- Page 1 Your Installation Guide For The CR500 MID Tower CASE...
- Page 3 Congratulations you are on your way to build the perfect gaming machine...
-
Page 5: Table Of Contents
Contents Chapter 1: Before You Begin - What is in the box - Product Details - Before You Begin Chapter 2: Ready, Setup, Go - Removing the Side Panel - Install the Motherboard - Install Hard Drives and SSDs - Install Drives to 2.5” Mounts - Attaching Cables - Attaching the Case Fan Cables - Fan Mounting Point and Water Cooling Support... - Page 6 USB 3.0 and multiple SSD/HDD bays. Note: This manual is a guide for RIOTORO’s CR500. For instructions on installing the motherboard and other components, please refer to their documentation.
-
Page 7: Chapter 1: Before You Begin
Before You Begin www.riotoro.com/cases... -
Page 8: What Is In The Box
CR500 Mid-Tower Case What’s in the Box CR500 Included Hardware 2x standoff screws 19x #6 screws 11x PWM screws 7x thumb screws 6x nylon ties Chapter 1 Before You Begin... -
Page 9: Product Details
CR500 Mid-Tower Case Product Details 1) Front Panel: - 2x USB 3.0 ports - Microphone jack - Headphone jacks - Power switch - Reset switch - Hard Disk Drive LED Chapter 1 Before You Begin... - Page 10 CR500 Mid-Tower Case Product Details 4) Fans & Fan/Rad Mounts 5) Motherboard Tray Cutout 6) Power Supply Bay 7) 2.5” Tool-less Drive Bays 8) 2.5” Tool-less Drive Bays 9) Radiator Mounts Chapter 1 Before You Begin...
-
Page 11: Before You Begin
CR500 Mid-Tower Case Before You Begin Please take the following precautions: - Handle all PC components and cards with care. - Hold cards and processors by their edges to avoid damaging compo- nents. - To avoid damaging components by electrostatic discharge, periodically ground yourself by touching an unpainted metal surface or by using a wrist grounding strap. - Page 12 CR500 Mid-Tower Case Before You Begin When routing cables Route and bundle PSU and case cables to reduce clutter for a cleaner look and to improve airflow. The case is designed with cable pass-through cutouts throughout and space to conceal cables under the right side panel (as seen from the front).
-
Page 13: Chapter 2: Ready, Setup, Go
Ready, Setup, Go www.riotoro.com/cases Chapter 1 Before You Begin... - Page 14 CR500 Mid-Tower Case Remove the Case Side Panels Put the case upright on a stable, flat surface with rear facing you. Remove the thumbscrews from both side panels and store them in a safe place. Remove the panel Remove the panel...
-
Page 15: Install The Motherboard
CR500 Mid-Tower Case Install the Motherboard The CR500 is compatible with motherboards up to ATX, Micro ATX, and Mini-ITX. Chapter 2 Ready, Setup, Go... - Page 16 CR500 Mid-Tower Case Install the Motherboard Install the CPU, CPU cooler and memory on the motherboard. Refer to your CPU and motherboard documentation how to mount the CPU and its cooler on your motherboard. If you are using a liquid CPU cooler you may find it easier to install it after the motherboard is installed in the case.
- Page 17 CR500 Mid-Tower Case Install the Motherboard Install the I/O shield Your motherboard should have come with a standard I/O shield that exposes the rear motherboard connectors out of the back of the case. From inside, snap the I/O shield into the cutout in the rear of the case.
- Page 18 CR500 Mid-Tower Case Install the Motherboard Attach the motherboard to the case. The CR500 comes with pre-installed standoff screws and includes extras if you need to add them. Slide the motherboard into the I/O shield and then align the motherboards screw holes with the case standoff. Attach the motherboard to the standoffs with the provided motherboard screws.
- Page 19 CR500 Mid-Tower Case Install HDD & SSD The 3.5" drive cage located at the bottom of the CR500 and holds two removable 3.5" drive trays. The drive trays require no tools to mount 3.5" drives. The trays can also be used to mount 2.5" SSD with screws.
- Page 20 CR500 Mid-Tower Case Installing Drives into the 2.5” Mounts The CR500 has two dedicated tool-free mounts for 2.5” solid state drives (SSD) located on side of the case. Instructions: - Place the 2.5” drives into each of the brackets by aligning the drive pins with the bracket pins.
-
Page 21: Attaching Cables
CR500 Mid-Tower Case Attaching Cables Connect the Front Panel Switches and LEDs The CR500 front panel switches, LEDs, and USB ports have wire leads that need to be attached to header pins the motherboard. Refer to your motherboard manual to locate the proper motherboard header pins and attach the cable connectors listed below. -
Page 22: Attaching The Case Fan Cables
CR500 Mid-Tower Case Attaching the Case Fan Cables The CR500 Comes with two fans: a front LED intake 120mm fan and a rear exhaust fan. Tips: - CR500 includes mounts for two more 120mm fans at the front. Note: The CR500 includes mounts for several 120/140mm fans – 3x 120 or 2x 140mm Fans on the front,. -
Page 23: Fan Mounting Point And Water Cooling Support
Tips: - Screws and rubber grommets are provided in the accessory box to allow you to add optional fans and radiators. - RIOTORO recommends Bifrost 120ti as a perfect water cooling companion for the CR500. Chapter 2 Ready, Setup, Go... -
Page 24: Install The Power Supply
- Align the PSU and case mounting holes and attach the power supply to the case with the provided PSU thumbscrews. - Connect the relevant PSU cables to your motherboard and drives. (In larger Modular PSU’s RIOTORO recommends to install the modular cables before installing the PSU into the case.) 85 mm... -
Page 25: Troubleshoot Your New Cr500
CR500 Mid-Tower Case Troubleshooting Your New CR500 The Front panel LED for Power and HDD activity does not lit. The polarity of the LED cables matter, and they are not connected as they should (inverted polarity), connect the positive cable marked as “+” to the right mother- board “+”... - Page 26 CR500 Mid-Tower Case Notes Chapter 2 Ready, Setup, Go...
-
Page 27: Chapter 3: Specifications
Specifications... -
Page 28: Specifications
CR500 Mid-Tower Case Specifications Motherboard Support - ATX, Micro ATX, Mini-ITX Drive Bays - 2x 3.5”or 2.5” (Convertible) - 2x 2.5” (Native) Front Panel I/O - 1x USB 3.0 Ports - 2x USB 2.0 Ports - 1x Headphone - 1x Microphone... - Page 29 CR500 Mid-Tower Case Specifications Fan/Radiator Mount Points - Front: 1x 120mm or 1x 240mm - Back: 1x 120mm PSU Support - ATX up to 180mm Max. GPU Length - 320mm (Front w/o WC) Materials - Steel, Plastic, Tempered Glass Dimensions - 17.1 x 8.1 x 17.8in /...
-
Page 30: Recommended Parts
CR500 MID TOWER Recommended Parts P O W E R S U P P L Y U N I T ENIGMA 850W: Unleash your gaming computer potential with the high efficiency and power of ENIGMA power supplies. The large built-in fan prevents it from overheating during heavy use, and the sturdy construction makes it easy to mount. - Page 31 CR500 MID TOWER Recommended Parts W A T E R C O O L I N G R G B F A N The BiFrost 120ti new generation water-cooling solution: The BiFrost 120ti a new generation water cooling solution for both AMD and Intel platforms.
-
Page 32: Recommended Peripherals
CR500 MID TOWER Recommended Peripherals G A M I N G M I C E G A M I N G K E Y B O A R D The URUZ Z5: It delivers precise tracking complimented by professional Design. The URUZ Z5 offers on-the-fly DPI adjustments up to 4,000 DPI, Multicolor RGB Customizable Back-lighting up to 16.8 million different... -
Page 33: Chapter 4: Everything Else
Everything Else... -
Page 34: Important Safety Information
CR500 MID TOWER Important Safety Information In order to achieve maximum safety while using your CR500 MID TOWER, we suggest that you adopt the following guidelines: - Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the RIOTORO hotline or go to www.riotoro.com for support. -
Page 35: General Maintenance
CR500 MID TOWER General Maintenance If you need to clean your gaming computer by doing more than wiping it down with a clean cloth, follow these instructions: - Complete power down of your machine, display and peripherals. - Disconnect all the power cables from the electrical outlet power strip. -
Page 36: Limited Product Warranty ("Limited Warranty")
CR500 MID TOWER LIMITED PRODUCT WARRANTY ("Limited Warranty") Limited Warranty. RIOTORO warrants the Product to be free from defects in materials and workmanship when used normally in accordance with the official documentation for the applicable Warranty Period from the date of retail purchase. - Page 37 Technical Support and Customer Service US & Canada 1-888- 270-7090 support@riotoro.com customerservice@riotoro.com sales@riotoro.com © Copyright 2017 RIOTORO. All rights reserved. All trademarks are the property of their respective owners. Reproduction in whole or part without written permission is prohibited.
- Page 38 © 2017 RIOTORO Inc. All rights reserved. RIOTORO, the RIOTORO logo and CR500 are trademarks of RIOTORO Inc., Registered in the U.S. and other countries. All other trademarks are the property of their respective owners. Product may vary slightly from those pictured.
- Page 40 www.riotoro.com...
