QVision Operations and Installation Guide
SPECIFICATIONS
Dimensions
Height
Depth
Width
Weight
Display
CRT
Type
Maximum Graphics
Resolution
Text Mode
Character Display
Color Scale
Brightness and
Contrast
Bandwidth
Horizontal Frequency
Vertical Frequency
Temperature Range
Operating
Non-Operating
Specifications
QVision Graphics System from Compaq
16.6 in
16.6 in
16.1 in
45 lb
15 in
Color
1024 x 768 up to 72 Hz Non-Interlace
720 x 400
80 x 25
Infinite, Analog Input 75 ohm
Adjustable
75 MHz
31.5 kHz to 58 kHz
50 to 100 Hz
50° to 104°F
32° to 140° F
15"
39.9 cm
42.2 cm
40.9 cm
20.4 kg
35.5 cm
17"
17.1 in
43.43 cm
17.4 in
44.29 cm
17.9 in
45.46 cm
56.6 lb
25.6 kg
17 in
43 cm
10° to 40°C
0° to 60°C
A-1
