Summary of Contents for Axesstel EU230
-
Page 2: Safety Precautions
Internet, data intensive files and multi- media s treaming. SMS messaging enable users to stay connected to colleagues, customers and family. EU230 allows for quick and easy connectivity to a l aptop PC equipped with ® ExpressCard 34 interface or USB interface, providing broadband data access from the home, office or while working remotely. -
Page 3: Checking The Parts
CHECKING THE PARTS Once you have unpacked your product package , make sure that you have all the parts shown below. If any piece is missing or broken, please call your customer service. 1. Main Unit 2. USB adapter jacket 3. -
Page 4: Installing The Modem Software
The entire process will take approximately 5 minutes to complete. Step 1: After inserting the Card to the PC port the above window will appear. Click “Axesstel Manager Setup.exe” to install AxessManager. Note: If Windows OS auto-play feature is not available and you don’t see the pop- up window in step 1, click on “Start”... - Page 5 Step 2: Click “Next” to continue Step 3: Click “Next” to continue Step 4: Click Finish to complete installation of AxessManager...
- Page 6 Step 5: Click Axesstel Driver Setup folder and select “Install 32” folder *If you use 64bit OS, please run “MSP_Install64.exe” under “Install 64” folder. Step 6: Click MSP_Install.exe to install USB Driver The following screen will appear Step 7: Click Install and make sure the driver was installed successfully.
- Page 7 Step 8: After finishing driver file copy, the Card will change to Modem mode from CD ROM Mode. Axesstel USB Mode will be detected on your PC. Select Next to install USB Driver Step 9: Select Continue Anyway...
- Page 8 Step 10:.Click Finish to complete the process Step 11: Axesstel Diagnostic Port will be detected on your PC. Select Next to install USB Driver...
- Page 9 Step 12: Select Continue Anyway . Step 13: Click Finish to complete the process. After this step you can begin to use AxessManager Once finished the installation, AxessManager SW utility will appear as a short cut icon in Window.
-
Page 10: Getting To Know Your Modem
GETTING TO KNOW YOUR MODEM AxessManager GUI AxessManager is a SW utility that allows the administration of your Card. You use AxessManager to: Initiate data sessions Receive and send SMS messag es Customize features and options 1. Setting Button: Change options of your Card such as SMS setting, APN setting, etc…... - Page 11 AxessManager Operation Guide 1. Getting Started When the PC and the Card are connected, AxessManager allows you to browse Internet, modify modem configurations and text messaging. In addition, you can perform management tasks for device numbers such as adding, modifying and deleting them, and you can write messages in your PC and send them to your modem.
- Page 12 1. Click the icon on your desktop to run the AxessManager Program. Axesstel Manager.lnk 2. Click the Connect/Disconnect button. Note that a connection profile needs to be defined and selected before using the Connect/Disconnect button. Please refer to the section “Add Connect Item” below for more information. When the connection...
-
Page 13: Device Setting
Disconnecting 1. Click the Connect/Disconnect button after finishing your job. The connection is discontinued and the active Connect/Disconnect button is changed to the disabled status. 2. To exit the program after finishing the job, click the “X” button at top right of the program window. - Page 14 SMS setting sub- menu: use this function to (i) set the timer for the message to remain in your Card and (ii) select the location where incoming messages will be stored. If you select the location as “SIM inbox”, all incoming messages to your number are stored in the memory of your SIM card.
-
Page 15: Sms Manager
Add New Connection Profile To add new profile, simply enter the information into each connection parameter then click Save button. (1) Profile Name: Enter the name to be displayed on the 'Connect Item' list. (2) Number : Specify the device number to which modem will connect. (3) User Name: If required, enter the user ID for the network provider. - Page 16 3.1. Inbox /SIM Inbox Manager Both Inbox and SIM Inbox Manager offer same features. The difference is only the location where the messages were stored. Refer to section 2.1 for more details about storing incoming messages. With Inbox Manager, you can reply to, forward, or delete selected messages. 1.
- Page 17 To delete multiple data simultaneously, select them with your mouse while pressing down the Shift or Ctrl key and then press the Delete key. The selected Inbox data is deleted at once from the device. The deleted Inbox data cannot be restored 4.
- Page 18 (1) The detail of the Outbox message selected from Outbox List View is displayed in the Preview window at bottom. (2) To write a new message, click the Send button in the Preview window. A new window pops up in which you can write a new message and send it to others. (3) When you click the Forward button in the Preview window, a new window pops up for you to edit the message and send it to the another person.
- Page 19 3.5. Send To send a new message, press New button the Preview window. A new window will pop up. There are 4 buttons in the Send window. 1. Send Send the message directly to the recipients through the modem. 2. Send & Save Send the message directly to the recipients through the modem.
-
Page 20: Specifications
Miscellaneous SPECIFICATIONS Tri-band UMTS: 2100/ 1900/ 850 MHz (Band I/ II/V) Frequency Range Quad- band GSM / GPRS / EDGE: 850 / 900 / 1800 / 1900 MHz Channel Bandwidth WCDMA 5 MHz External appearance Express Card: 125.2 x 46 x 13 (mm) Express Card + USB Adaptor: 144.1 x 46 x Weight... -
Page 21: Safety Information For Rf Exposure
requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest FCC SAR value for this device when tested for use at the when worn on the body, as described in this user guide, is 0.92 W/Kg . -
Page 22: Radio Frequency Interference Statement
U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful Interference in a residential installation This equipment generates, uses, and can radiate radio frequency energy and, if Not installed and used in accordance with the instructions,... - Page 23 SAR operating levels may be below the maximum value because the device is designed to use only that power necessary to reach a network. That amount varies depending on base station proximity and other factors. ˙ There may be different SAR values depending on the mode, all modes are designed to meet radio wave requirements.
