Get Started Spraying - Flowzone Cyclone FZSAAJ Operation Manual

Fill the sprayer with liquid
1
through the intake filter
and securely tighten
the tank cap.
NOTE: Always mix
liquid solution in a
separate container.
Screw the brass hose fitting
2
to bottom of spray gun.
NOTE: Always connect hose / wand /
nozzles when sprayer is turned off.
Copyright © WESSOL, LLC
STEP 2: Get started spraying
Determine which nozzle is
3
right for the job & connect
to spray wand by pulling
down on quick-connect and
inserting nozzle.
1. Adjustable nozzle =
ranges from
jet stream to
conical stream
2. Fan nozzle =
flat 25° stream
3. Jet nozzle =
narrow pin stream
Turn pump on by flipping
4
switch on side of unit.
Flipping switch to "I" will
activate pump at 60 psi.
Flipping switch to "II" will
activate pump at 45 psi.
NOTE: The pump will make a priming
noise when first activated.
Begin spraying by
5
squeezing spray trigger.
04
