Teradek VidiUPRO Instructions

B
C
D
A
E
A: SD Card slot F: Start/Stop Joystick
B: Video Input Status G: Menu Joystick
C: Encoder Status H: USB Port
D: Broadcast Status I: HDMI input
E: Warning Indicator J: MIC/Line input
H
Start/Stop Joystick:
: Start/stop broadcasts, exit menu screens
● (button press)
Menu Joystick:
, , , : Select menu items, change status screen on main display, select characters
▲ ▼
, : Confirm selection, open selected menu
● (button press)
Reset Button:
Hold for 3−6 seconds: Reset all network settings
Hold for 10+ seconds: Perform complete factory reset
pantone 1795 pantone 355 pantone 307
K: Headphone output
L: Reset Button
M: Ethernet
N: DC Input
O: Power Switch
O
N
M
L
K
J
I

GET ONLINE

iOS
Download the VidiU app from the App Store. Next, decide how VidiU should connect to the Internet:
Use your phone's data plan
Connect to VidiU's WiFi network: VidiU−XXXXX (serial number of the device)
1
F
Open the VidiU app and select VidiU under the list of WiFi devices.
2
When prompted, click Yes to use your cellular data plan. If you have a ShareLink account, up to four phones
3
can be used simultaneously.
Connect to an existing WiFi network
Ensure Bluetooth is enabled on your iOS device, then open the VidiU app and select
G 1
VidiU pro under the list of Bluetooth devices
If your iOS device is connected to a WiFi network, the Network field will be completed
2
automatically. Enter the WiFi network's password and press Connect. Click Done.
After a few seconds VidiU should connect to your network. Select VidiU pro under WiFi Devices
3
once it appears.
ANDROID/PC
Connect to VidiU Pro's WiFi network: VidiU−pro−XXXXX (serial number of the device)
1
Open a web browser and navigate to http://172.16.1.1, or find VidiU using Bonjour
2
Enter the Settings menu and open the Network section to configure VidiU Pro's WiFi
3
Once configured, connect your mobile device or computer to the same network as VidiU Pro
4
Use the VidiU app (Android) or a Bonjour browser (PC/Mac) to find VidiU Pro's new IP address.
5

CONNECT TO A WIRED NETWORK

Plug an Ethernet cable into VidiU Pro's 10/100 Ethernet port and connect it to an Internet−connected
Ethernet switch or router

CONNECT VIA A 3G/4G USB MODEM

Connect a compatible 3G/4G modem to VidiU Pro via USB. See http://support.teradek.com for a list
of supported modems

CHOOSE A PLATFORM AND QUALITY

Using the VidiU app, web UI, or front panel prompts, Enter the Broadcast menu
1
Choose a platform − Ustream, Livestream, YouTube, Twitch − or select manual RTMP
2
Enter your credentials or RTMP destination info and press apply
3
Select your desired Video bitrate and resolution under the Broadcast Quality menu
4
NEED MORE HELP?
1. Support forum: http://support.teradek.com → Contains tips, information and all the latest firmware & software updates.
2. Training videos: http://www.teradek.com/trainin
TERADEK SUPPORT STAFF: support@teradek.com or call 888−941−2111 ext2 (Mon−Fri 9am to 6pm PST)
