- Page 2 AC-SW62-UHD Introduction AVProConnect’s AC-SW62-UHD (aka EasyStreet) is a robust multi-format matrix switch designed for small offices, classrooms and conference rooms. This 6x2 matrix is designed to be an ALL-IN-ONE solution for the active office allowing for multiple input types, including HDMI (x3), VGA, DisplayPort. In addition to the local inputs, it has a...
- Page 3 AC-SW62-UHD Applications: • The efficient user interface makes it an ideal "leave in room" device for conference rooms that the end user can control simply. • Conference/huddle room configurations where many sources types can be used, DisplayPort, HDMI and VGA •...
-
Page 4: What's Included
Designed for the conference/classroom room so your customer can focus on their meetings, not their video system. Supports uncompressed PCM 2- Ch., 5.1, 7.1, Dolby Digital, DTS, • Dolby TrueHD, DTS HD-Master Audio, Atmos. What's Included ■ AC-SW62-UHD (Matrix) • IR Emitter • IR Receiver • •... - Page 5 AC-SW62-UHD Notice AVProConnect reserves all the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this device to 6.
- Page 6 AC-SW62-UHD Specifications ■...
-
Page 7: Basic Installation
1. Plug in the display(s) or sink devices 2. Plug in the sources 3. Plug in the power supply to the AC-SW62-UHD 4. Power on the Sources and Display(s) This will ensure proper EDID application across the device. - Page 8 Auto-Switching Logic ■ When the AC-SW62-UHD is in "Auto" mode the logic is to switch to the most recently plugged in device based on a Hot Plug Event. You can have either the HDMI, HDBaseT or both be set to "Auto" mode. See examples: 1.
- Page 9 AC-SW62-UHD PoE & HDBaseT (In/Out) ■ The AC-SW62-UHD has a HDBaseT Input and an HDBaseT Output. The distance for HDBaseT is 70M (230ft) using UTP/STP Cat cable. PoE works as described below. HDBaseT Input: • By default the PoE on the HDBaseT Input is set to OFF. This allows the device to be compatible with any HDBaseT Transmitter of ANY brand as long as the Transmitter can be powered.
- Page 10 1. HDBT - This is for transmitting RS232 signals from the matrix to the remote HDBaseT Receiver. 2. RS232-CTL - This is for send signals to the AC-SW62-UHD for controlling the device - The Command List can be found on the next page.
- Page 11 AC-SW62-UHD RS-232 Commands ■...
- Page 12 IR IN - The IR IN port is designed for a IR Receiving Eye (pictured below). This port has two main functions: 1. To receive IR signals to control the AC-SW62-UHD 2. To receive IR signals and pass them to the IR Emitter connected to an HDBaseT Receiver.
- Page 13 AC-SW62-UHD IR Configuration Cont. ■ IR OUT - The IR OUT port is send IR signals out of an IR Emitter (Pictured below) that originate at the HDBaseT Receiver OR HDBaseT Transmitter IR Emitter:...
- Page 14 The Relay Control Panel is for selecting the active input. How it works: • To trigger the AC-SW62-UHD to switch to the desired input, you must complete a circuit from the terminal for the "Input" and "Ground". ex, If you close a circuit from the "VG"...
- Page 15 AC-SW62-UHD Using The Relay Panel cont. ■ Using the "OS" Output Select Function: • Rear panel I/Os can be used to change source for local HDMI output port or HDBT port. • Default is to change the source both HDMI and HDBT at the same time.
- Page 16 AC-SW62-UHD Audio Extraction ■ Stereo audio extraction is available from the AC-SW62-UHD. Audio extraction supports 2CH PCM audio only and is ideal for audio from conferencing device like PC's, MACs, etc... How it works: • Audio from this port is ON by default, so just plugging in a cable will start pulling the audio.
-
Page 17: Advanced Edid Management
AC-SW62-UHD Advanced EDID Management ■ EDID Management can be done by RS232 and also from the front panel controls. From RS232: • Send EDID commands here (notepad command lisf available on www.avproconnect.com: From Front Panel: • Press and hold the HDBaseT Input Select Button for 5 seconds (All LEDs will flash indicating it is in EDID setup mode) •... - Page 18 AC-SW62-UHD Advanced EDID Management - EDID Table ■...
- Page 19 The unit has been dropped or the housing damaged. ● Warranty If your product does not work properly because of a defect in materials or workmanship, AVProConnect (referred to as “the warrantor”) will, for the length period indicated below, (10) （Parts/Labor...
- Page 20 AC-SW62-UHD ● Warranty Limits and Exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages which occurred in shipment, or failures which are caused...
- Page 21 AC-SW62-UHD Notes: ■...
- Page 22 AC-SW62-UHD Thank you for choosing AVProConnect! Please contact us with any questions, we are happily at your service! A V P r o C o n n e c t 3 5 1 8 N C a s c o A v e n u e ~ S i o u x F a l l s , S D 5 7 1 0 4 1 - 8 7 7 - 8 8 6 - 5 1 1 2 ~ 6 0 5 - 2 7 4 - 6 0 5 5 s u p p o r t @ a v p r o c o n n e c t .
