Next Day Blinds Motorized Honeycomb Shades Installation Instructions

A

Getting Started

The Parts: Before starting, please remove and identify the following parts required for the installation of your shades:
Standard Mounting Bracket Installation Screws
(Qty varies based
on window width)
B

The Tools

To install your Next Day Shades Motorized Honeycomb Shade, you will need
a few basic tools:
Phillips head screwdriver*, or
•
1/4" nut driver*
•
* Power screwdriver or power drill with #2 Phillips attachment or
1/4" nut driver attachment may be used.
C

Sorting Your Shades

On top of the headrail of your Next Day Blinds Motorized Honeycomb Shade,
there is a sorting label. On this label, you will recognize:
1. Order size of the shade
2. Room location (If not present, info not given at time of order)
3. Whether the shade was ordered for inside mount (IB), or outside mount (OB)
D

Bracket/Clip Placement

There is one set of brackets to mount the shade and one set of clips for the battery wand that powers the shade. The battery wand clips are designed to
be horizontal or vertically mounted on the window frame. If window depth permits, we recommend mounting the battery clips behind the bracket mounts
for the shade.
Battery Clip
Select the desired location for your battery wand, preferably on the right side of the window (the distance from the motor to the battery should not exceed
10") and mark the location. Install the battery clips at marked location, 6" from each other on center, with the included screws. Be sure the clips are level
with each other. Gently slide battery wand into the clip with the cable on the right side.
Mounting Brackets
Shades are shipped with the required number of brackets for proper installation. Depending on the width of the shade, additional brackets may be
necessary, evenly spaced between the two end brackets.
Installation Instructions |
Battery Wand + 8 Lithium Batteries
Battery Wand Clips
(Qty. 2)
Motorized Honeycomb Shades
Spacer Blocks (optional)
Important Note: Screws provided are for installation into wooden frames only. For
metal surfaces, use suitable sheet metal screws and pre-drill holes. For concrete,
stone, brick, or tile, use a carbide drill and appropriate anchors and screws.
For wallboard or plaster, use hollow wall anchors and/or longer screws to reach
framing or stud. In all cases, follow the fastener manufacturer's recommendations.
2. Room Location Work Order Number
1. Order Size of Shade 3. Type of Mount
Side Mount Bracket Hold Down Bracket
(optional) (optional)
