Intermatic CD1-024R Installation Instructions Manual page 3

Table 1. LED Indicators (Diagnostics)
Condition
Surge Protected
No Surge Protection
Under Voltage
Short Cycle Protect
Unit Power Lost
Table 2. Operation
See operation table below for an overview of the Compressor Defender™ Operation
Condition
Under Voltage
Short Cycle Delay
Normally Closed Operation
Understanding the Compressor Defender™ Limited Warranties
The Compressor Defender™ will be free from defects in material and workmanship for 3 years from date
of purchase or 39 months from date of manufacture.
If your compressor becomes damaged while using the Compressor Defender™, please follow the claim
process below:
1) Process an insurance claim with your homeowner's insurance policy.
2) Send the Compressor Defender™ back to lntermatic for evaluation and testing to:
lntermatic Warranty Coordinator, 7777 Winn Road, Spring Grove, IL 60081
3) Upon receipt of the damaged Compressor Defender™, lntermatic will investigate whether the
Compressor Defender™ had a defect in material or workmanship that led to the damage to your
equipment. If the findings determine there was a defect in material or workmanship, lntermatic
will cover any costs beyond your homeowner's coverage up to $7500.00.
**Please sign below to acknowledge that you understand the limited warranties associated with the
Compressor Defender™ and the responsibility of checking the green indicator light to ensure protection
of your HVAC equipment.
Homeowner's Signature
Date of Installation
Green LED
ON
OFF
−
Flash
OFF
Description
If line voltage falls below the accepted level, the relay output will open un-
til the line voltage returns to the accepted level. Voltage Drop Protection
conditions comply with AHRI standard 110-2016 Range B. For Voltage
conditions that drop below outside the limits of Range B prompt correc-
tive action is recommended
• 120 VAC Nominal – Range B 104 VAC
• 208 VAC Nominal – Range B 180 VAC
• 240 VAC Nominal – Range B 208 VAC
Once the line voltage exceeds the pick-up line voltage, the relay will close
after the time delay elapses. Delay = 3 Minutes (non-adjustable).
If surge or voltage monitoring protection is lost, the unit will continue nor-
mal compressor and thermostat operation without surge protection. The
unit should be replaced to restore surge protection to the circuit.
3-Year Product Warranty
$7500.00 Connected Equipment Warranty
Red LED
−
−
Flash
OFF
Service Installer Signature
Suggested Replacement Date
3
3
−
