- Page 1 “Building the Best, Servicing the Rest” ™ AGC Model pro3 P lat e Heat ex c H a n g e r O Perati O n a nd in sta l l at i On M a n ual...
-
Page 3: Table Of Contents
Pro3-DF Frame Components ..15 Pro3-I Tiebolt Assembly ... . 16 Pro3-S/SH Tiebolt Assembly ..17 Pro3-F/DF/DFH Tiebolt Assembly . -
Page 5: Scope
AGC Heat Transfer Pro3 tiebolt style heat exchangers. Currently 6 (six) different models of the Pro3 tiebolt style heat exchangers are available and this manual covers all 6. Please read this manual carefully before installing your heat exchanger. Pay particular attention to the safety instructions and the initial startup procedures. -
Page 6: Drawing Package
We recommend only qualified forklift drivers should lift and position the unit. It should be noted that high leg frames such as the Pro3-SH and Pro3-DFH can be top heavy and could tip if they are not moved properly. -
Page 7: Frame Placement
(stamped at the top of each plate) or by looking at the plate noting which ports have been opened. Since the Pro3 plate is a vertical flow plate, each plate can be used for either a right or left hand plate. The ProFlow manual explains how these plates are used in greater detail. - Page 8 The Pro3-SH, Pro3-S, Pro3-DFH and Pro3-DF frames are equipped with adjustable ball feet. These feet are adjusted by turning the base clockwise to lower and counterclockwise to raise the press. The ball feet should be adjusted so the ports are level from side to side.
-
Page 9: Frame Connections
(toward the fixed end or follower) is appropriate for your installation. The Pro3-I and Pro3-F frames are built with flat foot pads that are designed to be bolted to the floor. Therefore, no provisions for leveling are designed into the frame. However, these frames can be leveled by adding an appropriate amount of filler material under each foot pad as required. -
Page 10: Normal Operation
Normal Operation: The Pro3 series heat exchangers are tiebolt style frames. This means the press is closed by using 6 tiebolts to compress the plates. For this type of frame it is important for each tiebolt to take an equal share of the load. After your heat exchanger is in place you should check the compressed dimension if the plates were shipped installed. -
Page 11: Opening The Heat Exchanger
Figure 8 Tightening Location and Sequence Measure top and bottom as well as front and back. The heat exchanger is designed operate at its top efficiency when it is closed to a metal to metal condition. This means the rubber plate gaskets are fully compressed and the plates contact points are fully engaged with each adjacent plate. -
Page 12: Operator Maintenance
Model Features: The Pro3 tiebolt frame is offered in 6 different models (see figure 9). Regardless of the model chosen, each Pro3 frame will accept the AGC Pro3 heat exchanger plates and one or more AGC terminal(s). - Page 13 Pro3-S Pro3-SH Pro3-F Pro3-DF Pro3-I Pro3-DFH Figure 11 Pro3 Tiebolt Frame Assemblies 800.825.8820 eastern 888.489.8820 central 800.715.8820 western www.agcheattransfer.com...
-
Page 14: Parts List
All models of the Pro3 heat exchangers have some parts that are common as well as model specific parts. The following parts diagrams are separated by model when appropriate. -
Page 15: Pro3-Sh Frame Components
Pro3-SH Frame Components Item No. Pro3-SH Qty. Part Number Description See Table on page 17 Pro3 Bottom Rail 11018300 Pro3-S/SH Follower See Table on page 19 Pro3-S/SH Tiebolt 11018400 Pro3-S/SH End Support 11018200 Pro3-S/SH Fixed End See Table on page 17 Pro3 Upper Rail 800.825.8820 eastern... -
Page 16: Pro3-S Frame Components
Pro3-S Frame Components Item No. Pro3-S Qty. Part Number Description 11011610 Pro3-S Fixed End Assembly See Table on page 19 Pro3-S/SH Tiebolt Assembly See Table on page 17 Pro3 Bottom Rail Assembly 11011611 Pro3-S End Support Assembly 11018300 Pro3-S/SH Follower Assembly... -
Page 17: Pro3-F/I Frame Components
Item No. Pro3-F/I Qty. Part Number Description 11015000 Pro3-F/I Follower Assembly 11017400 Pro3-F/I Fixed End Assembly See Table on page 17 Pro3 Bottom Rail Assembly 11017500 Pro3-F/I End Support Assembly See Table on page 20 Pro3-F Tiebolt Assembly See Table on page 17 Pro3 Upper Rail Assembly 800.825.8820 eastern... -
Page 18: Pro3-Dfh Frame Components
Item No. Pro3-DFH Qty. Part Number Description 11015000 Pro3-F/I Follower Assembly 11017410 Pro3-DFH Fixed End Assembly See Table on page 17 Pro3 Bottom Rail Assembly 11014899 Pro3-DFH End Support Assembly See Table on page 20 Pro3-F Tie Bolt Assembly See Table on page 17... -
Page 19: Pro3-Df Frame Components
Item No. Pro3-DF Qty. Part Number Description 11015000 Pro3-F/I Follower Assembly 11014600 Pro3-DF Fixed End Assembly See Table on page 17 Pro3 Bottom Rail Assembly 11014900 Pro3-DF End Support Assembly See Table on page 20 Pro3-F Tie Bolt Assembly See Table on page 17 Pro3 Upper Rail Assembly 800.825.8820 eastern... - Page 20 Pro3 UPPeR RaIl Pro3 bottom RaIl Pro3 Rail Size Chart (All Pro3 Tiebolt Frame Models) Rail Size Rail Length Bottom Rail Assembly Upper Rail Assembly Pro3 Size 1 44" 11014700 11014800 Pro3 Size 2 67" 11014703 11014815 Pro3 Size 3 91"...
-
Page 21: Pro3-I Tiebolt Assembly
Pro3-I tiebolt assembly Pro3-I tiebolt Size Chart Tiebolt Overall Tiebolt Assembly Item Pro3-I Tiebolt Part Description Size Length Part Number Number Quantity Number Pro3-I Tiebolt Base Pro3-I Size 1 44" 11015130 11025011 See Size Chart Pro3-I Size 2 67" 11015131... -
Page 22: Pro3-S/Sh Tiebolt Assembly
Pro3-S/SH tiebolt assembly Pro3-S/SH tiebolt Size Chart Item Pro3-I Tiebolt Part Description Tiebolt Overall Tiebolt Assembly Quantity Number Size Length Part Number Number Pro3-S/SH Size 1 44" 11015126 11025007 See Size Chart Pro3-S/SH Tiebolt Base Pro3-S/SH Size 2 67" 11015127... -
Page 23: Pro3-F/Df/Dfh Tiebolt Assembly
Pro3-F/DF/DFH tiebolt assembly Pro3-F/DF/DFH tiebolt Size Chart Item Pro3-I Tiebolt Tiebolt Overall Tiebolt Assembly Part Description Quantity Number Size Length Part Number Number See Size Chart Pro3-F Tiebolt Pro3-F/DF/DFH Size 1 44" 11015110 11024200 Pro3-F/DF/DFH Size 2 67" 11015111 SG112N... -
Page 24: Pro3 Terminal Assembly
Part Number Pro3 Terminal Body with Roller 11018500 Pro3 Terminal Roller with Pin 11015007 Pro3 Port Boss V Configuration with 3" Connection 11018516 Pro3 Port Boss X Configuration with 3" Connection 11018515 Pro3 Port Boss Thru with 2" Connection 11018520... -
Page 25: Pro3 Plate And Frame Gaskets
Pro3 Flow GaSket Pro3 enD GaSket PRo3 DIe CUt PRo3 molDeD PoRt GaSket PoRt GaSket Pro3 Plate and Frame Gaskets Description Part Number Frame Application Pro3 Flow EPDM AGPRO301E All Pro3 Models Pro3 Flow NBR AGPRO301N All Pro3 Models Pro3 End EPDM... - Page 26 “BUILDINg THe BeST, SeRvIcINg THe ReST” ™ Agc Heat Transfer, Inc. is the leading supplier of sanitary plate heat exchangers in North America, manufacturing plate heat exchangers specifically designed for sanitary applications. Agc offers complete heat exchangers services including new frames as well as upgrade plate packs, gaskets and spares that fit other brands. Frames available are tie-bolt, twin spindle and hydraulic (automatic) closure.
- Page 27 Upgrade your existing APV Plate Pack. Plates in stock ready for shipment! proflow s a n i t a r y MANUFACTURED IN THE USA BY AGC old aPV Design Innovative aGC Design AGC Snap-in Gasket Reduced Restriction Inlet —...
- Page 28 EaSTERN Building the Best, 10129 Piper Lane I Bristow, VA 20136 Servicing the Rest 703.257.1660 I 800.825.8820 I FAX 703.330.7940 CENTRaL 8400 Lakeview Parkway, Suite 700 I Pleasant Prairie, WI 53158 847.301.6890 I 888.489.8820 WESTERN 9109 SE 64th Avenue I Portland, OR 97206 503.774.7342 I 800.715.8820 I FAX 503.774.2550 Rev 1, 01/2017...
