- Page 1 IW-RS424-02M User’s Manual...
-
Page 2: Table Of Contents
Table of Content PREFACE SAFETY INFORMATION SPECIFICATIONS 1 Product Introduction Box Content General Information 1.2.1 Front Panel Controls and Indicators 1.2.2 Rear Panel Configuration 2 Hardware Installation Removing and Installing a Hard Drive 2.1.1 Installing a Hard Drive 2.1.2 Removing a Hard Drive Removing and Installing Top Cover P.10 Removing and Installing a Fan Module... -
Page 3: Preface
PREFACE Thank you for choosing In Win IW-RS424-02M. This manual is written for system technicians who are responsible for installation, troubleshooting, managing, and repairing this server chassis. This document provides the overview of all the features of the chassis, a list of accessories or other components you may need to finish the installation, troubleshooting methods, and instructions of adding and removing components on the In Win IW- RS424-02M. - Page 4 Hazardous conditions, devices and cables: Hazardous electrical conditions usually present on power supply units, and communication cables. Disconnect the power cord, and any other device which attached to the server before opening the case. Otherwise, it will raise the risk of personal injury or equipment damage.
-
Page 5: Specifications
SPECIFICATIONS Model Name IW-RS424-02M Standard EIA-RS310D M/B Form Factor ATX (12” x 9.6”), ATX(12” x10”), EEB(12” x 13”) Dimensions (D x W x H) 625 x 482.6 x 177 mm (24" x 19" x 7") External: Hot-Swap 3.5" x 24 or 2.5" x 24, 2.5" HDD Hot-Swap x 2 (Optional) Drive Bay Internal: 2.5"... -
Page 6: Product Introduction
1 Product Introduction Box Content When you open the carton box of IW-RS424-02M, the contents should include:... -
Page 7: General Information
General Information When you open the top cover should be like the diagram shows. Top cover ATX or EEB M/B CRPS Redundant or Single module power supply 120 x 38 mm PWM Easy-Swap Fan x 3 mm PWM Rear Fan x 2 Front Controls and 24 x 3.5”... -
Page 8: Front Panel Controls And Indicators
1.2.1 Front Panel Controls and Indicators After unlock and removing the front cover, you can see the 24 disk bays, and the control panel, USB IO ports and indicators on the handles. Name Color Status Description Solid on System is powered on Power ON/OFF Button Blue with LED... -
Page 9: Rear Panel Configuration
1.2.2 Rear Panel Configuration The rear side of IW-RS424-02M contains space of AC power source, system IO, and an expansion cards slot. Name Description The bracket is for holding single PSU. For redundant PSU, remove this cover PSU Bracket and replace as redundant PSU housing case bracket. -
Page 10: Hardware Installation
Removing and Installing a Hard Drive In Win IW-RS424-02M has 24 external hot-swap disk bays, which support both 3.5” hard drives, 2.5” hard drives, and 2.5” SSDs. Also, IW-RS424-02M supports 2 internal 2.5” hard drives or SSDs for building system OS. -
Page 11: Removing A Hard Drive
2.1.2 Removing a Hard Drive Step 1: Press the release button then pull outward the disk tray. Step 2: Loosen the 4 screws and unmount the hard drive. Step 1 Press Release HDD tray Step 2 Pull Unscrew 2.1.3 Installing 2.5” 2bay SSD module Step 1: Remove the slot bracket to left the space for the module. - Page 12 Step 4: Push forward the cover and make sure the clip clicks, then screw up to fix the cover. Removing and Installing the fan wall The fan module of IW-RS424-02M is flexible which you can move forward or backward to optimize the cooling efficiency. Removing the fan wall before posting the motherboard to get more space for the processing.
- Page 13 Step 2 Loose the thumb screw 2.3.2 Moving and installing the fan wall (Repeat the actions of 2.3.1) Step 1 Install the fan wall Step 2 into the chassis...
-
Page 14: Removing And Installing A Psu Module
Removing and Installing a PSU In Win IW-RS424-02M supports single and redundant power supply unit. Users can select power supply according to the environment’s requirements. Note: The different PSU needs different rear and side bracket. The accessory box includes the bracket sets for supporting models. -
Page 15: Installing Slide Rail
2.5 Installing a Slide Rail In Win IW-RS424-02M is a rackmount model, which support EIA-RS310D standard cabinet and chassis rack. In Win provides standard slide rail to let users mount the chassis on to the cabinet. 2.5.1 Identifying the sections of the Slide Rail 2.5.2 Installing a Slide Rail... -
Page 16: Installing Motherboard
Installing Motherboard Before installing the motherboard, please find the IO shield form your motherboard package, and install it to the system IO window 1.2.2 shows. If you cannot find the IO shield, please check with your motherboard vendor, or contact In Win for IO shield OEM service. Step 1: Measure the motherboard location and removing the plastic dots to appear the holes. -
Page 17: Connecting Cable
Connection Cable 2.2.1 Connecting backplane through SAS connectors In Win IW-RS424-02M needs SAS cable connecting the backplane and your motherboard or RAID controller. In Win provides verified SAS cable for installation, please contact In Win local partners and sales to get more information. -
Page 18: Backplane Introduction
3 Backplane Introduction The backplane is different by order, Please reference the backplane user guide to complete the installation. Visit In Win website: https://www.in-win.com/en/ipc-server The download link is at the download section of each product. Top Side Bottom Side... -
Page 19: Compatibility Lists
4 Compatibility Lists To reach best performance and avoid system failure, In Win strongly recommend users choosing the components from In Win’s compatibility list. All the components are tested in In Win’s lab and assured the components are working well with In Win’s chassis. You can download the latest updated device compatibility list from In Win’s website: https://www.in-win.com/en/ipc-server 5 Q&A... - Page 20 f. Do the chassis support mirrored OS disks? In Win IW-RSXXX-02M models supports at least 2 internal disks, RS424-02M and RS424-02M have built- in 2bay hot swap module. Yet, the disk mirroring is defined by your motherboard or your RAID 1 controller card.
