- Page 1 Table of Contents Snow Pusher SPL0548 & SPL0560 39713 SPL0560 39546 SPL0560 Shown With Pull Back Option 303-454M Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception.
- Page 2 Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you, or the dealer, have added Options not originally ordered with the machine, or removed Options that were originally ordered, the weights and measurements are no longer accurate for your machine.
-
Page 3: Table Of Contents
Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future. -
Page 5: Important Safety Information
Download the appropriate App on your Refer to Parts Manual QR smart phone, open the App, point your Locator on this page for phone on the QR code and take a picture. detailed instructions. 9/07/16 SPL0548 & SPL0560 Snow Pusher 303-454M... - Page 6 Remove all tools and unused parts permit turning. Disconnect battery ground cable (-) from equipment before operation. Do not use safety chain for towing. before servicing or adjusting electrical systems or before welding on attachment. SPL0548 & SPL0560 Snow Pusher 303-454M 9/07/16...
- Page 7 Never allow children to operate and machine overturn. signals are recommended machinery. whenever driving on public roads. Wear protective equipment such as a hard hat, safety shoes, safety glasses, and ear plugs. 9/07/16 SPL0548 & SPL0560 Snow Pusher 303-454M...
-
Page 8: Safety Labels
Peel backing from label and press label firmly onto the damaged or missing labels. Order new labels from your surface. nearest Land Pride dealer. To find your nearest dealer, visit our dealer locator at www.landpride.com. Squeeze out air bubbles with edge of a credit card or with a similar type of straight edge. -
Page 9: Introduction
Table of Contents Introduction Introduction Land Pride welcomes you to the growing family of new NOTE: A special point of information that the product owners. operator should be aware of before continuing. This Snow Pusher has been designed with care and built by skilled workers using quality materials. -
Page 10: Section 1: Options & Accessory Set-Up
Refer to “Hook-up With BX Quick Hitch” on page 9 3. Park tractor and attachment on level, solid ground. or “Hook-up Without BX Quick Hitch” on page 10. 4. Lower attachment to ground or onto support blocks. SPL0548 & SPL0560 Snow Pusher 303-454M 9/07/16... -
Page 11: Pull Back (Optional)
Pull Back (Optional) 39714 Refer to Figure 1-2: Land Pride offers an optional pull back (#2). It is shipped complete with mounting hardware (#3, #4, #5, & #6). This kit will allow operator to pull snow away from garage doors and other objects while backing up. See Figure 1-2 for part numbers and descriptions. -
Page 12: Steel Blade (Optional)
Section 1: Options & Accessory Set-up Steel Blade (Optional) 39715 Refer to Figure 1-4: Land Pride offers optional steel blade kits complete with mounting hardware. See Figure 1-4 for part numbers and descriptions. IMPORTANT: Steel blades are not designed to move soil, rock, and other compacted surfaces. -
Page 13: Hook-Up With Bx Quick Hitch
9. Replace hitch pins (#3B) in quick hitch bushings (#4) 6. Shut tractor down properly. Refer to “Tractor and secure with retaining pins (#3A). Shutdown Procedures” on page 6 without lowering attachment to ground. 9/07/16 SPL0548 & SPL0560 Snow Pusher 303-454M... -
Page 14: Hook-Up Without Bx Quick Hitch
KIT, BX LOADER DIRECT PIN Land Pride’s “BX Direct Pin Accessory Kit” is required when hooking Snow Pusher directly to the front loader arms. See your nearest Land Pride dealer to order this kit. SPL0548 & SPL0560 Snow Pusher 303-454M... -
Page 15: Unhook Without Bx Quick Hitch
10. Secure lower hitch pins (#1) with hairpin cotters (#5). 11. Secure center hitch pin (#2) with bolt (#3) and lock nut (#4). Screw-on lock nut only 3 or 4 full turns. 9/07/16 SPL0548 & SPL0560 Snow Pusher 303-454M... -
Page 16: Section 2: Operating Procedures
Keep away from electrical power lines. Place an orange condition before operating the attachment. warning sign under overhead power lines indicating type of danger above. Electrocution is often fatal. SPL0548 & SPL0560 Snow Pusher 303-454M 9/07/16... -
Page 17: Transporting
Once you have familiarized yourself with the Operator’s Manual, completed the operating checklist, and properly WARNING attached your Land Pride Snow Pusher to your tractor When traveling on public roads, use accessory lights, SMV loader, you are about ready to begin work. The Snow... -
Page 18: Section 3: Maintenance
WARNING WARNING Do not alter Land Pride equipment or replace parts with other brands. Doing so can cause equipment to perform improperly To avoid serious injury or death, always secure underside of and may lead to breakage causing bodily injury or death. -
Page 19: Steel Blade (Optional)
2. Attach new steel blade (#3) as shown with 1/2"-13 x 1 1/2" GR5 plow bolts (#1) and hex whiz nuts (#2). 3. Center blade (#3) between the side panels and tighten hex whiz nuts (#2) to the correct torque. 9/07/16 SPL0548 & SPL0560 Snow Pusher 303-454M... -
Page 20: Poly Blade (Optional)
4. Center poly blade between side panels and tighten hex whiz nuts (#3) to the correct torque. 5. Back drag unit 50 yards on dry concrete to level trailing edge of snow blade with bottom of skid shoe. SPL0548 & SPL0560 Snow Pusher 303-454M 9/07/16... -
Page 21: Long Term Storage
Land Pride Parts only. 3. Repaint parts where paint is worn or scratched to prevent rust. Ask your dealer for Land Pride aerosol touch-up paint. Paint is also available in touch-up bottles with brush, quarts, and gallon sizes by adding TU, QT, or GL to the end of the aerosol part number. -
Page 22: Section 4: Specifications & Capacities
Poly blades (option) Reversible and replaceable blade Steel blades (option) 3/8" x 4" Replaceable blade(s) Pull Back (option) 3/8" x 3" Steel blade Orange marker (accessory) 28" Tall, bolts to the side panels 39722 SPL0548 & SPL0560 Snow Pusher 303-454M 9/07/16... -
Page 23: Section 5: Features & Benefits
Used to pull snow away from structures such as garage doors and other objects. Assist in locating outer ends of the Snow Pusher when approaching buildings, 28" High orange marker (accessory) trees, poles, and other obstacles that can damage equipment. 9/07/16 SPL0548 & SPL0560 Snow Pusher 303-454M... -
Page 24: Section 6: Torque Values Chart
= nominal thread diameter in millimeters x thread pitch 1-1/2" - 12 1330 2970 2190 4820 3560 Torque tolerance + 0%, -15% of torquing values. Unless otherwise specified use torque values listed above. SPL0548 & SPL0560 Snow Pusher 303-454M 9/07/16... -
Page 25: Section 7: Warranty
This Warranty is limited to the repair or replacement of any defective part by Land Pride and the installation by the dealer of any such replacement part, and does not cover common wear items such as blades, belts, tines, etc. Land Pride reserves the right to inspect any equipment or parts which are claimed to have been defective in material or workmanship. - Page 26 Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...
