BASIC SYSTEM COMPONENTS

1.
1.1. Because each installation is different, your system may or may not contain these basic components.
1.2. Ensure all components listed are present prior to assembly.
1.3. NOTE: Items not shown actual size.
PATHWAY 3G UNIVERSAL GATE
(QTY 1)
1/4" -20 LOCKNUT (QTY 3)
1-1/2" DIAMETER TUBE PLUG
(QTY 4)
5/16"-18 X 3/4" HEX BOLT
(QTY 2)
Used for Pathway Modular Stair
installation only
1/4"-20 X 2" LONG HEX CAP SCREW
(QTY 3)
1/4" FENDER WASHER (QTY 6)
5/16"-18 X 5" HEX BOLT
(QTY 1)
Used for Pathway Modular Stair
installation only
5/16"-18 LOCKNUT
(QTY 2)
Used for Pathway Modular Stair
installation only
- 3 -
#8-32 X 1/2" LONG HEX WASHER
HEAD THREAD CUTTING SCREW
(QTY 7)
GRAVITY LATCH (QTY 1)
Includes Latch & Latch Bar
1/4"-20 X 3/4" HEX BOLT
(QTY 3)
Used for Pathway Modular Stair
installation only
PATHWAY STAIR TO GATE
MOUNTING ADAPTER (QTY 1)
Used for Pathway Modular Stair
installation only
