Sharp VL-NZ10S Service Manual

Sharp VL-NZ10S Service Manual

Liquid crystal digital camcorder
Hide thumbs Also See for VL-NZ10S:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
www.freeservicemanuals.info
1. SPECIFICATIONS .............................................................................................................................. 2
2. PART NAMES .................................................................................................................................... 3
3. DISASSEMBLY OF THE SET ............................................................................................................ 4
4. MECHANISM ADJUSTMENT JIGS AND PARTS .............................................................................. 6
ITEMS AND INTERVALS ................................................................................................................... 7
6. MECHANICAL ADJUSTMENTS AND CHECKS ................................................................................ 8
7. TAPE RUNNING ADJUSTMENT ..................................................................................................... 11
(DISASSEMBLY AND REASSENBLY) ........................................................................................... 13
9. ADJUSTING THE ELECTRICAL CIRCUITS .................................................................................... 20
10.USEFUL TIPS ................................................................................................................................... 38
11.SIGNAL FLOW DIAGRAMS ............................................................................................................. 39
12.BLOCK DIAGRAMS ......................................................................................................................... 42
13.SCHEMATIC DIAGRAMS ................................................................................................................ 48
14.SEMICONDUCTOR LEAD IDENTIFICATION ............................................................................... 102
15.PRINTED WIRING BOARD ASSEMBLIES .................................................................................... 104
16.REPLACEMENT PARTS LIST ....................................................................................................... 121
17.PACKING OF THE SET ................................................................................................................. 142
SERVICE MANUAL
LIQUID CRYSTAL DIGITAL CAMCORDER
MODELS
In the interests of user-safety (Required by safety regula-
tions in some countries) the set should be restored to its
original condition and only parts identical to those specified
be used.
CONTENTS
SHARP CORPORATION
Published in Heiloo, Holland
1
VL-NZ10S/H/E
12/9/2016
S01B8VL-NZ10S
VL-NZ10S
VL-NZ10H
VL-NZ10E
Page
PAL
