for bar codes with bars that are close together. 2.7.2 Scan LED Indicators The 7535 scanner LED (the lower-left LED) indicates whether or not your scan is successful. The LED behaves as follows: • Scan In Progress: scan LED displays solid red colour.

  • Page 51: Navigating A Touchscreen

    A touchscreen is an optional feature. A 7535 equipped with a touch- screen has a stylus – a pointing tool that looks like a pen – stored in a slot at the top of the 7535. The stylus is used to select objects on the touchscreen.

  • Page 52: The Startup Desktop

    Go to Start Menu <BLUE><0> 3.3 The Startup Desktop When the 7535 boots up, the startup desktop is displayed. Any applications stored in the Startup folder will start up immediately. The Startup folder is located in \Windows\Startup and \Flash Disk\Startup.

  • Page 53: Accessing Desktop Icons

    3.3.2 The Taskbar The 7535 is equipped with a taskbar at the bottom of the screen. It displays icons through which you can view the security level, battery capacity and radio signal quality of your unit. A 7535 attached to a charger, cradle, docking station or PDM displays the associated icon.

  • Page 54: The Start Menu

    3.4 The Start Menu lists operations you can access and work with. It is Start Menu available from the startup desktop or from within any application. To display the menu: Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 55 • Tap on the Window® Start button in the taskbar. Tap on the item in the menu with which you want to work. The Desktop Choosing Desktop from the displays the 7535 desktop. Start Menu Security Settings To assign a security level: Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 56 • Choose System Tray from the Start Menu When System Tray is chosen, the taskbar icons become acces- sible. To display the dialogue box attached to an icon: Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 57 When Cycle Tasks is selected (and the Task Manager is not open), you can cycle through active applications. To choose this: • Press <BLUE><0>, and type <C>, or • Press <ALT> <TAB>. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 58 With Program highlighted, pressing the <RIGHT> arrow key dis- plays a sub-menu of options with which you can work. Settings With Settings highlighted, pressing the <RIGHT> arrow key displays a sub-menu of options with which you can access the Control Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 59 Panel applets, configure your radio (Network and Dial-up Connections) and customize the Taskbar and Start Menu. Choosing the Run option displays a dialogue box in which you can enter the name of the program, folder or document you want to open. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 60 Resets the 7535. Files stored outside of permanent memory are lost. Note: This menu varies slightly depending on the security level chosen. When the 7535 is set to User level, the Shutdown Suspend option is replaced by . A sub-menu is not available.

  • Page 61: Using A Dialogue Box

    <TAB> key until a tab in the dialogue box is highlighted. To display adjoining tabs, press the <RIGHT> or <LEFT> arrow key. To display the information in the next tab from anywhere in the window, press <CTRL> <TAB>. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
  • Page 62 Saving Your Choices: Once you’ve made all your changes, press the <ENTER> key to save your changes and exit the window. Note: A dialogue box item that is displayed in grey text indicates that it is not currently available. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 63: General Maintenance

    • Use only mild detergent or soapy water to clean the hand- held unit. • Avoid abrasive cleaners, solvents or strong chemicals for cleaning. The 7535 has a plastic case that is susceptible to Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 64: Support Services & Worldwide Offices

    For technical support outside of Canada or the U.S.A., please contact your local Psion Teklogix office listed on our worldwide website: http://www.psionteklogix.com Click on the heading labelled “Contacts” to choose a Psion Teklogix technical support representative closest to you. Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...

  • Page 65: Worldwide Offices

    Canadian and U.S. customers can receive access to repair services, by calling the toll-free number below, or via our secure website (see Technical Support, above). Note: Before calling the toll-free number, have your Psion Teklogix customer number or trouble ticket number available. Voice:1 800 387-8898 (press option “2”) Fax:1 905 812-6304 5.3 Worldwide Offices...
  • Page 66 Psion Teklogix S.A. La Duranne 135 Rue Rene Descartes BP 421000 13591 Aix-En-Provence Cedex 3; France Tel: +33 4 42 90 88 09 Fax: +33 4 42 90 88 88 E-mail: tekeuro@psion.com Psion Teklogix 7535 Hand-Held Computer Quick Start Guide...
