A
Getting Started
The Parts: Before starting, please remove and identify the following parts required for the installation of your shades:
Hex Head Screws
Mounting Brackets
(1 1/4")
B
The Tools
To install your Next Day Blinds Roller Shades, you will need a few basic tools:
•
Phillips Head Screwdriver*, or 1/4" nut driver*
Measuring tape
•
Pencil
•
* Power screwdriver or power drill with #2 Phillips attachment or 1/4" nut attachment may be used.
C
Sorting Your Blinds
On top of the headrail of your Next Day Blinds Roller Shade, there is a sorting label.
On this label, you will recognize:
1. Order size of the blind
2. Room location (If not present, info not given at time of order)
3. Whether the shade was ordered for inside mount (IB), outside mount (OB), or side mount (EM)
D
Bracket Spacing
The brackets should be installed where the centerlines are noted in the illustration.
Depending on the width of the roller shade, necessary additional brackets may be
evenly spaced between the two end brackets.
E
Bracket Installation
Inside Mount (IB)
No Headrail Version: Make sure that the screw head
is fully recessed inside the clear plastic part of the
mounting bracket (Fig. 1).
Headrail Version: Refer to Figure 2 for bracket
installation details.
Installation Instructions |
Lift Systems: for Premium Cordless
Mounting Bracket
(no headrail)
Figure 1
No Headrail Version
Roller Shades
Bolts and Nuts
Universal Extension
(optional)
Brackets (optional)
Important Note: Screws provided are for installation into wooden frames only. For
metal surfaces, use suitable sheet metal screws and pre-drill holes. For concrete,
stone, brick, or tile, use a carbide drill and appropriate anchors and screws. For
wallboard or plaster, use hollow wall anchors and/or longer screws to reach framing or
stud. In all cases, follow the fastener manufacturer's recommendations.
2. Room Location
1. Order Size of Blind
Installation Bracket Spacing on Headrail
Shade
Number of
Width
Brackets
2 1/4"
To 40"
2
40" To 72"
3
72" To 84"
4
84" To 96"
5
Hold Down Bracket
& Screw (optional)
Work Order Number
3. Type of Mount
Space evenly
Space evenly
Installation
Centerline
Bracket
Figure 2
Headrail: Smooth or Fabric Insert
2 1/4"
