Summary of Contents for Roadstar PCD-9700
- Page 1 AUDIO VIDEO Instruction manual Bedienungsanleitung Manuel d’instructions Manuale d’istruzioni Manual de instrucciones...
- Page 2 ROADSTAR. Le feMamos y ie dames las gracias por su election de este aparado. Por f&or leer el manual antes de poner en funcionamiento el equip0 y guardar esta nuevamente.
- Page 3 PCD-9700...
- Page 4 II vostro nuovo apparecchio e stato prodotto ed assemblato sotto lo stretto controllo di qualitti ROADSTAR. Vi ringraziamo di aver acquistato un nostro prodotto per il vostro piacere d’ascolto. faction. Prima di pmcedere alhttiliio dell’appamahio, leggete Avant de vous adonner &...
- Page 5 The exclamation point within the triangle is a warning sign alert- ing the user of important instructions accompanying the product. The lightening flash with arrowhead s is a warning sign alerting the user of y angerous voltage” inside the unit. To reduce the risk of electric shock, do not remove the cover.
- Page 6 PCD-9700 Portable CD Player TABLEOFCONTENTS Functions and Controls Power Supply Connections Phones Jack CD Playback Locating a Particular Track or Point of the Track Repeat Playback Intro Random Programmed Playback Special Functions Maintenance Specifications CD DOOR HEADPHONE socket LINE-OUT socket (AUX OUT)
-
Page 7: Power Supply
POWERSUPPLY Use with regular batteries Open the battery compartment door, located on the bottom of the unit, by sliding the door and lift it up. (Do not remove the battery door). . Insert 2 x 15V /UM-3/AA size alkaline batteries, following the correct polarity, as indicated on the unit. -
Page 8: Phones Jack
Cautions: DO NOT mix the rechargeable(Nickel-Cadmium) and regular(Carbon-zinc) batteries. DO NOT charge continuously for 24 hours or more, otherwise it will deteriorate the performance of the rechargeable batteries. DO NOT try to recharge normal (not rechargeable) batteries. They can explode! Notes: If the rechargeable batteries are being charged for the first time, it will take approximately 15 hours to be fully charged. - Page 9 Adjust the VOLUME control to your desired listening level. To stop playback temporarily, press the PLAY/PAUSE ( >II ) button (6) once. The time and track number will flash on the display. Press the PLAY/PAUSE ( >II ) button again to resume playback.
-
Page 10: Random Play
INTRO PLAY Press the PLAY/PAUSE button (6) and after 3 seconds the STOP button (7). Press the PROGRAM button (14) once during playback to enter the Intro mode, IINTRO’ appears on the display. Press the PLAY/PAUSE button, CD will play the first 10 seconds of each track on the CD. Press PLAY/PAUSE button to cancel Intro playback and resume normal playback. -
Page 11: Special Functions
SPECIAL FUNCTIONS Bass Boost Set the BASS BOOST switch to y ON n position to enjoy a more powerful Bass sound. Note: Since Bass Boost performance will change depending on the volume level, sound maybe distorted due to high volume is set. Lower the volume level until the sound quality is improved. - Page 12 Audio D/A conversion l-bit DAC four times oversampling Frequency response Wow and flutter Below measurable limits No. of channels 2 channels (stereo) Output level Line output: 0.6V rms (47KW ) Headphone: 20mW (32W) Bass Boost effect (100Hz) + 6 dB General Power requirements -2 x LR6 / UM-3 / “AA”...
