Summary of Contents for iReliev iRecover et-1313
- Page 1 iRecover™ Pain Relief System TENS Therapy Model # ET-1313 Instruction Manual...
-
Page 2: Indications
The iRecover™ Pain Relief System is a TENS system for active treatment as per intended use: • For temporary relief of pain associated with sore and aching muscles in the upper and lower extremities due to strain from exercise or normal household and work activities. (Choose TENS programs P1 through P8) www.iReliev.com... -
Page 3: Table Of Contents
Selecting the Intensity Level..….……………………………………..........................................12 SPECIAL FEATURES…………………………………………………................................................... 13 ELECTRODE PAD PLACEMENTS………………………………………………..........................................14 TENS PROGRAMS…………………………………………………..................................................15 CARE AND MAINTENANCE………………………………………………….............................................. 16 TROUBLESHOOTING.………..……………………………………………….…..............................................17 TECHNICAL SPECIFICATIONS……………………………………………………..........................................18-20 INFORMATION ABOUT ELECTROMAGNETIC COMPATIBILITY..………................................21-24 FCC INFORMATION………………………………………………………………............................................... 25 WARRANTY…………………………………………........................................................26 REGISTER YOUR DEVICE..…………………....................................................28 REGISTRATION CARD..........................................................29 www.iReliev.com... -
Page 4: Contraindications, Warnings, And Precautions
Do not use the device on children, if it has not been evaluated for pediatric use. We also recommend the following: • Consult with your physician before using this device, because the device may cause lethal rhythm disturbances to the heart in susceptible individuals. • Apply stimulation only to normal, intact, clean, healthy skin. www.iReliev.com... - Page 5 You may experience headaches and other painful sensations during or following the application of electric stimulation near your eyes and to your head and face. • You should stop using the device and consult with your physician if you experience adverse reactions from the device. www.iReliev.com...
-
Page 6: What's Included
WHAT’S INCLUDED Package Content iRecover™ TENS Device (1) Belt Clip & Holster (1) 2” x 2” Electrode Pads (4) AAA Batteries (3) Lead Wires (2) Tote Bag (1) www.iReliev.com... -
Page 7: Device Features
Power OFF/Decrease Key Power ON/Increase Key CH1 (Channel 1) Key CH2 (Channel 2) Key Mode (Setting Select/Set) CH1 Intensity Level CH2 Intensity Level Lock Status Indicator Battery Status Indicator 10 Therapy Program: TENS (P1-P8) 11 Treatment Minutes 12 Therapy Mode www.iReliev.com... -
Page 8: Step By Step Operation Guide For Treatment
3. Trim excess body hair from the area with scissors (do not shave). 4. If desired, apply iReliev® Conductive Gel or Conductive Spray to help increase conductivity. This may also reduce the chance of skin irritation and may extend the life of the electrode pads. -
Page 9: Installing The Batteries
In the event you only want to run one channel, please insert the lead wire into channel 1 (Upper left-hand side). Note: The device will auto-reset by default to “0” Intensity Level on the respective channel if the lead wire is not fully inserted. www.iReliev.com... -
Page 10: Connecting Electrode Pads To Lead Wires
Note: Pads are for single person use. Never share the pads with another person. Note: Do not use pads after expiration date. Note: Do not place pad(s) on your body where it cannot be reached by your own hand. www.iReliev.com... -
Page 11: Turning On & Off The Device
The device offers 8 preset TENS programs; the programs differ with respect to varying pulse widths and frequencies. The program you choose determines the impulse output type. Choose the program that is appropriate to your needs as shown on page 15 or is most comfortable to you. www.iReliev.com... -
Page 12: Selecting The Intensity Level
Note: Always start with the lowest intensity gradually increasing until you feel a “tingling sensation”. Never increase the intensity to a level that causes additional pain. Stay under the point of discomfort. Start with short sessions of 5-10 minutes until you are comfortable with the stimulation. www.iReliev.com... -
Page 13: Special Features
Automatic shut off: The device turns off automatically when the therapy time has elapsed or when no button is pressed for 60 seconds. • Memory: The last treatment program will be stored and appear on the display when you turn on the device. www.iReliev.com... -
Page 14: Electrode Pad Placements
Electrode Pad Placement Calves Ankle Elbow Feet Lower Back Quad Shoulder Knee Upper Arm Upper Back Wrist www.iReliev.com... -
Page 15: Tens Programs
Variable comfortable pulsing and pumping action (action will appear to come in waves). Variable comfortable tingling and pumping action (action should appear to come in waves). Variable comfortable tingling and pulsing sensation (sensation should appear to come in waves). Pain should ease and there should be relief after treatment. www.iReliev.com... -
Page 16: Care And Maintenance
Note: Electrode pads are for single person use only. If you have questions about the integrity of the electrode pads or if you want to order new electrode pads, please order online at www.iReliev.com or call us at 855-723-2582. www.iReliev.com... -
Page 17: Troubleshooting
• Switch the device to the OFF position and then • Treatment time power ON. expired. The device doesn’t turn on • Contact ExcelHealth at 855-723-2582 or visit us at even though new batteries www.iReliev.com. We want your iReliev experience to be are installed. great. www.iReliev.com... -
Page 18: Technical Specifications
Essential Performance: The stimulation output as defined in the following specification table for TENS. TENS Programs : Program Pulse width(uS) Frequency(Hz) Function Mode Constant Burst Constant 260~156 2~60 Modulation 260~156 Modulation 7~60 Modulation 260~156 Modulation 2.45~245 Cycle **All electrical specifications are ±10% at 500Ω load. www.iReliev.com... - Page 19 Any emission, radiation, or induction that endangers the functioning of a radio-navigation service or of other safety services or seriously degrades, obstructs, or repeatedly interrupts a radio communication service operating in accor- dance with FCC rules with interference that may cause undesired operation. www.iReliev.com...
- Page 20 This symbol means “type BF equipment”; this device offers protection against electrical shock by standard compliance to leakage currents of electrode pad. There is a label on the package explained as: This symbol means “use before”, represented as “YYYY-MM” (for year and month). www.iReliev.com...
-
Page 21: Information About Electromagnetic Compatibility
The customer or the user of the system can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the iRecover™ Pain Relief System as recommended on next page, according to the maximum output power of the communications equipment. www.iReliev.com... - Page 22 Radiated RF IEC 3 V/m 3 V/m aration distance calculated from the equation applicable to 61000-4-3 80 MHz to 2.5 GHz the frequency of the transmitter. Interference may occur in the vicinity of equipment marked with the following symbol: www.iReliev.com...
- Page 23 (30 % dip in U ) for 25 operation during power mains interruptions, it is input lines cycles <5 % U cycles <5 % U recommended that the EQUIPMENT or SYSTEM be IEC 61000-4-11 powered from an uninterruptible power supply or a battery. www.iReliev.com...
- Page 24 The iRecover™ Pain Relief System is suitable for use in all estab- lishments, including domestic establishments and those directly Harmonic emissions connected to the public low-voltage power supply network that IEC 61000-3-2 Class C supplies buildings used for domestic purposes. Voltage fluctuations/Flicker Complies emissions IEC 61000-3-3 www.iReliev.com...
-
Page 25: Fcc Information
Important Note: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. www.iReliev.com... -
Page 26: Warranty
WARRANTY This iRecover™ Pain Relief System carries a one-year warranty from the date of purchase. Extended warranties are provided with device registration at iReliev.com/registration. The warranty applies to the main device and necessary parts and labor. Consumable items like lead wires, electrode pads, and other accessories are guaranteed to be free from defects in workmanship and materials at the time of delivery. - Page 27 THANK YOU FOR PURCHASING Your new iReliev ® product is one of the best in the industry, and in many ways, leads the industry, particularly in the warranty coverage and customer satisfaction. Customer satisfaction is a key factor in every iReliev ® transaction.
-
Page 28: Register Your Device
REGISTER YOUR DEVICE Please go to https://www.iReliev.com/register to register your iRecover™ Pain Relief System, model # ET-1313, within 14 days of purchase to receive free gifts and discounts. Enter the serial number on the warranty registration form. The serial number may be found on the underside of the device or retail box. -
Page 29: Registration Card
www.iReliev.com... - Page 30 www.iReliev.com...
- Page 31 www.iReliev.com...
- Page 32 ExcelHealth Inc. www.iReliev.com 1603 Hart Street Southlake, TX 76092 If you have any questions whatsoever regarding your iRecover™ Pain Relief System Model # ET-1313, contact your reseller or ExcelHealth Inc. at: 855-723-2582 or visit www.iReliev.com...
