Assembly Manual
Pathway® Modular Gate
For use with the Pathway® 3G Modular Ramp and Pathway Stair System
Gate shown on Pathway 3G Modular Ramp
Gate shown on Pathway Stair System
Click here to view detailed product descriptions and
prices.
Call 800-397-5899 to order today!
LIFETIME WARRANTY. Please register at www.ezaccess.com/warranty-satisfaction.
®
© EZ-ACCESS
, a division of Homecare Products, Inc. All rights reserved.
All text and images contained in this document are proprietary and may not be shared, modified,
17025 04-03-17
distributed, reproduced, or reused without the express written permission of EZ-ACCESS.
Advertisement
Related Manuals for EZ-ACCESS Pathway Modular Gate
Summary of Contents for EZ-ACCESS Pathway Modular Gate
- Page 1 © EZ-ACCESS , a division of Homecare Products, Inc. All rights reserved. All text and images contained in this document are proprietary and may not be shared, modified, 17025 04-03-17 distributed, reproduced, or reused without the express written permission of EZ-ACCESS.
-
Page 2: Installation Table Of Contents
INTRODUCTION ® The Pathway 3G Modular Gate is universal and can be installed on a Pathway 3G Modular Ramp system or at the top of a Pathway Stair System. Hinge can be installed on left or right. Before starting installation, determine which side of the ramp or stair the hinge should be on and which direction the gate should swing based on the specific installation and the end user’s desired placement. -
Page 3: Basic System Components
BASIC SYSTEM COMPONENTS 1.1. Because each installation is different, your system may or may not contain these basic components. 1.2. Ensure all components listed are present prior to assembly. 1.3. NOTE: Items not shown actual size. #8-32 X 1/2” LONG HEX WASHER 1/4”-20 X 2”... -
Page 4: Getting Started
GETTING STARTED Install the 1-1/2” diameter tube plugs into ends of the 1-1/2” diameter tubes on the gate. Use a rubber 2.1. mallet to tap plugs into place until fully engaged (FIG. 1). FIG. 1 INSTALLING GATE ON A RAMP 3.1. - Page 5 Attach the gate to the ramp post using the 1/4”-20 x 2” long hex cap screws, 1/4”-20 locknuts and 1/4” 3.3. fender washers. Orient the hex cap screws with the head on the hinge side of the post and the washers (FIG.
- Page 6 3.8. Hold the latch so it is centered on the ramp handrail post opposite the post where the gate is installed and on the outswing side of the gate then align the catch with the latch bar. While holding the latch in place, open and close the gate a few times to confirm the catch is working correctly and reposition up or down if needed.
- Page 7 FIG. 6 Attach the gate to the Pathway Stair to Gate Mounting Adapter using the three 1/4”-20 x 3/4” long hex 4.4. bolt, 1/4”-20 locknuts and 1/4” fender washers. Orient the hex bolts with the head on the hinge side of the adapter and fender washers under the bolt heads and the locknuts as shown (FIG.
- Page 8 4.7. Hold the latch so it is centered on the stair post opposite the hinge and on the outswing side of the gate then align the catch with the bolt installed in the previous step. While holding the latch in place, open and close the gate a few times to confirm the catch is working correctly and reposition up or down if needed.
- Page 9 CONNECTING A STAIR POST TO A PLATFORM POST 5.1. Assemble stair and mount to platform in desired location as described in the Pathway Stair Assembly Manual. Assemble gate to stair using closure elbows instead of the 5/16” locknuts (see Section 4). 5.2.
- Page 10 Cut the 1-1/2″ diameter round tubes to fit the gap measured in the previous step. 5.5. 5.6. Using a metal file, smooth all sharp edges from cutting the round tubes. 5.7. Disassemble the closure elbows by removing the elbow screws and nuts but do not remove the closure elbows halves from the platform post or stair top post (FIG.
