Landscape Rakes
LR3784 & LR3796
Table of Contents
Read the Operator's Manual entirely. When you
!
see this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Cover photo may show optional equipment
not supplied with standard unit.
© Copyright 2016
302-337M
Operator's Manual
Printed
2/26/16
39414
Advertisement
Table of Contents
Related Manuals for Land Pride LR3784
Summary of Contents for Land Pride LR3784
- Page 1 Table of Contents Landscape Rakes LR3784 & LR3796 39414 302-337M Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! Cover photo may show optional equipment not supplied with standard unit.
-
Page 2: Machine Identification
Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you, or the dealer, have added Options not originally ordered with the machine, or removed Options that were originally ordered, the weights and measurements are no longer accurate for your machine. - Page 3 Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
-
Page 5: Safety At All Times
Download the appropriate App on your Refer to Parts Manual QR smart phone, open the App, point your Locator on this page for phone on the QR code and take a picture. detailed instructions. 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M... - Page 6 ▲ Remove all tools and unused parts permit turning. ▲ Disconnect battery ground cable (-) from implement before operation. ▲ Do not use safety chain for towing. before servicing or adjusting electrical systems or before welding on implement. LR3784 & LR3796 Landscape Rakes 302-337M 2/26/16...
- Page 7 ▲ Be sure to ask how close you can serious injury or death from falling equipment. and machine overturn. work to the marks they positioned. ▲ Wear protective equipment such as a hard hat, safety shoes, safety glasses, and ear plugs. 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M...
-
Page 8: Safety Labels
Spray soapy water onto the cleaned area. all damaged or missing labels. Order new labels from your Peel backing from label and press label firmly onto the nearest Land Pride dealer. To find your nearest dealer, surface. visit our dealer locator at www.landpride.com. -
Page 9: Important Safety Information
(2 Places: Right & left back side of rake) 39415 39414 838-603C 2" x 9" Orange Reflector (1 Place: Left front side of LR3796 rake only) 818-335C 3/4" x 4 5/16" Red Reflector (2-Places: Right and left gauge wheel arms) 33891 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M... -
Page 10: Using This Manual
Table of Contents Introduction Introduction Owner Assistance Land Pride welcomes you to the growing family of new product owners. This Landscape Rake has been The Online Warranty Registration should be completed designed with care and built by skilled workers using by the dealer at the time of purchase. -
Page 11: Section 1: Assembly & Set-Up
IMPORTANT: Remove paint from rake pivot shaft and wipe grease from inside of mainframe pivot hole before lowering mainframe onto blade pivot shaft. Slot In Turn Table Typical Both Sides 35096 Landscape Rake Assembly Figure 1-1 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M... -
Page 12: Tractor Hook-Up
1 or 2 inches. Rotate parking stand up to transport position and NOTE: Land Pride’s Quick Hitch can be attached to secure with wire retaining pin. Make sure wire the tractor to provide quick and easy 3-point hook- retainer is caught over end of pin. -
Page 13: Check Clearances
4. Return “Rake Offset” and “Rake Angling” to center position. 5. Angle and offset rake as far as possible toward the left rear tractor tire and repeat steps 3 through 4 on the left side of the tractor. 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M... -
Page 14: Dual Gauge Wheel Installation
5. Refer to “Side Plate Assembly to Grader Blade” on page 11 for attaching side plates to both ends of 33841 grader blade. Grader Blade Assembly with Gauge Wheel Right-Hand Side Shown Figure 2-2 LR3784 & LR3796 Landscape Rakes 302-337M 2/26/16... -
Page 15: Section 2: Accessory Equipment Set-Up
(#4) to proper torque. 5. Repeat steps 1 thru 4 to attach the left-hand side plate (#1) to the left-hand side of the grader blade. 33842 Side Plate Assembly Right-Hand Side shown Figure 2-4 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M... -
Page 16: Hydraulic Angling Kit
4. Remove bent pin (#19) and store with hex drive pivot 12. Tighten lock nut (#6) and hex flange cap screw (#8) cap (#10). to the correct torque. 39441 Hydraulic Angling Kit Figure 2-5 LR3784 & LR3796 Landscape Rakes 302-337M 2/26/16... -
Page 17: Operating Checklist
Striking solid should the rake make contact with a solid object. objects can cause tractor to pivot violently resulting in loss of control, serious injury, or death. 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M... -
Page 18: Inspection After Hook-Up
5. Slow down if traveling on a wet slick road. Shift to a lower gear when traveling over rough or hilly terrain and when going downhill. LR3784 & LR3796 Landscape Rakes 302-337M 2/26/16... -
Page 19: Section 3: Operating Instructions
By now you should have thoroughly read your Operator’s information on performance enhancing options. Manual and properly installed your Land Pride rake to your tractor. Before you begin raking, you should visually survey the work site to make sure it is safe and free of foreign objects. -
Page 20: Safety Alerts
Read and follow all “Safety Alerts” above. Rake Angling (manual shown) 2. Pull bent pin (#2) from hole in mainframe. Figure 4-2 3. Rotate rake (#1) to the desired angle and reinsert bent pin (#2). LR3784 & LR3796 Landscape Rakes 302-337M 2/26/16... -
Page 21: Section 4: Adjustments
5. Replace bent pin (#3) in lower holes “B” to secure blade (#2) in the raised position. 6. Secure bent pin (#3) with hairpin cotter (#4). 33896 Grader Blade Lock Up Position Figure 4-4 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M... -
Page 22: Long Term Storage
The rake will fall off if rake pivot hardware is missing. CAUTION Do not alter Land Pride equipment or replace parts with other brands. Doing so can cause equipment to perform improperly and may lead to breakage that can cause bodily injury. -
Page 23: Section 5: Maintenance & Lubrication
35103 Hours Rake Pivot Shaft Type of Lubrication: Multi-Purpose Grease Quantity = Until grease emerges 35104 Seasonally Rake Teeth Grease before extended non-use or seasonally. Type of Lubrication: Multi-Purpose Quantity = Generously 35093 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M... - Page 24 Type of Lubrication: Multi-Purpose Quantity = Until grease begins to emerge. 35102 Hours (Accessory) Gauge Wheel Axle Grease gauge wheel axle every 25 hours. Type of Lubrication: Multi-Purpose Quantity = Until grease begins to emerge. 35102 LR3784 & LR3796 Landscape Rakes 302-337M 2/26/16...
-
Page 25: Section 6: Accessories
Hydraulic Angling NOTE: The Hydraulic Angling Kit allows operator to change rake angle from the tractor seat. Kit Bundle 302-335A ..KIT, LR37 HYDRAULIC ANGLE 2/26/16 LR3784 & LR3796 Landscape Rakes 302-337M... -
Page 26: Section 7: Specifications & Capacities
Flip-Down, Self-Supporting Grader Blade with Blade-up Locking Handles and Locking Pins Rear Blade Attachment (Accessory) Available in 72", 84" & 96" Working Widths * Dual gauge wheels are capable of supporting Flip Down Grader Blade Accessory 39418 LR3784 & LR3796 Landscape Rakes 302-337M 2/26/16... -
Page 27: Section 8: Features & Benefits
Fits many tractors with a Cat. l or Cat. ll 3-point hitch. Quick Hitch Compatible Fits Land Pride Quick Hitch for a quick and easy one person hook-up. Retractable Parking Stand Keeps frame off the ground and makes hook-up easier. -
Page 28: Section 9: Torque Values Chart
= nominal thread diameter in millimeters x thread pitch 1-1/2" - 12 1330 2970 2190 4820 3560 Torque tolerance + 0%, -15% of torquing values. Unless otherwise specified use torque values listed above. LR3784 & LR3796 Landscape Rakes 302-337M 2/26/16... -
Page 29: Warranty
This Warranty is limited to the repair or replacement of any defective part by Land Pride and the installation by the dealer of any such replacement part, and does not cover common wear items. Land Pride reserves the right to inspect any equipment or parts which are claimed to have been defective in material or workmanship. - Page 30 Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...
