Summary of Contents for CHCNAV LT700 SERIES
- Page 1 LT700 S ERIES ETTING TARTED UIDE Handheld GNSS Data Collector Shanghai Huace Navigation Technology LTD.
-
Page 2: Table Of Contents
CONTENTS Introduction ............................. 2 1.1. Technical Assistance ....................... 2 1.2. Your Comments ........................2 1.3. Safety Information ........................2 1.4. Warning and Cautions ......................2 1.5. Use and Care ........................... 2 Overview ..............................3 2.1. Features ..........................3 2.2. Specifications .......................... 3 LT700 Overview ............................ -
Page 3: Introduction
1.5. SE AND The LT700 Series is designed to withstand the rough environment that typically occurs in the field. However, the LT700 Series is high-precision electronic equipment and should be treated with reasonable care. Page 2 ... -
Page 4: Overview
VERVIEW 2.1. EATURES LT700 is the high-end GNSS tablet which supports Android 7.1 platform. It’s a FAD-W high accuracy tablet which can reach 10cm to 2m accuracy as different hardware configuration. Meanwhile, its dust and water proof level is IP67 and can survive 1.2m fall onto concrete. With 8000mAh Li-ion battery, it can continuously work more than 15h. - Page 5 Physical specifications Display · Size: 8inch Corning Gorilla Glass touch screen · Resolution: 1280*800 · Brightness: 450cd/m · Touch screen: Capacitance touch, 5 points touch screen · Point touch pen: Mapping pen with high degree of accuracy Physical · Dust proof and waterproof: IP67 ·...
-
Page 6: Lt700 Overview
LT700 O VERVIEW 3.1. RONT Power Button • Power ON: Press the button for 1-2 seconds, the Power Indicator will turn on and the boot screen will appear, and then the LT700 will enter the operation system after 30 seconds. Power OFF: Press the button for 1-2 seconds, the “SELECT”... - Page 7 Menu Button • Click this button to bring out the start menu. • Homepage Use the Homepage button to main menu. F1/f2 Function Button • This key is a shortcut key to the preset function or menu. • Type C This interface is used for battery charging and data transmission between LT700 and PC using USB cable.
-
Page 8: Back View
3.2. Page 7 ... -
Page 9: Side View
3.3. 3.4. NSTALLATION Please insert the SIM card and the MicroSD card in the direction of the diagram. Page 8 ... -
Page 10: Basic Operation
ASIC PERATION 4.1. SIM C NSERT ARD AND POWER ON • Refer to 3.4 Installation find the SIM card and TF card slot, and then insert the cards into slots correctly. • Before powering on LT700, please make sure the battery has plenty of power. Then long press the power button to turn on LT700 and enter its home screen. - Page 11 Figure 3 Figure 4 Use virtual button key to facilitate your operation with LT700. Click to go back to previous menu. Click to return home screen. Click to see all the running apps (Fig. 3) and then you can remove apps by sliding them right (Fig. 4). After powering on LT700 (refer to 4.2 Power on), Click Settings/SIM card to turn on the SIM cards.
-
Page 12: Language & Input
4.2. & ANGUAGE INPUT Click Settings/Language & input/Language to select language. 4.3. Click Settings/Date & time and enter Date & time interface. If you want to use date and time from network or GPS, click Automatic date & time to select Use network-provided time or Use GPS-provided time: Page 11 ... -
Page 13: Display
If you want to set date and time by yourself, please turn off the Automatic date & time first and then click Set date and Set time to start your own settings. OU CAN ALSO CUSTOMIZE YOUR TIME ZONE AND CHOOSE WHETHER TO USE HOUR FORMAT IN THIS INTERFACE 4.4. -
Page 14: Wifi
Sleep: Click to optimize the inactivity time LT700 needs to close screen. Font size: Click to change the font size. 4.5. WIFI Click Settings/WIFI to switch on the button. Select WIFI and type in its password to connect. Page 13 ... -
Page 15: Bluetooth
4.6. LUETOOTH Click Settings/Bluetooth to turn on the Bluetooth. Find nearby devices and pair with it. 4.7. USB C ONNECTION For connection or data transmission between LT700 and office computer, please use the USB data cable as Page 14 ... -
Page 16: Use Camera
shown below. Click Settings/Developer options/USB debugging to make sure this function is switched on. After USB data cable is connected with PC, wait until the Allow USB debugging dialogue pops up, click OK. You can also use third party software to manage the documents and data stored in LT700 and install software like GNSS Tool into it. -
Page 17: Log In 4G
Camera Settings Click to configure related parameters. 4.9. OG IN After inserting your SIM card, click Settings/More/Mobile Networks/Preferred network type and select corresponding network type of your SIM card. Then Click SIM card icon in the pull down menu and turn on Mobile data and click More Settings to see data usage. - Page 18 Set the Scheduled power on time and click OK. Set scheduled power on repeat time and click OK. Scheduled power off time settings is the same with Scheduled power on. Page 17 ...
-
Page 19: Location
4.11. L OCATION Click Settings/Location to switch on location service. Page 18 ... -
Page 20: Getting Started With Gnsstool
ETTING TARTED 5.1. ONNECTION Open GNSSTool and click [Connect] menu and select [Device Type] and [Connection Type] / [Device ID] in connect interface. Device Type: There are 4 types of Device Type: Smart RTK, GNSS RTK, Local and Peripheral. Here for LT700, we choose Local. - Page 21 Connection Type: For smart RTK (like i80), we select Bluetooth, WIFI or Demonstration. For GNSS RTK (like X91), we select Bluetooth, and Demonstration. For Local and Peripheral, we select the specific device type that we use. Here we select LT700 for Connection Type. Click [Connect] to connect with the receiver successfully and go back to the previous interface.
-
Page 22: Cors Login
5.2. CORS L OGIN After finishing connection successfully, we can log in CORS to receive differential data. 1. Click Diff Data Source in the main interface, type in IP, Port, Source Table and other parameters and then click LOGIN. 5.3. Click Sky Plot and see how many satellites (including GPS, GLONASS, BDS, GALILEO and SBAS) the device is currently tracking. -
Page 23: Debugging Data
5.4. EBUGGING Click Debugging Data to enter data debugging interface. Click HEX to change the data into txt format, you can also pause, save and clear the data using button in the upper side. Page 22 ... - Page 24 Shanghai Huace Navigation Technology Co., Ltd Building C, NO. 599 Gaojing Road, Qingpu District, 201702 Shanghai, China Tel: +86 21 542 60 273 Tel: +86 21 649 50 963 Email: sales@chcnav.com | support@chcnav.com Website: www.chcnav.com Page 23 ...
- Page 25 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment。 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
