Land Pride 380-354A Installation Instructions Manual

Third Function Valve Kit
#380-354A Installation Instructions
For B2301 and B2601 Kubota Tractors with LA434 Loader
Before You Start
When you see this symbol, the subsequent
!
instructions and warnings are serious - follow
without exception. Your life and the lives of others
depend on it!
California Proposition 65
WARNING: Cancer and reproductive harm.
!
www.P65Warnings.ca.gov
IMPORTANT: Before you begin, thoroughly read
these instructions and check to be sure all parts are
accounted for. Please retain these installation
instructions for future reference and parts ordering
information.
General Information
Your Third Function Valve Kit is exclusively designed for
your Kubota B2301 and B2601 tractors. Please read
these installation instructions thoroughly before
assembling this kit to your Kubota tractor and loader.
These assembly instructions apply to the Third Function
Valve Kit listed below:
• 380-354A: 3FVK FF B2601 . . . . . . . . . . . . . . . . page 3
Further Assistance
Your Land Pride dealer wants you to be satisfied with your
new Third Function Valve Kit. If for any reason you do not
understand any part of this manual or are not satisfied
with the service received, the following actions are
suggested:
1. Discuss any problems you have with your Third
Function Valve Kit with your dealership service
personnel so they can address the problem.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
question/problem, and request assistance.
3. For further assistance write to:
Land Pride Service Department
1525 East North Street
P.O. Box 5060
Salina, Ks. 67402-5060
E-mail address
lpservicedept@landpride.com
© Copyright 2020 Printed 7/8/20
Manual No. 380-353M
Assembly Instructions
A detailed listing of parts for this kit is provided on page 8
for kits. Use the list that is for your specific Third Function
Valve Kit as a checklist to inventory parts received.
Please contact your local Land Pride dealer for any
missing hardware.
Direction Reference
All directional references are made from the operator
seat while facing the direction the machine will operate.
U
F
L U = up
L = left
B
R
D
B = back
Directional Arrows Used in Illustrations
Initial Preparations
!
WARNING
To avoid serious injury or death: Hydraulic fluid under high
pressure can penetrate the skin and/or eyes causing a serious
injury. Wear protective gloves and safety glasses or goggles
when working with hydraulic systems.
The steps listed below must be followed before installing
this kit:
1. If the front loader is not attached to the tractor, skip to
step 8. Otherwise, continue with step 2 below.
2. Lower loader arms fully down, turn tractor off, and
relieve all hydraulic pressure to the front loader
couplers by operating the loader control lever(s) in all
directions.
3. Having released all hydraulic pressure, lock the
control lever(s) from moving.
4. Remove all mechanical connections securing the
front loader to the tractor.
5. Disconnect all hydraulic lines from the front loader.
6. Refer to your tractor/loader Operator's Manual for
additional unhooking instructions.
7. Restart tractor and slowly back away from the loader.
8. Park tractor on a flat, level surface. Put tractor in park
or set park brake, turn off engine, and remove switch
key to prevent unauthorized starting.
9. Place chocks in front and back of the tractor's left rear
wheel.
10. As a safety precaution, disconnect the battery cable
from the battery's negative (-) terminal. Move
negative cable away from the terminal to avoid
accidental contact.
KEY:
D = down
R = right
F = front
1
