AVProConnect AC-MX1616-AUHD User Manual

18 gbps true 4k60 4:4:4 16x16 hdmi matrix w/ audio de-embedding & routing
Hide thumbs

Advertisement

Quick Links

Download this manual
AC-MX1616-AUHD
User Manual
AC-MX1616-AUHD
18 Gbps True 4K60 4:4:4 16x16 HDMI Matrix
w/ Audio De-Embedding & Routing.
pg. 1
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
support@avproconnect.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the AC-MX1616-AUHD and is the answer not in the manual?

Questions and answers

Related Manuals for AVProConnect AC-MX1616-AUHD

Summary of Contents for AVProConnect AC-MX1616-AUHD

  • Page 1 AC-MX1616-AUHD User Manual AC-MX1616-AUHD 18 Gbps True 4K60 4:4:4 16x16 HDMI Matrix w/ Audio De-Embedding & Routing. pg. 1 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 2 AC-MX1616-AUHD Common Usage Diagram pg. 2 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...

  • Page 3: Specifications

    AC-MX1616-AUHD Specifications: pg. 3 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...

  • Page 4: Easy To Use

    AC-MX1616-AUHD The AC-MX1616-AUHD is a true high bandwidth powerhouse. Supporting the full HDMI 2.0a/b specification and supporting every flavor of HDR, this matrix will ensure you can get the most out of any system. This unit supports uncompressed HDR formats Including HDR, HDR10, HDR10+, Dolby Vision, HLG, BBC and NHK. All of them are supported in up to 4K 60Hz and up to 12 Bit Deep Color.
  • Page 5 Input (Source) & Output (Sink) Select IR Receiver Used w/ Control (Choose Output, press Enter, choose Input) for Switch Control Screen Screen Control HDMI Inputs HDMI Outputs pg. 5 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...

  • Page 6: Basic Setup

    2. Connect the HDMI output devices (AVR, Display, Distribution Amplifier, Extender) to the AC-MX1616-AUHD 3. Power on the sources 4. Connect the power supply's into the AC-MX1616-AUHD (You need to plug in both supply's) 5. Turn on output devices/displays 6. You may now use the front panel controls, supplied IR remote or free PC software to control the switch.
  • Page 7 2. Set new matrix routes. You can change the matrix routes here as well, this is good for demonstrating switching. NOTE: When setting a new route, select OUTPUT first then INPUT Select "Matrix" Then Choose Input Select Output First pg. 7 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 8 EDID effectively tells the source what the system is capable of handling, devices without robust EDID control just have to hope the source behaves how we want it to. With the AC-MX1616-AUHD you control the sources: To Set the EDID, just choose EDID from the "Home Screen"...
  • Page 9 Make sure this area says MATRIX Press the desired extracted audio OUTPUT number Choose "VIEW AUDO" Press Enter Press the desired INPUT number pg. 9 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 10 You can send Telnet commands to the machine by IP, the commands are the same commands used for RS232 listed in the "Command List" Route IP Device IP Address Subnet Mask DHCP Toggle TCP/IP Port (0=OFF, 1=ON) MAC Address pg. 10 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...

  • Page 11: Ir Remote Control

    IR Details: IR IN on this machine is for controlling the AC-MX1616-AUHD, RS232 or IP Control are the recommended methods, but IR can be used in some circumstances. The IR INPUT is for an IR Receiver EYE only. The IR Receiver Eye below can plug into the IR Ext.
  • Page 12 You can send serial commands in the 3-Pin port or the USB port USB has a built in USB-->Serial driver, a com port will be set 3-Pin RS232 up on the PC pg. 12 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 13 == GET OUTx AS IN : Get Output x Ex-Audio Route{x=[0~16](0=ALL)} == GET OUTx STREAM : Get Output x Stream ON/OFF Status{x=[0~16](0=ALL)} ==----------------------------------------------------------------------------------------== pg. 13 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 14 : Get Net Mask == GET TIP : Get TCP/IP Port == GET DHCP : Get DHCP Status == GET MAC : Get MAC Address ============================================================================================ pg. 14 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 15 A best practice is to set a static IP address for each unit, rather than DHCP. pg. 15 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 16 SET OUTx EAS INy -- Where (x=0-16) 0=ALL, 1-16=Desired Output & (y=1-16) 1-16=Desired Input NOTE: Extracted Audio Ports are PCM 2CH audio up to LPCM 6 CH, Dolby Digital 5.1 & DTS. No down-mix. Audio Diagrams: pg. 16 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 17 AC-MX1616-AUHD Extracted Audio cont: Audio Diagrams: pg. 17 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 18 Address of the device you want to control (If cascading multiple units). Press "Address Management" to set the Addresses. View "Address Management' Tab later for more. pg. 18 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 19 Note: PC Control Software can be used when connected to the RS232 or Mini USB Port. Switching - Simply choose the INPUT radio button you want to see on each output. pg. 19 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 20 Note: PC Control Software can be used when connected to the RS232 or Mini USB Port. Switching - Simply choose the INPUT radio button you want to see on each output. pg. 20 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 21 EDID later and apply it to one of the "USER" EDIDs. You can then apply that USER EDID to one or more of the inputs. pg. 21 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 22 Note: PC Control Software can be used when connected to the RS232 or Mini USB Port. Reset to default Toggle DHCP Set IP Settings Save Settings pg. 22 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 23 The Sense Switch page is the main page of the Web Interface. Here you can easily control switching of the matrix. NOTE: The inputs and outputs can be labeled in the "System Config" Tab. pg. 23 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 24 Ex-Audio Mode is "Matrix". 3 - Audio Status ~ You can turn each extracted audio port ON or OFF (Mute) pg. 24 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 25 12. 4K60HZ_3D_2CH 29. 4K60HZ_3D_8CH_HDR 13. 4K60HZ_3D_6CH 30. User EDID 1 14. 4K60HZ_3D_8CH 31. User EDID 2 15. 1080P_2CH_HDR 32. User EDID 3 16. 1080P_6CH_HDR pg. 25 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 26 The System Config tab let you achieve two functions. 1. Setting up your network (IP) settings 2. Labeling the Inputs and Outputs for the "Sense Switch" Tab pg. 28 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 27 AC-MX1616-AUHD This page left blank pg. 29 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 28 3518 N Casco A ve nue ~ Sioux F a lls , SD 57104 1 - 8 7 7 - 8 8 6 - 5 1 1 2 ~ 605-274 -6 05 5 pg. 30 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
