48 MONTHS / 40,000KM SERVICE
Hitch Inspect for damage and lubricate. Check bolt Torque to 76Nm
Jockey Wheel
Inspect for condition and operation
Hand winch Check brake function and webbing
Suspension Lubricate and check bushes for excess movement. Torque bolts to 190Nm
Brakes Inspect and adjust. Check lining thickness and drum wear
Replace bearings, seals and lubricate. Check stub axle condition and wear.
Wheel bearings
Replace split pin.
Inspect condition and torque to 125Nm (12mm studs)
Wheel Nuts
(140Nm 14mm studs alloy rims) (200Nm 14mm studs steel rims)
Tyres Check for damage and pressure
Lights Check all lights are functioning
Battery Check terminals and voltage at full charge
Seals Check condition and correct latch/lock adjustment for correct 30-50% compression
General fixings Check all structural fixing are secure.
Date:
Dealer Stamp:
54 MONTHS / 45,000KM SERVICE
Hitch Inspect for damage and lubricate. Check bolt Torque to 76Nm
Hand brake Check cable and adjust if necessary
Hand winch Check brake function and webbing
Suspension Lubricate and check bushes for excess movement. Torque bolts to 190Nm
Brakes Inspect and adjust. Check lining thickness and drum wear
Wheel bearings Remove, clean and re-lubricate. Inspect for wear and replace if necessary
Inspect condition and torque to 125Nm (12mm studs)
Wheel Nuts
(140Nm 14mm studs alloy rims) (200Nm 14mm studs steel rims)
Tyres Check for damage and pressure
Gas System
Leak, test, check stove operation and hose/coupling condition
Battery
Check terminals and voltage at full charge
Seals Check condition and correct latch/lock adjustment for correct 30-50% compression
General fixings Check all structural fixing are secure.
Date:
Dealer Stamp:
Service Person:
Service Person:
1300 494 494
CHECKED
CHECKED
