- Page 1 Solano Installation, commissioning and user manual Unit heater Issue 001 | September 2018 ENGLISH | UK | IRL | SmithsEP.co.uk 1 | SmithsEP.co.uk | Issue 001 - September 2018...
- Page 2 Technical Documentation waterfan HEATER v201803 INTRODUCTION HEATER heating and ventilation devices are designed to be applied in the buildings of small and medium capacity, especially such as: production and warehouse halls, car showrooms and service stations, sports halls and stadiums, sacral buildings and churches, retail stores and wholesales outlets, agricultural facilities, exhibition surfaces.
-
Page 3: General Information
Technical Documentation waterfan HEATER v201803 3. GENERAL INFORMATION HEATER heating and ventilation devices are manufactured in compliance with standards concerning quality, ecology, utility and work comfort. HEATER devices are delivered ready-to-use in a cardboard package that is to protect from mechanical damages. The package consists of: the device, the Manual (Operation and Maintenance Documentation) and Guarantee. -
Page 4: Instalacja Elektryczna
Technical Documentation waterfan HEATER v201803 Mounting bracket to the heater The bracket set consist of: a holder, two sleeves, two M8 screws and washers. In order to mount the bracket, drill two Ø12- 13mm holes in places visibly marked on the casing. -
Page 5: Electrical Installation
Technical Documentation waterfan HEATER v201803 5. ELECTRICAL INSTALLATION The electrical installation and connection to power supply must be done in compliance with the existing regulations and standards for building industry. The fan’s engine is equipped with the internal temperature limit fuse protecting the engine from its overheating. The unit set does not consist of: a feeding cable, a master switch (see diagram) The electrical installation must be done by an authorized person, acquainted with the Manual. -
Page 6: First Start
Technical Documentation waterfan HEATER v201803 COMFORT panel description ON/OFF – turning ON/OFF a unit I-II-III – switch for fan speed regulation HEAT - thermostat sends signal for valve and actuator and fan, fan turns off when temperature in room is achieved, valve/actuator closes water supply. - Page 7 Technical Documentation waterfan HEATER v201803 12. TECHNICAL PARAMETERS HEATER 7 | SmithsEP.co.uk | Issue 001 - September 2018...
-
Page 8: Electrical Connection Diagrams
Technical Documentation waterfan HEATER v201803 13. ELECTRICAL CONNECTION DIAGRAMS 1. Connecting HEATER with no automatic control * The unit set does not consist of: a master switch, a fuse, a feeding cable Fan wiring description high speed – brown middle speed – grey low speed –... - Page 9 Technical Documentation waterfan HEATER v201803 3. Connecting HEATER units with INTELLIGENT panel. Panel Intelligent controls actuators/valves and automatically regulates fans’ speed depending on the required room temperature. Fans speed changs automatically for lower rate, when temperature in a room gets closer to desired one. Additional functions –...
- Page 10 Technical Documentation waterfan HEATER v201803 5. Connection of HEATER unit with transformer speed regulator. * When using transformer speed regulator please use only maximum speed connector on a fan - U1 high speed 10 | SmithsEP.co.uk | Issue 001 - September 2018...
-
Page 11: Function Modes
Technical Documentation waterfan HEATER v201803 14. PANEL INTELLIGENT – programmable controller manual Panel Intelligent controls actuators/valves and automatically regulates fan’s speed depending on the required room temperature. Fans speed changes automatically for lower rate, when temperature in a room gets closer to desired one. Additional functions of Panel Intelligent: Weekly thermostat •... - Page 12 Technical Documentation waterfan HEATER v201803 SETTINGS MENU EXAMPLE SETTINGS of WEEKLY THERMOSTAT When Panel Intelligent is switched off, press and • hold MODE for 3 seconds. Mon-Fri Saturday Sunday To change option use MODE button. • To change value use +/- buttons. • 1 06:00 ~ 08:00 17°C 17°C 17°C...
- Page 13 Registering your product Disposal As part of the policy of continuous product improvement, Smith’s Thank you for purchasing a Smith’s product. It has been designed Environmental Products LTD reserves the right to alter specification and manufactured to the highest quality standards to ensure it gives without prior notice.
- Page 14 Notes 14 | SmithsEP.co.uk | Issue 001 - September 2018...
- Page 15 Notes 15 | SmithsEP.co.uk | Issue 001 - September 2018...
- Page 16 Happy to help To view the full product information Smith’s Environmental Products Ltd is one of the leading download the datasheet at: manufacturers of heating and cooling products in the UK. www.SmithsEP.co.uk We are committed to achieving the highest standards and our faith is supported by a free five year parts and labour For product information, customer services or sales support guarantee with every product.
