Performance Tool W54032 Owner's Manual

PARTS LIST
No. Description
1 Pan Head Machine Screw - 1/4" x 1-1/2"
2 1/4" Nut
3 Pan Head Machine Screw - 5/16" x 2"
4 5/16" Nut
5 Top Shelf
6 Bottom Shelf
7 Tool Drawer
8 Vertical Support Bracket
9 Horizontal Brace
10 Pan Head Machine Screw- 5/16" x 1-3/4"
11 5/16" Nut
12 Caster
13 Side Brace
14 Vertical Support Column
Note: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
5
9
10
1
14
13
3
12
WarNING: This product and its packaging contain a chemical known to the State of California to
cause cancer, birth defects or other reproductive harm.
Always wear eye protection when using tools.
7
8
6
14
Compact Mechanic's Shop Cart
Qty.
12
Stock Number W54032
12
8
8
1
1
1
4
1
4
4
4
2
4
SPECIFICATIONS
Caster Assembly:
Top Shelf:
........................................................................
Bottom Shelf:
Tool Drawer:
Maximum Weight Capacity
Bottom Shelf:
Top Shelf: ....................................................................... 30 lbs. (evenly distributed)

For your saFety,

please read these instructions carefully and retain them for future use.
OWNER'S MANUAL
(4) Swivel Casters, 2-1/2" diameter
............................................
.......................................................................
................................................................................
..............................................................
23-1/2" x 16-1/2" x 1-1/2"
23-1/2" x 16-1/2" x 2"
18" x 14-1/2" x 2"
100 lbs. (evenly distributed)
