ADG-P Series
Programmable DC Power Supply
User Manual
AC Power Corp. (Preen)
V 1.02.00EN
The information in this document is subject to change without notice.
©AC Power Corp. (Preen). All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADG-P Series and is the answer not in the manual?

Questions and answers

Related Manuals for Preen ADG-P Series

Summary of Contents for Preen ADG-P Series

  • Page 1 ADG-P Series Programmable DC Power Supply User Manual AC Power Corp. (Preen) V 1.02.00EN The information in this document is subject to change without notice. ©AC Power Corp. (Preen). All rights reserved...
  • Page 2 Copyright Notices. Copyright 2017 AC Power Corp. (Preen), all rights reserved. Re- production, adaptation, or translation of this document without prior written per-...
  • Page 3 Preen’s ADG-P series is warranted against defects in material and workmanship for a period of two year after date of shipment. Preen agrees to repair or replace any as- sembly or component found to be defective, under normal use during this period.
  • Page 4 Failure to comply with these precautions or specific WARNINGS given elsewhere in this manual will violate safety standards of design, manufacture, and intended use of the product. Preen assumes no liability for the customer‘s failure to comply with these require- ments. BEFORE APPLYING POWER Verify that the product is set to match with the power line input.

  • Page 5: Table Of Contents

    Contents Table of Contents 1 GENERAL INFORMATION ....................1 1.1 Introduction ....................1 1.2 Specifications ....................1 1.3 Exterior ......................6 2 INSTALLATION ........................9 2.1 Inspection ....................... 9 2.2 User Preparation ..................... 9 2.3 Remove the Front Door from the Product Enclosure ........10 2.4 Input Connection ....................
  • Page 6 Contents 4.1 Emergency Troubleshooting ................23 4.2 Dust Check ..................... 23 4.3 Product Maintenance ..................23 4.3.1 Daily Maintenance ...................... 23 4.3.2 Monthly Maintenance ....................25 5 REMOTE CONTROL ....................... 26 5.1 Remote Read ....................26 5.2 Remote Write ....................27 5.3 Transmission Example ..................

  • Page 7: General Information

    ADG-P series can be used as a facility power or EMC chamber power. With output power up to 100kW per unit, ADG-P series can offer output voltage up to 1600V or output current up to 2000A. Users can select standard interface RS-485 or optional interfaces RS-232 and GPIB.
  • Page 8 ADG-P Series User Manual Voltage Noise (Peak) ≦3.7% ≦2% ≦0.88% Voltage Slew Rate*1 ≦65ms ≦60ms ≦85ms Transient Response*2 ≦4-12ms Voltage Accuracy 0.5% F.S. Voltage Resolution 0.1V Current Accuracy 0.5% F.S. Current Resolution 0.1A Type Vin OVP, Vin UVP, OVP, OCP and OTP...
  • Page 9 ADG-P Series User Manual 30kW ADG-P-400-75 ADG-P-500-60 ADG-P-640-47 ADG-P-800-38 ADG-P-1000-30 ADG-P-1600-18 50kW ADG-P-400-125 ADG-P-500-100 ADG-P-640-78 ADG-P-800-63 ADG-P-1000-50 ADG-P-1600-31 3Φ3W + G Voltage 380 VAC/400VAC/415VAC/440VAC/480VAC ± 10% Input Frequency 47-63Hz Power Factor ≧90% at maximum power Line Regulation ≦0.1% Load Regulation ≦0.032%...
  • Page 10 ADG-P Series User Manual Storage Temperature -20°C-70°C Isolation Input to product cover: 2000VAC Dimension (H×W×D) 41.5×23.6×31.5 inch /1050×600×800 mm 30kW: approx. 412lbs/187kg Weight*3 50kW: approx. 423lbs/192kg 75kW ADG-P-40-1875 ADG-P-60-1250 ADG-P-100-750 ADG-P-320-234 ADG-P-640-117 ADG-P-1000-75 100kW ADG-P-40-2500 ADG-P-60-1666 ADG-P-100-1000 ADG-P-320-313 ADG-P-640-156 ADG-P-1000-100 3Φ3W + G...
  • Page 11 ADG-P Series User Manual OCP Range 5% - 115% from front panel OCP Accuracy 1% F.S. Efficiency ≧90% 3% maximum voltage drop from product output to load Remote Sense Limits (for product models with output voltage lower than 1000VDC) 0°C-40°C...

  • Page 12: Exterior

    ADG-P Series User Manual 1.3 Exterior Product exterior of the ADG-P series with power level 30kW, 50kW, 75kW and 100kW are given as follows, (a) Front-side view of the ADG-P series (30kW&50kW) (b) Right-side view of the ADG-P series (30kW&50kW)
  • Page 13 ADG-P Series User Manual Figure 1.2 Product exterior of the ADG-P series in axis-side view (30kW&50kW) (a) Front-side view of the ADG-P series (75kW&100kW)
  • Page 14 ADG-P Series User Manual (b) Right-side view of the ADG-P series (75kW&100kW) Figure 1.3 Product exterior of the ADG-P series (75kW&100kW) Figure 1.4 Product exterior of the ADG-P series in axis-side view (75kW&100kW)

  • Page 15: Installation

    ADG-P series should be installed in indoor and in dry environment with little dust. Location for installing ADG-P series must be stable and secure due to its heavy weight, and users should notice that ADG-P series is better to be placed on the ground.

  • Page 16: Remove The Front Door From The Product Enclosure

    ADG-P Series User Manual 2.3 Remove the Front Door from the Product Enclosure For input/output connection, please remove the front door from the product enclo- sure since the front door is fixed to the product via screws, and there are terminals of AC input and DC output inside the front door.

  • Page 17: Output Connection

    ADG-P Series User Manual 4. Confirm that the AC wires between the power line input and the AC input ter- minals are secured. Installation of the AC wires to the product must be done by a professional and ac- cording to local electrical codes.
  • Page 18 ADG-P Series User Manual DC Output Terminals Figure 2.3 DC output terminals...

  • Page 19: Local Operation

    ADG-P Series User Manual Local Operation 3.1 Power-on Procedures WARNING Before turning on the product, all protective grounding terminals, extension cords, and devices connected to the product must be connected to a protective ground. Any interruption of the protective ground will cause a potential shock hazard that could result in personal injury.

  • Page 20: General Page

    ADG-P Series User Manual 3.2 General Page The description for the items and the icons at the General page are given according to the figure below. Users can press the display area, and then the digital scope will be shown at the General page to provide product output waveform.

  • Page 21: Output Measurement

    ADG-P Series User Manual 3.2.1 Output Measurement At the General page, the item “Voltage” indicates measurement of the present DC output voltage; the item “Current” indicates measurement of the present DC output current; the item “Power” indicates measurement of the DC output power.

  • Page 22: Constant Current Mode

    General page. Figure 3.5 General page when the product performs at the constant Voltage mode NOTICE When ADG-P series performs at the constant current mode, the DC output voltage will be automatically adjusted to match load conditions.

  • Page 23: Function Page

    ADG-P Series User Manual 3.3 Function Page Press the icon “Function” to enter into the function page. Figure 3.6 Function page 3.3.1 Step Setting Press the icon “Step” to enter into the step page, and the step page is shown below.

  • Page 24: Step Performing

    ADG-P Series User Manual 3.3.2 Step Performing Press the icon “Run” to perform the step feature, and output status is shown on the output display area. Similarly, the output display area can show the output status by waveform display or digit display. “Run status” includes performing number, output voltage, elapsed time and total cycle times.

  • Page 25: Gradual Setting

    ADG-P Series User Manual 3.3.3 Gradual Setting Press the icon “Gradual” to enter into the gradual page, and the gradual page is shown below. After entering into the gradual page, press the icon “Voltage grad” or “Current grad” to operate at voltage/current gradual mode. Then, set start output...

  • Page 26: Gradual Performing

    ADG-P Series User Manual 3.3.4 Gradual Performing Press the icon “Run” to perform the gradual feature, and output status is shown on the output display area. Similarly, the output display area can show the output status by waveform display or digit display. “Run status” includes performing number, out- put voltage, elapsed time and total cycle times.

  • Page 27: Protection

    ADG-P Series User Manual 3.4 Protection 3.4.1 Protection: Vin UVP When the input voltage for the product is lower than a default value, Vin UVP will be triggered and the product will immediately stop the output. Then, the sign “Vin UV”...

  • Page 28: Protection: Ovp

    ADG-P Series User Manual 3.4.3 Protection: OVP When the output voltage of the product is higher than a default value, OVP will be triggered and the product will immediately stop the output. Then, the sign “OV” will be shown below the item “Voltage” at the General page. To reset the product from OVP, please press the icon “Reset”.

  • Page 29: Repair And Maintenance

    If ADG-P series has any abnormal conditions or triggers any product protection, users must immediately stop the product output and turn off the product. 4.2 Dust Check ADG-P series must be installed in dry and clean room, and please clean the dust for the product every six months once. 4.3 Product Maintenance Extreme temperature, high humidity, heavy dust, chemical pollution and physical vi- bration all could impose negative impacts on the life and reliability of the product.
  • Page 30 ADG-P Series User Manual Abnormal conditions on the product can be detected by the daily inspection and maintenance. Once an abnormal condition is detected, users should identify its root cause, and eliminate the abnormal condition accordingly. If users are unable to iden- tify the root cause or eliminate the abnormal condition, please call our customer ser- vice for technical support immediately.

  • Page 31: Monthly Maintenance

    ADG-P Series User Manual 4.3.2 Monthly Maintenance For monthly maintenance, screen filter for the air inlet should be detached and clean for well ventilated. According to the usage of this product and the environment where it operates, monthly maintenance can be carried out every 3-6 months once.

  • Page 32: Remote Control

    Preen provides specialized control software for ADG series programmable high power DC power supply, and this control software eases remote op- eration for users to quickly set product output. Additionally, Preen pro- vides MODBUS protocol for users, and users can use such protocol to program product control according to their practical requirements.

  • Page 33: Remote Write

    ADG-P Series User Manual 5.2 Remote Write Write packet format  Function Code 10H Length Start Address Data (High to Low) CRC16 1 Byte 1 Byte 1 Byte 2 Bytes N Byte 2 Bytes  Write feedback packet format (correct)

  • Page 34: Transmission Example

    ADG-P Series User Manual Status Code Description Correct CRC error Data length error Function code error Address error Output voltage exceeding the rated value Output current exceeding the rated value Product output writing prohibited 5.3 Transmission Example  Remotely read the product (correct) Remotely read the setting value Vout_set.
  • Page 35 ADG-P Series User Manual 100V. Function Code 03H Status Code Length Data (High to Low) CRC16 42 C8 00 00H D6 81H  Remotely read the product (error) Remotely read the setting value Vout_set. Start address will be 0000H, data length will be 4 bytes, and CRC16 is incorrect.
  • Page 36 ADG-P Series User Manual 00 00H 42 C8 00 00H D6 2AH  Feedbacks status code 00H from the product to indicate correct writ- Function Code 10H Status Code Length CRC16 00 DH  Remotely write into the product (error) Remotely write the setting value Vout_set 800V.

  • Page 37: Modbus Address Table

    ADG-P Series User Manual 5.4 MODBUS Address Table Parameter Name Start Address Function Length Format Output Voltage Setting 0000H 03H/10H 4 bytes IEEE754 Output Voltage Setting 0004H 03H/10H 4 bytes IEEE754 00H: Stop Product Output 0008H 03H/10H 1 byte 01H: Output...
  • Page 38 ADG-P Series User Manual Bit 3: Vin OVP Bit 4: Vin UVP Bit 5: OVP Bit 6: UVP Bit 7: OTP...
