Martec PRINCE MPAPP Operation And Installation Instructions

MARTEC PRINCE CEILING FAN REMOTE CONTROLLER OPERATION AND
INSTALLATION INSTRUCTIONS (MPAPP)

IMPORTANT

1. Read and save these instructions.
2. Please note that all fixed wiring appliances must be installed by a qualified electrician.
3. The supply to the remote-control receiver must be connected through a mains switch, i.e. existing wall
switch, to isolate the power.
4. Disconnect from power supply at wall switch before working on remote control receiver or ceiling fan.
5. Install receiver into the ceiling fan canopy of the fan to ensure proper protection (Do not install in ceiling
cavity as this will void warranty).
6. This unit is to be used for the control of a ceiling fan with a AC230/240V 50Hz power supply only.
7. Do not install in damp locations or immerse into water (For indoor use only).
8. Do not pull on or cut leads shorter.
9. Do not drop or bump the unit.
10. Please ensure plugs are in the correct position i.e. AC power input to the AC power and to the fan output
of the fan. If in the incorrect position, receiver will be damaged, and will not be covered under warranty.
11. PLEASE NOTE: The battery will weaken with age and should be replaced regularly before leaking takes
place as this will damage the transmitter. Dispose of used battery properly, keep the battery out of reach
of children. Leaking batteries are not covered under warranty.
12. CAUTION: To reduce the risk of fire or injury, do not use this product in conjunction with any variable (rheostat)
wall control.

INSTALLATION INSTRUCTIONS

CAUTION! INCORRECT WIRE CONNECTION WILL DAMAGE THIS RECEIVER. PLEASE ENSURE 240V
IS TO INPUT AND MAKE SURE POWER IS COMPLETELY OFF WHEN INSTALLING THE RECIEVER
UNIT OR A VOLTAGE SURGE MAY BLOW THE CIRCUIT BOARD.
www.martecaustralia.com.au | 02 8778 7500 | sales@martecltd.com.au
Once the connection has been made,
the receiver inserts into the drop rod
hanging bracket. The canopy comes up
to cover the receiver and bracket.
CAUTION
: When putting canopy of
the fan onto mounting bracket, please
ensure that wires are completely tucked
away to avoid canopy rupturing the
wires and causing a short circuit.
