Please take time to read and understand these installation instructions.
CORSA recommends that installation of this system be performed by a qualified service center or professional
muffler installer who has the necessary equipment, tools and experienced personnel. However, if you decide
to perform this install, the use of a hoist and an additional person will be required.
CAUTION: Never work on a hot exhaust system. Allow time for the vehicle to cool. Always wear eye protection
when working under a vehicle.
Please confirm that all parts are present before
beginning the factory exhaust system removal
and CORSA exhaust system installation.
PN14172 & PN 14164
Bill of Materials:
• Driver Side Rear Muffler Assembly
Single Pro-Series Tips
PN14172 (16CS2037)
PN14164 (16CS2047)
• Passenger Side Rear Muffler Assembly
Single Pro-Series Tips
PN14172 (16CS2036)
PN14164 (16CS2046)
• Driver Side Over the Axle Pipe
(16CS4021)
• Passenger Side Over the Axle Pipe
(16CS4020)
• (2) 3" Clamps
• (1) Anti-seize Lube Pouch
• (2) Vacuum Caps
PN14173
Bill of Materials:
• XO-Pipe Assembly
(16CS4028)
• (2) 3" Clamps
XO-Pipe
• (1) Anti-seize
Assembly
Lube Pouch
INSTALLATION INSTRUCTIONS / CAT-BACK EXHAUST SYSTEM
2006 Chevrolet Corvette Z06 Axle Back System
With Single Pro-Series 4.0" Tips
2006 Chevrolet Corvette Z06 Axle Back System
With Twin Pro-Series 4.0" Tips
2006 Chevrolet Corvette Z06 XO-Pipe
(1) Anti-Seize
Lube Pouch
(2) Vacuum
Caps
(1) Anti-Seize
Lube Pouch
(2) 3" Clamps
Recommended Tools:
• Safety Glasses
• 13mm Socket
• 15mm Wrench
• 15mm Socket
• 18mm Socket
Driver Side
Over the Axle Pipe
(16CS4021)
(2) 3" Clamps
Driver Side
Rear Muffler
(16CS2037)
Driver Side
Rear Muffler
(16CS2047)
PART NUMBER 14172
PART NUMBER 14164
PART NUMBER 14173
• Grommet Pullers
• 3/8" Ratchet
• 12" Ratchet Extension
• Torque Wrench
• Saw or Chain-Style Pipe
Cutter
Passenger Side
Over the Axle Pipe
(16CS4020)
Passenger Side
Rear Muffler
(16CS2036)
Passenger Side
Rear Muffler
(16CS2046)
