Roger Access Control System
XM-6DR Output expander
Operating Manual
Firmware version: 1.0.0
Hardware version: 1.1
Document version: Rev. F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XM-6DR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Roger XM-6DR

  • Page 1 Roger Access Control System XM-6DR Output expander Operating Manual Firmware version: 1.0.0 Hardware version: 1.1 Document version: Rev. F...
  • Page 2 1. D ESCRIPTION AND SPECIFICATION The XM-6DR is output expander with 6 relay outputs with single NO contact each. The module is addressable and it is dedicated to HRC series controllers.Currently the XM-6DR expander is available only in plastic enclosure for installation on DIN 35 mm rail.
  • Page 3: Led Indicators

    Fig. 2 Connection of XM-6DR expander with HRC402DR controller 2.2 LED indicators XM-6DR is equipped with two LED indicators i.e. LED Link and LED Power. LED Link signals the communication between expander and master device (controller) while LED Power can signal 4 states according to table.
  • Page 4: Power Supply

    2.3 Power supply The XM-6DR requires 12VDC nominal power supply. If the voltage is below ~10V then the module stops its operation, deactivates all relays and signals the error by means of LED Power indicator (blinks 10 times per second).
  • Page 5: Firmware Update

    The restart can be done by means of RESET button or power supply switch off and on. The address of XM-6DR can be programmed by means of jumpers based on their values e.g. jumpers on pins JP1 and JP3 signify the address ID=5 (1+4 = 5) while jumpers on all JP1…JP4 pins signify ID=15 (1+2+4+8 = 15).
  • Page 6 XM-6DR Operating Manual.doc 2017-04-21 Table 5. Connection of XM-6DR and RUD-1 XM-6DR terminal RUD-1 terminal +12V 4. O RDERING INFORMATION Product Description XM-6DR Input/Output addressable expander module with enclosure for installation on DIN 35mm rail. 5. P RODUCT HISTORY Version...
