- Page 1 Installation and Configuration Quick Guide TPH6700 IP67 PC/ABS Housing For R2000/R2000 Ent/R3000/R3000 Lite...
- Page 2 No part of this document may be reproduced in any form without the written permission of the copyright owner. The contents of this document are subject to change without notice due to continued progress in methodology, design and manufacturing. Robustel shall have no liability for any error or damage of any kind resulting from the use of this document.
-
Page 3: Package Contents
Package Contents Before installing your TPH6700 housing, please verify the kit contents as 3G/4G antenna Wi-Fi antenna Frequency range: 800-2700 MHZ Frequency range: 2400-2483/5725-5850 MHZ following. Impedance: 50 ohm Impedance: 50 ohm 1 x Robustel TPH6700 IP67 PC/ABS Housing Weight: 0.2 kg... -
Page 4: Product Overview
Product Overview Item Description Core plug—seal up these Metal PC/ABS unneeded interfaces for Weight 1010 g protecting Dimensions 310 x 245 x 93.4 mm Ingress protection IP67 Vent plug—applied to balance Standards for the housing Fully detachable differential pressure, protect Performance requirement for high and low temperature from dust and water, and Aging-resistance level (UL746C) - Page 5 The interface of each housing model is slightly different. For more details in each model, see the following views. R2000： R2000 Ent：...
- Page 6 R3000： R3000 Lite：...
-
Page 7: Sim Card Installation
SIM Card Installation You need to remove the installed device when you install. 1. Remove the detachable cover of TPH6700 housing with a screwdriver. Note: Your device has been installed into the enclosure before delivery. 2. Disconnect all cables or wires of the router and take it out. - Page 8 Note: For more details about inserting or removing SIM card, please contact your Robustel sales representative for relevant user guide. 4. Put back the router and reconnect its cables or wires according to the original way.
-
Page 9: Antenna Installation
Antenna Installation Remove the protective caps from the cellular and Wi-Fi connectors. Here take Wi-Fi connector as an installation example. Connect the antenna to the corresponding antenna connector by holding onto the metal part of the antenna and rotating it clockwise. Note: Each antenna is labeled as 3G, 4G or WiFi for easy installation. -
Page 10: Serial Port Connection
Serial Port Connection Remove the protective cap from the serial port connector labeled SERIAL. Connect a serial port cable to the serial connector at the top of the enclosure, and rotate it clockwise. Description Connect the other end of the cable to your serial device. -10-... -
Page 11: Ethernet Connection
Ethernet Connection Remove the protective cap from the Ethernet connector. Connect an Ethernet cable to any port marked ETH0~ETH4 at the bottom of the enclosure, and rotate it clockwise. Description Connect the other end of the cable to your network interface, such as a personal computer. -11-... -
Page 12: Power Options
Power Options The TPH6700 can be powered via AC/DC power supply. The enclosure provides devices with a waterproof power connector allowing it to be powered by a specific input voltage which depending on the specific device inside. Note: For more details about power voltage, please contact your Robustel sales representative for relevant data sheet. - Page 13 Mountings The TPH6700 can be mounted to a wall or a pole. Wall Mounting Make sure you have mounting bracket, bracket mounting screws, wall plugs, wall mounting screws and other required tools. Before you start, make sure your SIM card has been inserted, your antennas have been attached and that all cables have been disconnected from your enclosure.
- Page 14 Mount the mounting bracket horizontally to the wall by fixing the wall mounting screws into the wall plugs (Figure WM-2). Figure WM-2 Figure WM-3 Mount the enclosure to the mounting bracket with the bracket mounting screws (Figure WM-3). Note: Place the Ethernet port side down when installing. Reconnect the cables to your TPH6700. -14-...
- Page 15 Pole Mounting Make sure you have mounting bracket, bracket mounting screws, hose clamp and other required tools. Before you start, make sure your SIM card has been inserted, your antennas have been attached and that all cables have been disconnected from your enclosure.
- Page 16 Straighten out the hose clamp and slide it through the rectangular holes in the mounting bracket (Figure PM-3). Figure PM-3 Figure PM-4 Wrap the hose clamp around the pole (Figure PM-5). Use a screwdriver to tighten the locking mechanism by turning it clockwise. Reconnect the cables to your TPH6700. -16-...
- Page 17 Guangzhou Robustel Technologies Co., Ltd. Add: 3rd Floor, Building F, Kehui Park, No.95 Daguan Road, Guangzhou, China 510660 Tel: 086-20-29019902 Email: info@robustel.com Web: www.robustel.com -17-...
