Produktpräsentationsbild mit grünen, schrägen Balken links
Produktpräsentationsbild mit grünen, schrägen Balken links
Supplementary
Instruction Manual WLAN
ALMEMO
Connection to a WiFi network as
relay bridge
V7-Technology
English
V2.4
24.01.2018
- 1 –
®
500
www.ahlborn.com
WLAN
network as

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALMEMO 500 and is the answer not in the manual?

Questions and answers

Related Manuals for Ahlborn ALMEMO 500

Summary of Contents for Ahlborn ALMEMO 500

  • Page 1 Produktpräsentationsbild mit grünen, schrägen Balken links Produktpräsentationsbild mit grünen, schrägen Balken links Supplementary Instruction Manual WLAN WLAN ® ALMEMO Connection to a WiFi network as network as relay bridge V7-Technology English V2.4 24.01.2018 - 1 –...

  • Page 2: Table Of Contents

    1 Table of Contents Table of Contents ..................2 Explanation of Symbols................3 How to reset the access point to its factory setting ......4 How to configure the access point ............5 4.1 Open the configuration page ..............5 4.2 Check the OPKG setting ...............

  • Page 3: Explanation Of Symbols

    2 Explanation of Symbols Notice Result Reference referring to the global overview of the data of the data logger (page 2) Back Text displayed within a software - 3 –...

  • Page 4: How To Reset The Access Point To Its Factory Setting

    3 How to reset the access point to its How to reset the access point to its factory setting ! No Ethernet cable shall be connected to the data logger. be connected to the data logger. 1. Switch the data logger on and wait until the device is ready for operation. and wait until the device is ready for operation.

  • Page 5: How To Configure The Access Point

    4 How to configure the access point How to configure the access point 4.1 Open the configuration page ! The data logger must be connected to the PC via Ethernet. The data logger must be connected to the PC via Ethernet. 1.

  • Page 6: Set The Distribution Feeds

    4 How to configure the access point 6. Correct the paths if necessary. 7. Click on 4.3 Set the distribution feeds 1. Click on System. 2. Click on Software. Configuration. 3. Click on the tab Distribution feeds. 4. Scroll down to the section The following distribution feeds will be listed: 5.

  • Page 7: Install Required Supplementary Programs

    4 How to configure the access point configure the access point 6. Click on 4.4 Install required supplementary programs 1. Click on System. 2. Click on Software. Actions. 3. Click on the tab 4. Click on Download and install packages relayd 5.

  • Page 8: Choose Wifi Network And Connect

    4 How to configure the access point The supplementary program “luci-proto-relay” has already been installed if has already been installed if the following message appears:: The supplementary program “luci-proto-relay” is being installed if is being installed if the following message appears: 4.5 Choose WiFi network and connect 1.

  • Page 9: Generate An Interface Bridge

    4 How to configure the access point configure the access point In the section Interface Overview, the LAN und WWAN will be displayed in will be displayed in green. 11. Click on 4.6 Generate an Interface BRIDGE 1. Click on Network. 2.
  • Page 10 4 How to configure the access point The changes will be saved and the Interface BRIDGE will be displayed in green in the Interface Overview. - 10 –...

  • Page 11: Set The Wwan Firewall

    4 How to configure the access point configure the access point The changes will be saved and the Interface Bridge will be The changes will be saved and the Interface Bridge will be displayed in the Interface Overview. 9. In the line BRIDGE, cklick on Firewall Settings.

  • Page 12: Restart The Data Logger

    4 How to configure the access point Firewall Settings. 4. Click on the tab Create / Assign firewall-zone 5. In the section , click on LAN. LAN. 6. Click on 4.8 Restart the data logger 1. Switch the data logger off. 2.
  • Page 13 4 How to configure the access point configure the access point The configuration site of the access point will open. 6. Click on Network. 7. Click on Interfaces. 8. In the line LAN, click on 9. Scroll down to the section DHCP server. General Setup Disable DHCP for this Disable DHCP for this...

  • Page 14: Information Regarding The Subsequent Login To The App

    5 Information regarding the subsequent subsequent login to the app The tablet must be connected to the same WiFi network the data the data logger is connected to. The data logger will now receive an IP address from the DHCP The data logger will now receive an IP address from the DHCP server of the connected network.
  • Page 15 Despite greatest diligence, the possibility of incorrect information cannot be excluded. Subject to technical modifications without prior notice. - 15 –...
