Neon HFX-50 Instruction Manual

Cd hifi system
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTION MANUAL
HFX-50
CD HIFI SYSTEM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HFX-50 and is the answer not in the manual?

Questions and answers

Related Manuals for Neon HFX-50

Summary of Contents for Neon HFX-50

  • Page 1 INSTRUCTION MANUAL HFX-50 CD HIFI SYSTEM...

  • Page 2: Table Of Contents

    Table of Contents Safety Warnings ..............................3 Battery Safety Guidelines ..........................5 Pack Contents..............................6 Product Overview .............................. 7 Remote Control Overview ..........................8 Installation of Battery ..................................9 Handling the Remote Control..............................9 Remote Control Operation Range ............................10 Connections ...............................10 Connect to the FM Antenna ..............................10 Connecting the Headphone ...............................11 Connecting the AC/DC Adaptor ..............................11 ECO Power/Standby Features ........................12...
  • Page 3 To Select Album (For MP3/WMA discs) ..........................16 Playing Repeatedly ..................................16 Text Display During Playback ..............................16 Use the USB ..............................17 Access a folder ....................................17 Charge your device ..................................17 About NFC .................................18 Play from Bluetooth device ..........................18 Setting the Daily on Timer ..........................19 Setting the Sleep Timer ............................19 Activate the sleep timer ................................19 To deactivate sleep timer ................................19...

  • Page 4: Safety Warnings

    Safety Warnings - Read all the instructions carefully before using the unit and keep them for future reference. - Retain the manual. If you pass the unit onto a third party make sure to include this manual. Dame - Please inspect the unit for damage after unpacking. - Do not continue to operate the unit if you are in any doubt about it working normally, or if it is damaged in any way - switch off, withdraw the mains plug and consult your dealer.
  • Page 5 Batteries - Batteries used in the remote control for this unit are easily swallowed by young children and this is dangerous. - Keep loose batteries away from young children and make sure that the battery holder tray is secure in the remote control. Seek medical advice if you believe a cell has been swallowed. - Please dispose of batteries correctly by following the guidance in this manual.

  • Page 6: Battery Safety Guidelines

    Used correctly, domestic batteries are a safe and dependable source of portable power. Problems can occur if they are misused or abused — resulting in leakage or, in extreme cases, fire or explosion.Here are some simple guidelines to safe battery use designed to eliminate any such problems.

  • Page 7: Pack Contents

    Pack Contents Make sure all of the following contents are included. OPTICAL REPEAT RANDOM INFO The Unit Remote Control FM Antenna (battery included) In s t ru c t io n M a n u a l Audio Cable AC/DC Adaptor Instruction Manual - 6 -...

  • Page 8: Product Overview

    Product Overview 1. Source Button 10. Remote Sensor 2. Standby Button 11. LCD Display Lens 3. Disc Tray 12. Volume Control Knob ( VOLUME 4. Play/Pause Button ( 13. Headphone Jack ( ) Tuning Forward Button ( 14. Next Button ( Paring Button ( Long press: Search Forward Button ( 5.

  • Page 9: Remote Control Overview

    Remote Control Overview Intro Button ( 1. Standby Button ( ) INTRO Loudness Button ( 2. CD Function Button ( LOUDNESS Preset Equalizer Button ( 3. Tuner Function Button ( P-EQ Clock Button ( 4. Repeat Button ( CLOCK REPEAT Next Button ( ) Stereo/mono Select Button ( REPEAT...

  • Page 10: Installation Of Battery

    Installation of Battery The first use of remote control, remote control to activate the battery piece remove protection! It is located at the bottom back side of the remote control. Replace remote control battery 1. Loosen the screw on the battery compartment cover with a screwdriver.

  • Page 11: Remote Control Operation Range

    Remote Control Operation Range Point the remote control to the unit no more than 6 meters from the remote control sensor and within 60° horizontally and 40° vertically of the front of the unit. The operating distance may vary according to the brightness of the room. Note: • Make sure that there is no obstacle between the infrared remote sensor of the unit and remote control.

  • Page 12: Connecting The Headphone

    2. If reception is poor, connect the outside antenna. Note: Before attaching a 75 ohm coaxial lead (the kind with a round wire going to an outside antenna), disconnect the supplied FM wire antenna. Caution: To avoid noise, keep antennas away from the system, the connecting cord and the AC power cord.

  • Page 13: Eco Power/Standby Features

    ECO Power/Standby Features Switching ON / OFF When you first connect the unit to the DC Jack, the unit will be in standby mode. • Press the button to switch the unit on. The “HELLO” will show in the display. • Press the button to switch the unit back to standby mode.

  • Page 14: Sound Quality

    Sound Quality Adjusting the Volume To increase or decrease the volume, rotate the knob on the unit or press the VOLUME VOL +/- buttons on the remote control. Mute sound You can mute the sound temporarily. During play, press the button to mute or unmute sound.

  • Page 15: Listening To Radio Broadcasts

    Listening to Radio Broadcasts Caution: Before listening to the radio, please check that the FM Antenna is correctly connected and adjusted for length and direction. Tuning in to a Station 1. Repeatedly press the button on the unit or directly press the button on the SOURCE remote control to select tuner source.

  • Page 16: To Change The Fm Reception Mode

    To change the FM Reception Mode Press the button to select the Stereo or Mono channel to receive the best FM reception REPEAT mode. CD Operation CD Playing 1. Repeatedly press the button on the unit or directly press the button on the SOURCE remote control to select the disc source.

  • Page 17: Playing The Beginning (Intro) Of Each Track

    6. Press the button to start programme play. 7. Press the button once to stop the programme play. Press the button twice to clear programme. Playing the Beginning (Intro) of each Track Press the button on the remote control to play the beginning of each track consecutively. INTRO The playing time of each track is 10 seconds, then the first track is playing automatically.

  • Page 18: Use The Usb

    Use the USB 1. Insert the USB device's USB plug into the socket on the unit. 2. Repeatedly press the button on the unit or button on the remote SOURCE OPTICAL control to select the USB source. The word “USB” will be displayed on the LCD. 3.

  • Page 19: About Nfc

    3. Activate the Bluetooth function in your Bluetooth device (see the device user manual). 4. Select "HFX-50" on your device for pairing. - For elder devices, you need to input “0000” as pairing password.

  • Page 20: Setting The Daily On Timer

    Setting the Daily on Timer Caution: Make sure that you have set the clock correctly. 1. In standby mode, long pressing the button on the remote control, until [TIMER SET] TIMER scrolls on the LCD. Then the source is displayed, e.g. DISC. Note: If the clock is not set, the “SET CLOCK FIRST”...

  • Page 21: Listen To An External Device

    Listen to an external device 1. Connect the AUX IN terminals on the rear of the unit to the line output terminals on the auxiliary equipment with an audio cable. 2. Repeatedly press the button on the unit or button on the remote control to SOURCE select AUX IN source.

  • Page 22: Specifications

    Specifications Main unit Power requirements ..................100-240V~ 50/60Hz 1.5A Max. Adaptor Model No........................S060A1603000U Adaptor Vendor ..............................BP Adaptor Output ..........................16V Output power (@10% THD) ....................25 W x 2 RMS Frequency Response ........................20-20000Hz Tweeter Speaker Impedance ........................8 Ω x 2 Woofer Speaker Impedance .........................4 Ω...

  • Page 23: Maintenance

    Maintenance Cleaning the Unit Note: Ensure the unit is fully unplugged from the mains socket before cleaning. - To clean the unit, wipe the case with a slightly moist, lint-free cloth. - Do not use any cleaning fluids containing alcohol, ammonia or abrasives. - Do not spray an aerosol at or near the unit.

  • Page 24: Troubleshooting

    Troubleshooting If you are having a problem with your unit, check this list for a possible solution before calling for service. If you cannot solve the problem from the hints given here, or the unit has been physically dam- aged, call a qualified person, such as your dealer, for service. No power - Check that the speakers are connected correctly.
  • Page 25 Music playback is unavailable on this the device to find out how to enable the unit even after successful Bluetooth function. connection. - This unit is not in pairing mode. - This unit is already connected with - The device cannot be used to play music another Bluetooth-enabled device.
  • Page 26 Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
