User Guide

PLEASE READ PG 1

Need help?

Do you have a question about the Sphere and is the answer not in the manual?

Page 2: Physical Connections
Move the System on/off switch (A) to the on position. If mounting Sphere on a tripod or articulating arm, attach the T-bracket to the bottom of Sphere using the included screws. The bracket has four 1/4”-20 threaded holes for use with various mounting hardware.
Page 3 ADDING CAMERAS Connect your iPad Pro to the Internet and download Teradek’s Sphere app After connecting to Sphere and starting the app, you’ll need to create a rig and add cameras to it. from the App Store. SPHERE 1. Tap New Rig! Enter a name for it,...
Page 4 The Snapshots menu allows you to save a snapshot of the full panoramic view or an 1. Lens Correction contains controls to adjust for any distortion caused by a particular undistorted device stream. After saving a snapshot they can be viewed from Sphere’s main camera/lens combination.
Page 5 The Streaming panel allows you to start and stop a live stream to YouTube or any other plat- form with support for live 360º video. Streaming live video from Sphere requires the streaming license, which is available at teradek.com if it wasn’t purchased with the device.
