Page 1
GFX Data Logger Series electronics Quick Start Guide Download software now from www.easylogusb.com...
Page 2
FIRST INSTALL YOUR SOFTWARE & USB DRIVER Windows ™ XP/VISTA/7 ● Visit www.easylogusb.com and click “Begin Software Download” Follow the instructions found in “Installing EL-WIN-USB on Windows” (link on website) ●...
Page 3
INSTALL YOUR BATTERY ● Your EL-GFX data logger is supplied with batteries fitted. To connect the batteries pull and remove the plastic tag located at the join between the top and bottom housing. With this removed tighten the screws to ensure a waterproof seal between housings.
Page 4
If you would like advice on how best to use the data logger for a particular application, please contact your nearest Lascar representative. Do not leave your data logger connected to the USB port as this will cause some of ●...
Page 5
GETTING TO KNOW YOUR EL-GFX LOGGER Status ● USB Cover: This USB port cover gives IP65 Audible LEDs protection* to your data logger when fitted. Alarm 128x128 Backlit LCD ● Mounting Clip: The plastic mounting clip supplied allows wall mounting if required or to USB Port metal surfaces using the integrated magnet.
Page 6
SP5 2SJ UNITED STATES Kwun Tong, Kowloon UNITED KINGDOM HONG KONG T +1 (814) 835-0621 T +44 (0) 1794 884567 E us-sales@lascarelectronics.com T +852 2389 6502 To register your data logger online visit www.lascarelectronics.com/registration-form.php E sales@lascar.co.uk E sales@lascar.com.hk Issue 3...
Page 7
Calibration Certification Calibration certificates for all of Lascar’s temperature and humidity data loggers are available to purchase. For custom-specific or multiple temperature points, please contact the Lascar sales team for further pricing.
