PolyJohn Applause SK3-3000 Operation & Maintenance Manual

Wash station with water hookups

Advertisement

Quick Links

Color Options
• Granite Gray
• Tan
NOTE: All dimensions are subject to change due to environmental factors.
POLYJOHN
USA
PolyJohn Enterprises Corp
2500 Gaspar Ave.
Whiting, IN 46394
Phone: 800-292-1305
Fax: 219-659-0625
www.polyjohn.com
info@polyjohn.com
We recommend reading through the entire booklet prior to proceeding with installation, service or
maintenance. All references to left and right throughout this guide are as viewed from the front.
SK3 Applause™ 3000
Wash Station with Water Hookups
Operations & Maintenance Guide
POLYJOHN
WORLDWIDE
PolyJohn (UK) Ltd.
Equinox 1 Audby Lane
Wetherby, England LS22 7RD
Phone: 44 (0) 1937-583333
Fax: 44 (0) 1937-583322
www.polyjohn.co.uk
sales@polyjohn.co.uk
SK3-3 Guide - July 2009
Page 1 of 8

SPECIFICATIONS

Dimension
Imperial Metric
Height
Width
Depth
Weight
Capacity
Pump Capacity
(per stroke)
Number of Single
Dispenses
Paper Towel
Capacity
Soap Dispenser
Capacity
All materials, including resin, pigments and additives
used to make the plastic components as well as the
plumbing components that come in contact with the
fresh water are U.S. FDA food grade compliant.
PolyJohn Canada
199 Forest Plain Rd.
Orillia, Ontario LV3 6S2
Phone: 800-465-9590
Fax: 705-325-8250
www.polyjohncanada.ca
info@polyjohncanada.ca
47.5 in
121 cm
50.5 in
128 cm
21.7 in
55 cm
80 lb
36 kg
60 gal
227 L
2 fl oz
59.14 ml
3840
3840
1000
(4 pks-Georgia Pacifi c 23504)
or (2 rolls-Baywest Ecosoft 46200)
30 fl oz
887 ml
POLYJOHN
CANADA
P.O. Box 2300

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Applause SK3-3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PolyJohn Applause SK3-3000

  • Page 1: Specifications

    U.S. FDA food grade compliant. NOTE: All dimensions are subject to change due to environmental factors. POLYJOHN POLYJOHN POLYJOHN WORLDWIDE CANADA PolyJohn Enterprises Corp PolyJohn (UK) Ltd. PolyJohn Canada 2500 Gaspar Ave. Equinox 1 Audby Lane P.O. Box 2300 Whiting, IN 46394 Wetherby, England LS22 7RD 199 Forest Plain Rd.
  • Page 2: General Product Overview

    General Product Overview This is a uniquely designed two-station “Water-Mains Hookup Sink”. The sink must be hooked up to a fresh water source as well as a drain for gray water. The sink is designed to hold a small amount of fresh water in the tank. The amount of water is controlled with a fl oat operated valve.
  • Page 3: Operations Information

    Operations Information Fresh Water Plumbing The plumbing system in this sink is simple and requires minimal maintenance. If the system becomes plugged, fi rst check the foot pumps. Depress each foot pump and observe the level of resistance. If there is resistance and water is not dispensed, there is most likely an obstruction in the tube or at the orifi ce of the water spigot.
  • Page 4 Part Replacement Information ~~TOOLS REQUIRED~~ • Drill with 9/64” and 13/64” bits • Rivet Gun • Standard slotted screw driver • Channel Locks Spigot Replacement To replace the spigots, open the hinged lid and from the underside of the bowl, drill out the (2) PC-000104 - Rivets.
  • Page 5 Conversion from Water-Mains Hookup to Stand-alone Optional - SK3-3250 / Bag Complete Mains Conversion Step 1. Remove the towel chutes from the trash bag holders and release the latch locks. Step 2. Under the sink bowl loosen the PC-000351 - #10 Hose Clamps and remove the hoses from the elbows.
  • Page 6: Parts Drawing

    Parts Drawing SK3-3 Guide - July 2009 Page 6 of 8...
  • Page 7: Exploded View

    - Exploded View SK3-3 Guide - July 2009 Page 7 of 8...
  • Page 8: Cleaning And Maintenance

    800-822-3020 / 612-854-8300 FAX 612-854-7560 www.psai.org MISSION STATEMENT “PolyJohn is a family owned, state of the art, plastics manufacturing company dedicated to providing its employees with a work environment committed to excellence, and its customers with innovative products, services and technology that meet or exceed their requirements.
