Lascar EL-PDF-1 Series Quick Start Manual

1. Your new logger comes ready to go.
Simply press and hold the
Status mark
Preset high
and low alarm
levels
Status LEDs
2.
Now place your logger in the location you want to monitor.
Once logging, pressing the
status. It will also add a marker to the data to show that you have checked it.
No alarms will be triggered in the first 30 minutes to allow the logger to settle at the
monitored conditions.
Red + Green single flash
Logger is ready to start new logging session
Green single flash
The data logger is currently logging
No alarm has been triggered
Red single flash
The data logger is currently logging
An alarm has been triggered!
Green double flash
The data logger's memory is full or the logger has been
stopped. No alarm was triggered during the session.
Red double flash
The data logger's memory is full or the logger has been
stopped. An alarm was triggered during the session!
No LEDs flash
The data logger has a flat battery
www.lascarelectronics.com/data-loggers
button until the green LED lights up to start logging.
STATUS START
MARK STOP
EasyLog
CHILLED GOODS
button will light up an LED to give a quick indication of the
QUICK START GUIDE
EL-PDF-1 Series
Push to start/stop
Push Start / Stop button
No action required
Check status in the PDF
Plug your logger in to a PC and download
the PDF
Plug your logger in to a PC, download the PDF
and check alarm condition
Contact your distributor for a new logger
