- Page 1 PCD-9335RMPT...
- Page 2 ITEM Description LOCATION 001-2019D-T80 P.C.B MAIN BOARD 002-0016M-P01 I.C 16M DRAM THIN TYPE IC71 002-08038-000 I.C FAN8038 002-09276-H00 I.C KS9276 "QFP" IC70 002-7000D-D00 I.C LA4533/FAN7000D IC80.150 002-09291-H00 I.C S5L9291 IC60 002-1923F-G07 I.C BU1923F IC120 IC20 002-09226-S01 I.C SIL9226 RF-AMP & RPE-SERVO 002-00520-H00 I.C DSP520R IC100...
- Page 3 ITEM Description LOCATION 010-A0107-000 CHOKE COIL 100uH 3Pin 6x8mm CY68-83 010-A0396-000 CHOKE COIL 39uH 2Pin 4x6mm L3.1 28 011-A220D-200 RESISTOR 22 OHM 1/4W ±5% 011-A471A-200 RESISTOR 470 OHM 1/16W ±5% R138.139.45.30.41.20. 011-B100A-200 RESISTOR CHIP 0 OHM ±5% 0603 143.142.154.137 011-B100A-200 RESISTOR CHIP 10 OHM ±5% 0603 R17.27 011-B101A-200 RESISTOR CHIP 100 OHM ±5% 0603 R9.58.130.67.RR139...
- Page 4 ITEM Description LOCATION 011-B683A-200 RESISTOR CHIP 68K OHM ±5% 0603 R56.60.36 011-B562A-200 RESISTOR CHIP 5.6K OHM ±5% 0603 011-B823A-200 RESISTOR CHIP 82K OHM ±5% 0603 012-6107B-300 ELECT CAP 100uF 10V ±20% 5x5mm 012-4105F-300 ELECT CAP 1uF 50V ±20% 4x5mm E4.5.6.83.84 012-4106B-300 ELECT CAP 10uF 10V ±20% 4x5mm E10.12.110.91...
- Page 5 ITEM Description LOCATION 83 014-B471C-500 CHIP CER. CAP 470PF 50V ±10% 0603 C7.24 84 014-B472C-500 CHIP CER. CAP 0.0047uF 50V ±10% 0603 85 014-B473C-500 CHIP CER. CAP 0.047uF 50V ±10% 0603 86 014-B474C-500 CHIP CER. CAP 0.47uF 50V ±10% 0603 C46.67.68 87 014-B682C-500 CHIP CER.
- Page 6 ITEM Description LOCATION 112 002-06523-H00 I.C PT6523LQ IC200 113 004-04148-S00 CHIP DIODE CD4148 0805 D200 114 008-07860-C00 LCD DISPLAY （TTD7860DPRDCN） 115 011-B102A-200 RESISTOR CHIP 1K OHM ±5% 0603 R213 116 011-B472A-200 RESISTOR CHIP 4.7K OHM ±5% 0603 R217 117 011-B152A-200 RESISTOR CHIP 1.5K OHM ±5% 0603 R214 118 011-B331A-200 RESISTOR CHIP 330 OHM ±5% 0603 R211...
- Page 7 ITEM Description LOCATION 141 234-KB017-03B SCREW KB 1.7x3 Black 12 FOR KEY 142 234-KM020-03B SCREW KM 2x3 BLACK FOR KEY:4 143 225-10020-A00 LAMP BUSHING 144 225-00068-100 Rubber Sponge D=6.8x1mm 145 301-0C067-080 POLYBAG 6-3/4x8"T=0.04mm 146 303-2008A-A10 POLYFOAM 147 304-2069A-A10 GIFT BOX 148 305-2069A-A10 INSTRUCTION MANUAL 149 306-20690-A10 CARTON 1/10 150 307-CD020-A00 CD PAPER CARD FOR CD...
